- Page 1 QUICK ADJUST RESISTANCE REMOTE｜Type A STRONG SERIES ROWER User Manual...
-
Page 2: Part List
Part List Type A Please note that the Handlebar Type A has a vertical line on the center part of the handlebar. ROUND HEAD SCREW M2x16MM*4 HANDLEBAR CYLINDER *1 CONTROLLER COVER - BOTTOM *1 CONTROLLER COVER - TOP *1... - Page 3 Type A｜Step 1 - Secure the belt In order to ensure stability and safety, it is crucial to secure the belt properly. Start by extending the belt to its full length, then fold it in half to create a loop. Tie a knot in the loop, and attach it to the handlebar holder.
- Page 4 Type A｜Step 2 - Remove the cap Tools: (Optional) To remove the cap at the end of the handlebar, you will need a flat head screwdriver. Slowly use the screwdriver to loosen the cap by working your way around the circum- ference of the end of the handlebar.
- Page 5 Type A｜Step 3 - Pry apart holder To separate the holder, you may need to apply some force as it is typically glued to- gether. If you end up causing some damage to the holder, don't worry as the part is not necessary...
- Page 6 Type A｜Step 4 - Insert the cylinder in the loop Parts: Insert the cylinder through the loop in the belt. The belt wraps around the cylinder.
- Page 7 Type A｜Step 5 - Slide the cylinder through the handlebar...
- Page 8 Type A｜Step 6 - Attach the ring, foam and the end cap To assemble the ring, foam grip, and cap, you may need to use some soapy water on the handlebar and inside the foam grip to make it easier to slide into place. If necess- ary, wiggle the foam grip until it is securely in place.
- Page 9 Type A｜Step 7 - Ensure the top of the belt is smooth prior to attaching the remote...
- Page 10 Type A｜Step 8 - Snap in the top and the bottom resistance remote on the belt Parts:...
- Page 11 Type A｜Step 9 - Secure the resistance remote by using the four screws provided Tools: Parts:...
- Page 12 Type A｜Complete Please remove the safety slip prior to rowing.
-
Page 13: Battery Replacement
Battery Replacement CR2032 To replace the battery in the remote, you may need to gently remove the battery holder. Replace the battery with a CR2032 type and carefully insert the holder back into the remote. - Page 14 Tip 1: Make sure you adjust the resistance in the finish position...
- Page 15 Tip 2: Make sure the remote is directly aligned with the screen You may need to tip the screen up or down depending on your height...
- Page 16 Tip 3: Keep the remote straight...
