Vitavia VA0040-TRP Assembly Instructions Manual

Hide thumbs

page of 40

/ 40
Bookmarks

Quick Links

Download this manual

Montageanleitung

Notice de Montage

Montage Instructies

Montagevejledning

Monteringsanvisning

Montasjeveiledning

0111.01.2210

Assembly instructions

Kokoonpano-ohjeet

Istruzioni di Montaggio

Montážní Návod

Instrukcja Montażu

Navodila za Montažo

Szerelési útmutató

VA0040-TRP

5000P

Skupština Upute

Skupština Uputstvo

Instrucţiuni de Asamblare

Popis konštrukcie

инструкция по монтажу

Інструкція по монтажу

Need help?

Do you have a question about the VA0040-TRP and is the answer not in the manual?

Questions and answers

Summary of Contents for Vitavia VA0040-TRP

Page 1 Montageanleitung Kokoonpano-ohjeet Skupština Upute Notice de Montage Istruzioni di Montaggio Skupština Uputstvo Montage Instructies Montážní Návod Instrucţiuni de Asamblare Montagevejledning Instrukcja Montażu Popis konštrukcie Monteringsanvisning Navodila za Montažo инструкция по монтажу Montasjeveiledning Szerelési útmutató Інструкція по монтажу VA0040-TRP 5000P 0111.01.2210...
Page 3 Glazing - Polycarbonate Verglasung - Hohlkammerplatten 22 - 25 Montering af Glas - Kanal plader i polykarbonat Swing Door Schwingtür 26 - 29 Svingdør Sliding Door Schiebetür 30 - 35 Skydedøre Roof Vents Dachfenster 36 - 39 Tagvindue VA0040-TRP 0111.01.2210...
Page 4 Vises senere Alternative options Not required Incorrect! Alternativen nicht benötigt Falsch! Alternative muligheder Ikke nødvendig Forkert! 2033 Version 1 to 3 Version 1 only Variante 1 bis 3 Nur Variante 1 Version 1 til 3 Kun version 1 VA0040-TRP 0111.01.2210...
Page 5 Verglasung möglichkeiten Forskellige glas muligheder Polycarbonate Full Pane Glass Hohlkammerplatten Ganze Scheiben Kanal plader i polykarbonat Hele baner Split Pane Glass Frosted Pane Glass Klinkerverglasung Nörpelglas Delt glas Uigennemsigtigt glas Persons required. Important! Go to Not included in product! VA0040-TRP 0111.01.2210...
Page 6 1067 2237P 1092 2240P 455.5 1343 2241P 455.5 1404 2242P 445.5 1500 M6 x 5 2244P 1515 2245P 2001 M6 x 12 2248P 104.5 2207P 1002.5 2249P 104.5 2209P 2250P 2210P 1002.5 2251P 2214 2252P 2215P 1002.5 2253P VA0040-TRP 0111.01.2210...
Page 7 3.5 x 30 2257 23.5 2289 3.9 x 34 2258P 2290P 2260P 2292P 493.5 2261P 2293P 510.5 2262P 2391P 2263P 2399 Nylon 2270P 6056 2271 9029 2272 9030P 2275 50.7 9031P 1042 2276 46.7 9106 2280 2281 2285 VA0040-TRP 0111.01.2210...
Page 8 242 x 508.5 / 678 40006239 242 x 678 / 508.5 40002015 177.5 x 0 / 62 / 0 40002011 242 x 516 40002012 242 x 454 40002013 242 x 207 40002010 242 x 318 40002009 242 x 254 Total Mirror of VA0040-TRP 0111.01.2210...
Page 9 {S0} 1001 9031P 1002 9106 9030P 9030P 9106 9031P 9106 9106 9031P 9106 9030P VA0040-TRP 0111.01.2210...
Page 10 10mm 10mm 0.3A 0.3B 2x 1001 2x 1001 9030P / 9031P 9030P / 9031P 2x 1002 2x 1002 9106 0.3C 1002 ≤ 3 Nm VA0040-TRP 0111.01.2210...
