- Page 1 The Muir Sectional support@maidenhome.com (888) 513 - 5754 Assembly Instructions...
- Page 2 The Muir Sectional support@maidenhome.com (888) 513 - 5754 Assembly Instructions Sofa Components Throw Pillows (6) Legs (3) Support Leg (1) Arm (1) Short Screws (12) Long Screws (15) Note: 120x102 Sectionals have 15 long screws and 130x112 Sectionals have 16 long screws.
- Page 3 The Muir Sectional support@maidenhome.com (888) 513 - 5754 Assembly Instructions Secure both legs to the side table platform base by placing the short screws with washers into the pre-drilled holes of the platform base. Ensure the leg installed opposite the side table has pre-drilled holes that are facing towards the...
- Page 4 The Muir Sectional support@maidenhome.com (888) 513 - 5754 Assembly Instructions Elevate the return sofa platform on top of two blocks or stacks of books, making sure it is flat and facing up. Place the ledge of the longer backrest into the longest slot of the return sofa platform.
- Page 5 The Muir Sectional support@maidenhome.com (888) 513 - 5754 Assembly Instructions Place the ledge of the arm panel into the designated slot and connect to the backrest by inserting the pre-attached prolonged fastener into the backrest slot and hooking into place. Press down firmly to set in place.
- Page 6 The Muir Sectional support@maidenhome.com (888) 513 - 5754 Assembly Instructions While holding the backrest and arm in place, carefully rotate the piece off of the blocks and onto the floor, so it is resting on the backrest. Secure both the arm piece and backrest by placing the long screws with washers into the pre-...
- Page 7 The Muir Sectional support@maidenhome.com (888) 513 - 5754 Assembly Instructions Secure the leg and support leg to the return sofa platform base by placing the short screws with washers into the pre- drilled holes of the platform base. Ensure the corner of the support leg is aligned to the outside corner of the platform...
- Page 8 The Muir Sectional support@maidenhome.com (888) 513 - 5754 Assembly Instructions Carefully flip the return sofa platform base upright. Secure the two platforms together by placing the short screws with washers through the pre-drilled holes in the cleat and leg of the platform bases. Use an allen key to tighten the screws,...
- Page 9 The Muir Sectional support@maidenhome.com (888) 513 - 5754 Assembly Instructions Place the ledge of the shorter backrest panel into the designated slot and connect to the longer backrest by inserting the pre-attached prolonged fastener into the backrest slot and hooking into place. Press down firmly to set in place.
- Page 10 The Muir Sectional support@maidenhome.com (888) 513 - 5754 Assembly Instructions Secure the shorter backrest by placing the long screws with washers into the pre-drilled holes of both platform bases. Use an allen key to tighten the screws, being careful not to over tighten.
- Page 11 The Muir Sectional support@maidenhome.com (888) 513 - 5754 Assembly Instructions Set the seat and back cushions into place, securing seat cushions with the tie-down toggles.
