FILTREC F280 Series Manual

TECHNICAL INFORMATION

HOUSING
HYDRAULIC SYMBOL:
PRESSURE:
CONNECTION PORTS:
MATERIALS:
BYPASS:
ELEMENT
FILTER MEDIA:
DIFFERENTIAL COLLAPSE PRESSURE:
OPERATING TEMPERATURE RANGE:
FLUID COMPATIBILITY:
HYDRAULIC DIVISION
F280 SERIES
In line medium pressure filters
Inline filters for operating pressure up to 320 bar, flow rate up to 400 l/min.
Available with or without bypass, indicator port is a standard option to fit a
visual or electrical differential indicator.
tested according to NFPA T3.10.5.1 , ISO3968
Max operating: F280 D12x port size G 1/2" & 3/4": 320 bar
F280 D12x port size G 1":
F280 D14x:
Burst: F280 D12x port size G 1/2" & 3/4": 1260 bar
F280 D12x port size G 1":
F280 D14x:
G 1/2"÷1 1/2"
Head:
Bowl:
Seal:
No by-pass or 6 bar setting
tested according to ISO 2941, 2942, 2943, 3968, 16889, 23181
Inorganic microfiber:
Paper:
21 bar or 210 bar
-25°C +100°C
Full with HH-HL-HM-HV (acc. To ISO 2943).
For use with other fluid please contact Filtrec Customer Service
(info@filtrec.it).
F280 SERIES
cast iron
extruded steel
NBR (FKM on request)
G03 - G06 - G10 - G15 - G25
C10
320 bar
280 bar
960 bar
960 bar
F280 SERIES 1/8