Page 11 {S1} 1001 2215P 6x 2 1x 2 1002 2231P 6x 2 3x 2 2207P 1x 2 2215P 2231P 2231P 2231P 2207P VA0040-TRP 0111.01.2210...
Page 12 10mm 10mm 1.3A 1.3B 2231P 2231P 2231P 1001 1001 2207P 2207P 1002 1.3C 1.4A 2231P 1001 2215P 1002 2231P 2207P 1.4B 2215P 1002 ≤ 3 Nm 2231P 2215P 2231P Mirror of VA0040-TRP 0111.01.2210...
Page 13 242 x 678 / 508.5 1x 2 40002015 177.5 x 0 / 62 / 0 1x 2 Total 2249P 2248P 2241P 2240P 2280 2245P 2244P 2281 2237P 1343 1343 2290P 2290P 2292P 2292P 2230P 2236P 2235P 2230P 2209P VA0040-TRP 0111.01.2210...
Page 14 2241P  2237P 1001  1001 2249P  AL, AR, D 2248P 1001 2248P 2237P 2249P 3x 1002 2.5B 2.6A 2241P  2240P 1001 2248P 2235P  2237P 1001 1001 1001 2237P 2235P Important! Look closely Outside Recycle VA0040-TRP 0111.01.2210...
Page 15 2.7B 2244P 2245P 4x 1002  2230P 1343 2x 1001 2292P 2290P 2230P 2281  2280 2241P 2244P  2290P 2230P 2244P 2x 1001 2292P 2245P 1001 2.8A 2.8B 2235P 2236P 2290P 2290P 2235P 2235P 2236P Mirror of VA0040-TRP 0111.01.2210...
Page 16 2230P 2.10A 2.10B  1002  1002 1001  2209P  2230P 1001 4x 1002 2209P AL / AR 4x 1001  2209P 2209P 2.10C 2.11 1002 2292P ≤ 3 Nm 2235P 2209P go to Outside Mirror of VA0040-TRP 0111.01.2210...
Page 17 {S3} {S0} 1001 1092 2293P {S1} 1002 2225P 9029 {S2} 1056P 2242P 2225P 3x 2242P 3x 2242P {S1} {S2} 2293P 2293P 2293P 2293P {S2} {S1} {S0} VA0040-TRP 0111.01.2210...
Page 18 {S2} 1001/1002 3.4A 3.4B 2230P {S2}  1001  2230P 2209P {S1} 1002 2207P 2209P 2207P {S2} {S1} {S1} 3.5A 3.5B {S2} 2240P 2241P 2215P 2240P {S1} 2215P 1092 1092 3x1002 3x1001 {S2} 2293P 2293P 2230P Mirror of VA0040-TRP 0111.01.2210...
Page 19 2293P 3.6A 3.6B 2293P 1001 2207P 1002 2207P 3.7A 3.7B 2225P 2225P  1001  1092 1002 2240P 1092 2240P 2225P 3.7C 3.8A 2x 1001 2x 1001 1002 1002 2242P 2242P 2242P 2x 1001 Mirror of VA0040-TRP 0111.01.2210...
Page 20 2225P 3.8B 3.8C 2225P 2x 1001 3x 1001 1002 1002 2242P 2242P 2242P 3.8D 3.9A 2242P 2242P 1001 2225P 1001 2242P 1002 2231P 2215P 3.9B 3.10A 2242P 2242P  1056P 2231P 1002 1002  2215P VA0040-TRP 0111.01.2210...
Page 21 3.10B 3.11A 2225P 2242P 1056P {S0} 2230P 3.11B 3.11C 2231P 2231P   1002  9029  9029 9030P 9031P 3.12 1002 ≤ 3 Nm VA0040-TRP 0111.01.2210...
Page 22 {S4} 1001 1404 2399 1002 2210P 6056 {S3} 1006 2260P No. 4mm 5000P 40002011 242 x 516 40002012 242 x 454 40002013 242 x 207 Total 1404 2210P 2260P 1404 1404 {S3} 2210P 1404 VA0040-TRP 0111.01.2210...
Page 23 10mm 10mm 4.3A 4.3B E, F, G 4.3C 4.3D {S3} {S3} 4.4A 4.4B 2210P 2210P   4x 1001  4x 1001 2210P Important! Look closely Outside Recycle VA0040-TRP 0111.01.2210...
Page 24 4.4C 4.5A 2210P F / G 1002 2210P 1404 2215P 4.5B 4.6A 2210P 2225P 1404 2399 2399 4.6B 4.7A 1006 1006 2225P 6056 2399 2399 2260P Mirror of VA0040-TRP 0111.01.2210...
Page 25 4.7B 4.7B 2260P 1002 6056 2260P 1002 4.7D 1002 6056 ≤ 3 Nm 2260P VA0040-TRP 0111.01.2210...
Page 26 1002 2252P 2258P 2276 2288 {S4} 1092 2253P 2270P 2285 1500 2254P 2272 2286 No. 4mm 5000P 40002010 242 x 318 Total 2275 7A.2 2272 2253P 1092 2270P 2252P 1092 2254P 2272 1092 2276 2258P 2270P 1092 2256P VA0040-TRP 0111.01.2210...
