(50.8 cm)
(49.5 cm)
76½"
76
½
"
(194.3 cm)
(194.3 cm)
(144.8 cm)
(143.5 cm)
SUBMITTAL
STANDARD:
6" plain end inlet/outlet | Capacities - Liquid: 750 gal.(2,839 L); Grease (Factory Rating): 5,336 lbs. (2,420.4 kg)@ 100 GPM /
3,628 lbs. (1,645.6 kg)@ 200 GPM; Solids: 75 gal. (284 L) | Highway traffic load rated, bolted, gas/water tight composite covers. (16,000 lbs.)
OPTIONS:
H20 Load Rated Pickable
Cast Iron Covers
4" Plain End Inlet/Outlet
4" Male Thread Inlet/Outlet
6" Male Thread Inlet/Outlet
9500 Woodend Road | Edwardsville, KS 66111 | Tel: 913-951-3300 | Fax: 913-951-3399 | www.schierproducts.com
057-0880-03
GGI-750
Gravity Grease Interceptor Technical Data
Submittal
75"
81"
(94.0 cm)
(205.7 cm)
19
20"
½
"
56½"
5
7
"
67½"
68"
(172.7 cm)
(171.5 cm)
TeleGlide Risers
SR24 (x2) 5" – 23"
LR24 (x2) >23" – 38"
SR24 (x4) >38" – 43"
SR24 (x2) + LR24 (x2) >43" – 58"
LR24 (x4) >58" – 72"
MODEL NUMBER:
GGI-750
PART #: 4350-001-04
| Specifications | Installation
APPROVAL:
This product is made-to-order and is not returnable.
This product is for below grade installations only.
Signature:
Date:
Company:
Specifying Engineer:
Engineering Firm:
DESCRIPTION: Polyethylene Gravity Grease Interceptor
100/200 GPM - 750 gallon capacity
DWG BY: B. Karrer
DATE: 4/10/2019
21
20"
"
½
(50.8 cm)
(54.6 cm)
56½"
5
5
"
(143.5 cm)
(139.7 cm)
REV:
5 11/8/2018
ECO:
© Copyright 2019 Schier, All Rights Reserved
page 1 of 5
Advertisement
Table of Contents
Related Manuals for Schier BigFoot GGI-750
Summary of Contents for Schier BigFoot GGI-750
- Page 1 PART #: 4350-001-04 DWG BY: B. Karrer DATE: 4/10/2019 REV: 5 11/8/2018 ECO: 9500 Woodend Road | Edwardsville, KS 66111 | Tel: 913-951-3300 | Fax: 913-951-3399 | www.schierproducts.com © Copyright 2019 Schier, All Rights Reserved 057-0880-03 page 1 of 5...
- Page 2 SPECIAL PRECAUTIONS For All Schier Grease Interceptor Installations - Failure to follow this guidance voids your warranty Installation Instructions High Temperature Kitchen Water installation Installation instructions and additional If water is entering the interceptor at excessive temperature (over 150º F), a...
- Page 3 Adapters with up to Solids: 75 gal. 3-1/2" of adjustability ENGINEER SPECIFICATION GUIDE Schier Big Foot™ grease interceptor model # GGI-750 shall be lifetime guaranteed and made in USA of seamless, molded TOP VIEW polyethylene with minimum 3/4" uniform wall thickness.
- Page 4 PART #: 4350-001-04 DWG BY: B. Karrer DATE: 4/10/2019 REV: 5 11/8/2018 ECO: 9500 Woodend Road | Edwardsville, KS 66111 | Tel: 913-951-3300 | Fax: 913-951-3399 | www.schierproducts.com © Copyright 2019 Schier, All Rights Reserved 057-0880-03 page 4 of 5...
- Page 5 Tilting is done using gasket flexibility. or Riser Tilting before tightening clamps may ruin a perfect gasket seal. Schier recommends tilting only the adapter versus the entire riser assembly to make sure your riser height and proper tank Figure 2 - Insertion Depths access is maintained.
