Superior Electric STABILINE DIN3-70 Series Owner's Manual

STABILINE® Transient Voltage Surge Suppressors
Thank you for purchasing the DIN3-70 Series STABILINE
Transient Voltage Surge Suppressor ... another Superior product!!
Expect exceptional performance. The unit is built to the highest
standards for your complete satisfaction.
To assure many years of uninterrupted service, please read this
Owners Manual to familiarize yourself with the operation and
proper installation of the DIN3-70 Series unit.
DIN3-70 Series STABILINE® Transient Voltage Surge Suppressors are single pole, parallel and/or "in-line" connected, MOV technology
Class I, Category C Surge Protective Devices suitable for use in AC electrical power systems for protection against surge and transient activity.
DIN3-70 Series protectors provide 70 or 100 kA Surge Amp Capacity in a maintenance free, low profi le, DIN Rail mountable module. All line
voltage protectors (L-In / L-Out) can also be connected "in-line" and provide for 50A Maximum Continuous Operating Current protection.
MODEL NUMBER & Typical System Voltage / Service Confi gurations
STABILINE
Model
DIN3-70-120-L1
DIN3-70-220-L1
DIN3-70-277-L1
DIN3-100-NG1 120, 120/240, 220, 277, 380, 480 VAC Neutral to Ground
For a minimum of (20) 8 x 20usec surges
1
2 UL 1449 2nd Edition, (6kV, 500A 8 x 20usec) Surge Voltage Rating
3
C3 Combination Wave, 20kV, 8 x 20usec, 10 kA
TYPICAL SERVICE CONFIGURATIONS for Parallel-Connected Method
Contact Factory for addititional confi gurations
L
In Out
M M M
F F F
V V V
C
1 Ø, 2-Wire, w/ground
L 1
In
M
F F
V V
Downloaded from Elcodis.com electronic components distributor
DIN3-70 Series - OWNERS MANUAL
Typical
System Voltage / Service Configuration
1 Ø, 120 VAC, 2-Wire, w/ground
1 Ø, 120/240 VAC, 3-Wire SPLIT-PHASE, w/ground
3 Ø, 208Y/120 VAC, 4-Wire WYE, w/ground
1 Ø, 220 VAC, 2-Wire, w/ground
3 Ø, 380Y/220 VAC, 4-Wire WYE, w/ground
3 Ø, 220 or 240 VAC, 3-Wire DELTA
1 Ø, 277 VAC, 2-Wire, w/ground
3 Ø, 480Y/277 VAC, 4-Wire WYE, w/ground
N L 1
In Out
In Out
M M M
F F F
V V V
C
L 2 L
Out
In Out In
M M M
M M M
F F F F F F
V
V V V V V
C
C
3 Ø, 4-Wire WYE, w/ground
L1 L2
In Out In Out
M M M
M M M
F F F F
F F
V
V V V V V
C
C
3 Ø, 3-Wire DELTA
Protector Quantity
Protection Mode
Line
Voltage
L-N, N-G 1
L-N / L-N, N-G 2
L-N / L-N / L-N, N-G 3
L-N, N-G 1
L-N / L-N / L-N, N-G 3
L-L / L-L / L-L 3
L-N, N-G 1
L-N / L-N / L-N, N-G 3
N-G N/A
L 2 N
In Out
In Out
M M M
F F F
V V V
C
1 Ø, 120/240 VAC, 3-Wire
SPLIT-PHASE, w/ground
3 N
Out In Out
M
M
F
V
C
L2
In Out
M M M
F F F
V V V
C
Surge Performance Specifications
1
Max Surge
N-G MCOV Nominal Surge
Current Rating
Current Rating
1
150 VAC 70 kA 30 kA
1
1
1
330 VAC 70 kA 30 kA
1
N/A
1
330 VAC 70 kA 30 kA
1
1 600 VAC 100 kA 50 kA
SPECIFICATIONS
Electrical Specifi cations
Modes of Protection: L-N; L-G; L-L protectors use MOV
technology and N-G protector use Gas Tube.
Line Voltage Protectors: Multi-redundant protection
circuit (triple stage fault indicators).
Input Power Frequency: 47-64 Hz.
Associated Fusing: DIN3-70 protectors incorporate an
internal thermal disconnect system with time-delayed
Class J,30A-125A over current fuses.
Environmental Specifi cations
Operating Temperature: -40° C to 85° C (-40° F to 185° F).
Relative Humidity: 5% to 95% non-condensing.
Max. Operating Altitude: 4,000 meters (13,000 feet).
Mechanical Specifi cations
Enclosure: IP20 enclosures (UL94V0 thermoplastic
housing material).
Mounting: Din Rail 35mm symmetrical.
Connection Method: Screw terminal # 2-10 AWG.
Size (H x W x D): 3.5 x 1.42 x 2.63 inches (90.0 x 36.0 x 67 mm).
Weight (Shipping): 0.80 lbs (0.35 kg).
General Specifi cations
Standards Compliance and Safety Approvals: Meet UL
1449, 2nd Edition, EN61643-11 (Europe), ANSI/IEEE
C62.41-2002, NF EN 61643-11 (France), VDE0675-6,
CSA-22.2 and CE marked.
Warranty: Ten Years.
* These INSTRUCTIONS are subject to change
without notice.
2 3
UL 1449 C3 Comb
SVR Rating Wave
400 VAC 400 VAC
600 VAC 600 VAC
600 VAC 600 VAC
800 VAC ----