Page 27 2x 1001 1001 2x 1001 2253P 2256P 2x 1001 2256P 2256P 2253P 7A.4A 7A.4B 2258P 2258P 2254P 2x 1001 2x 1001 2254P 2254P 7A.5A 7A.5B  2256P 2254P 2253P  2258P Mirror of Important! Look closely Outside Recycle VA0040-TRP 0111.01.2210...
Page 28 2252P 2256P  1001 2x 1001   2x 1001 7A.7A 7A.7B 2270P 1515 2270P 2258P 2258P 2252P 2252P 2258P 2252P 2270P 1500 2256P 7A.8A 7A.8B 2286 2286 2287 2258P 2285   2288 2288 2285 Mirror of VA0040-TRP 0111.01.2210...
Page 29 7A.9A 7A.9B 2258P 2275 2256P 2272 2272 1001 2276 2253P 2276 2209P 2258P 1002 7A.9C 7A.9D 2235P 2237P 1002 2275 2209P 1001 2256P 2276 7A.9E 7A.10 1002 2275 2253P 2237P ≤ 3 Nm 2235P VA0040-TRP 0111.01.2210...
Page 30 1001 1515 2251P 2255P 2271 1002 2001 2252P 2257 2285 1006 2214 2253P 2258P 2289 {S4} 1500 2250P 2254P 2270P No. 4mm 5000P 40002010 242 x 318 Total 7B.2 2251P 2253P 2270P 2252P 2250P 2254P 2258P 2270P 2255P VA0040-TRP 0111.01.2210...
Page 31 1002 2258P 2255P 1001 1001 2x 1001 2253P 2255P 2255P 2255P 2253P 7B.4A 7B.4B 2258P 2258P 2254P 2x 1001 2x 1001 2254P 2254P 7B.5A 7B.5B  2255P 2254P 2253P  2258P Mirror of Important! Look closely Outside Recycle VA0040-TRP 0111.01.2210...
Page 32 1002  2x 1002 2253P   2258P 1002  2254P  1001  2252P 2252P  2255P 2x 1001  1001 7B.8A 7B.8B 2270P 1515 2270P 2258P 2258P 2252P 2252P 2258P 2252P 2270P 1500 2255P Mirror of VA0040-TRP 0111.01.2210...
Page 33 7B.9A 7B.9B 2252P 2252P 2289 2285 2285 7B.10A 7B.10B 2252P 2258P 2252P 2271 2271 7B.11A 7B.11B 1002 2237P 1001 Mirror of VA0040-TRP 0111.01.2210...
Page 34 7B.12R 7B.12L 7B.12L 2237P 7B.13A 7B.13B 2251P 2251P 2237P 2237P 2237P 2251P 2251P 7B.13C 7B.13D 2001 ≈ 45mm 2001 2251P 2251P 1002 Alternative options VA0040-TRP 0111.01.2210...
Page 35 2251P 7B.15A 7B.15B 2251P 1002 2257P 1001 2250P  2257P  2257P 1002 2001 1001 2250P  2251P  1002 2001 1002   & 7B.15C 7B.16 2257P 1002 2250P ≤ 3 Nm 2230P 2250P 2001  Important! VA0040-TRP 0111.01.2210...
Page 36 {S8} {S4} 1001 1019 2262P 1002 1067 2263P 1006 2261P 2391P No. 4mm 5000P 40002009 242 x 254 Total 2261P 1019 2262P (2291P) 1067 2262P (2291P) 2263P VA0040-TRP 0111.01.2210...
Page 37 2262P 2391P 1001 2262P 8.4A 8.4B 2261P 2262P 2262P 2261P 8.4C 8.4D 2262P 2262P 1002   2262P 1002  2263P 1001 1001    1001  2263P 2263P 2262P Mirror of Important! Look closely Outside Recycle VA0040-TRP 0111.01.2210...
Page 38 8.6A 1002 1067 1006 ≤ 3 Nm 1006 2263P 1019 8.6B 8.7A 1067 1067 2263P 8.7B 8.8A 1019 2261P {S8} 2225P 1067 {S6} VA0040-TRP 0111.01.2210...
Page 39 8.8B 8.8C 2261P 2225P {S6} 2263P 1067 6056 2260P 8.8D VA0040-TRP 0111.01.2210...
Page 40 E.P.H. Schmidt u. Co. GmbH Hoefkerstrasse 30 44149 Dortmund OPJ A/S Postfach 170163 Volderslevvej 36 A 44060 Dortmund 5260 Odense S Deutschland Danmark Tel.: +49 231 941655 0 Tel.: +45 66 15 10 30 Fax: +49 231 941655 99 Fax: +45 66 15 00 84 www.eph-schmidt.de www.opj.dk verkauf@eph-schmidt.de...
