- Page 1 Smart - CC series Solar charge controller Suitable for Lithium batter y (Constant Current, Buck) 10A 30W User Manual User Manual_Smart-CC series_MA CE, Rohs, ISO9001:2015 Subject to change without notice!
- Page 2 Solar charge controller Smart-CC series User Manual Dear Clients, Thanks for selecting the Smart -CC series solar controller. Please take the time to read this user manual, this will help you to take advantage of controller’s new features. This manual gives important recommendations for installing, programming, using and so on.
- Page 3 Dim5 100% 5 Remote control, Default setting D/N Thr 5.0V When Smart-CC series controller is connected to the D/N Dly 0min system, you can setting the controller with S-Unit infrared Load I 0.3A * remote controller, as shown below! Detailed setting operations, please read S-Unit User Manual.
- Page 4 Solar charge controller Smart-CC series User Manual 6.Starting up the controller 8.LVD, LVR, Threshold, Dimming 8.1Low Voltage Disconnect(LVD) Low voltage disconnect setting range: 8.0~15.0V. 8.2Low Voltage Reconnect(LVR) Low voltage reconnect setting range: 8.6~16.0V. If the controller goes into low voltage disconnect, it will restore only when the battery being recharged to the recovery voltage.
- Page 5 Solar charge controller Smart-CC series User Manual 9. Streetlight Function 八、安全特性及故障描述 11.Safety Features and Faults & Alarms Smart-CC series controller with advanced street light control function. The modes of lighting can be based on 11.1 Safety Features customer needs. 9.1 Dusk to Dawn (D2D)
- Page 6 Solar charge controller Smart-CC series User Manual 12.Technical Data Item SMR1006-CCN5M Li System Voltage Max Charging Current Battery Type GEL, Liquid, AGM Lithium（Programmable） Max volt on Bat. Terminal Fast voltage <14.5V (25℃) Boost voltage 14.5V (25℃) Equal voltage 14. V (25℃) Liquid （...
