Summary of Contents for MAINGEAR F131
- Page 1 F131 System Maintenance Guide...
-
Page 2: Table Of Contents
Table of Contents Page Preparation………………………………………………………………………………3 Cleaning…………………………………………………………………………………….8 Draining…………………………………………………………………………………….9 Filling……………………………………………………………………………………….10 Re-Assembly…………………………………..……………………………………..11 Support…………………………………………………………………………………...12... -
Page 3: Preparation
1. Detailing Cleaning Spray 2. Microfiber Cleaning Cloth Our website contains the following tools in a kit able to be purchased. 1x Bottle of MAINGEAR Coolant 1x Microfiber Cloth 1x Squeeze Bottle 1x Compressed Air Can 1x Detailing Cleaning Spray... - Page 4 Preparation 1. Power off your system, unplug every connection, and place your system in an area easily accessible from all angles. 2. Start off by removing the front glass by removing the four thumb screws shown below. Place the glass back inside the box in between the foam inserts (or safe place on a soft/protected surface.) …………………………………………………..
- Page 5 Preparation 4. Remove the top grill by gently pulling up on it. The clips should release relatively easy. Place the grill inside the box separated by the foam inserts (or on another soft/protected surface.) …………………………………………………………………………….. Ref 3 5. On the front side of the case, the top right 2 screws need to be undone.
- Page 6 Preparation Reference 5 7. Facing the front of the chassis, you may now lift the right side of the top grill and insert your place holder to prop up the top panel. Turn the power switch into the off position “o” and press the power button to drain any residual power remaining in the system.
- Page 7 Preparation Reference 6 The preparation process is now complete. Most of the maintenance that needs to be done can now be completed in your current system’s state. Please skip to a page down below to continue with your process: Cleaning…………………………………………………………………………………….….…….8 Draining……………………………………………………………………………………..….…….9 Filling………………………………………………………………………………………………….10 IF AT ANY POINT IN TIME LIQUID MAKES CONTACT WITH...
-
Page 8: Cleaning
Cleaning General Cleaning • Using a can of compressed air, you may blow out the system thoroughly until most dust and other particles are removed from your system. When directing air to any fan, please ensure to hold the fan so it does not spin with the air current, as allowing the fan to spin during this procedure may damage the fan bearings and will make it significantly harder to clean the fan. -
Page 9: Draining
Draining Draining an APEX open loop system • Set down a bucket to catch all fluid removed from the loop. • Remove the rubber cover on the fitting at the bottom of the APEX block. Attach a drain tube to the fitting and guide it to the bucket to catch the liquid that will be drained. -
Page 10: Filling
Filling Filling an APEX open loop system • Remove the right fitting on the top of the APEX block..Ref 8 • Pour coolant into a squeeze bottle • Insert nozzle of squeeze bottle into the opening where the fitting was removed from and gently squeeze the bottle to refill the loop. -
Page 11: Re-Assembly
• Set the back panel onto the chassis and replace all 8 screws. • Carefully reseat the front panel and hand tighten all 4 thumbscrews to secure the glass back onto the chassis. • Reconnect your system and continue enjoying your MAINGEAR system! -
Page 12: Support
Support To get support from MAINGEAR experts use the resources listed below: Hours of Operation Mon – Fri: 10:00 AM – 7:00 PM EST SAT: 10:00 AM – 1:00 PM EST Phone Number: 1-888-624-6432 Email: support@maingear.com...
