First Solar 6 Plus Series User Manual

Hide thumbs Also See for 6 Plus Series:
Table of Contents

Advertisement

Quick Links

Download this manual
US
REV 2.0
Plus
First Solar Series 6 Plus Modules | USER GUIDE
MPD-00594-06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6 Plus Series and is the answer not in the manual?

Questions and answers

Related Manuals for First Solar 6 Plus Series

Summary of Contents for First Solar 6 Plus Series

  • Page 1 REV 2.0 Plus First Solar Series 6 Plus Modules | USER GUIDE MPD-00594-06...
  • Page 2 First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR i of 26 First Solar and the First Solar logo are trademarks of First Solar, Inc., registered in the U.S. and other countries. Series 6 Plus is a trademark of First Solar, Inc. NOTICE First Solar reserves the right to make changes in solar module design and/or specifications at any time without notice.

  • Page 3: Table Of Contents

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR ii of 26 TABLE OF CONTENTS INTRODUCTION SAFETY REGULATORY COMPLIANCE PRODUCT IDENTIFICATION & RATINGS 4.1 PRODUCT IDENTIFICATION & RATINGS 4.2 WIRING SYSTEM DERATING FACTORS HANDLING & STORAGE 5.1 HANDLING & STORAGE 5.2 PRODUCT DIFFERENTIATION...

  • Page 4: Introduction

    1 of 26 INTRODUCTION This document provides information on First Solar Series 6 Plus modules (including both Series 6 Plus SL and Series 6 Plus HL) for system designers, installers, and maintenance personnel. In instances that do not apply to both the Series 6 Plus SL and Series 6 Plus HL, the User Guide will specifically name and detail both product types as necessary.

  • Page 5: Safety

    All instructions and safety information should be read and understood before attempting to handle, install, or electrically connect First Solar modules. Failure to follow safety, installation, and handling instructions may result in injury. Only qualified personnel should install, operate, or maintain PV modules or systems.
  • Page 6 DANGER Reverse currents higher than the rated values for a First Solar module, may result in module failure, including module breakage due to RCOL. Extreme and continuous RCOL conditions may cause a fire or create electrical shock hazards. To avoid RCOL: Maintain equivalent voltage in parallel strings by installing an equal number of modules ►...

  • Page 7: Regulatory Compliance

    REGULATORY COMPLIANCE It is the responsibility of the installer and/or system integrator to ensure compliance with all local structural and electrical codes, which may be applicable to the installation and use of First Solar Series 6 Plus modules. For systems installed in North America, First Solar Series 6 Plus modules are Listed by a Nationally Recognized Test Laboratory (NRTL) to UL 61730, the standard for Flat-Plate Photovoltaic Modules and Panels.

  • Page 8: Product Identification & Ratings

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 5 of 26 PRODUCT IDENTIFICATION & RATINGS 4.1 PRODUCT IDENTIFICATION & RATINGS Each module is equipped with a product label on the back and laser-etched identification on the front glass.

  • Page 9: Wiring System Derating Factors

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 6 of 26 Table 2: Temperature Characteristics TEMPERATURE CHARACTERISTICS Module Operating Temperature Range (°C) -40 to +85 Temperature Coefficient of P -0.32%/°C (Temperature Range: 25°C to 75°C) Temperature Coefficient of V -0.28%/°C...

  • Page 10: Handling & Storage

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 7 of 26 HANDLING & STORAGE 5.1 HANDLING & STORAGE When handling packs using forklifts or other mechanical aids, ensure uniform pack support, and the forks fully extend under the pallet. Packs can be lifted from either the short or long side of the pallet. Forklifts must engage the pallet a minimum of 1.3 m (51 in) for long side engagement and a minimum of 1.5 m (60...

  • Page 11: Product Differentiation

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 8 of 26 5.2 PRODUCT DIFFERENTIATION Series 6 Plus SL and Series 6 Plus HL product packaging and labeling are differentiated by the following: Number of modules per pack ►...

  • Page 12: Mechanical Specifications

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 9 of 26 MECHANICAL SPECIFICATIONS Table 3: Series 6 Plus Module Mechanical Specifications Plus SL Plus HL SPECIFICATION Series 6 Series 6 Module Weight 33.3 kg +1.5/-2.5 kg (73.4 lbs +3.3/-5.5 lbs) 34.0 kg +1.5/-2.5 kg (75 lbs +3.3/-5.5 lbs)

  • Page 13: Installation & Mounting

    First Solar is not responsible for bonding failure, breakage, damage, wear, corrosion, or module performance issues that are deemed to be caused by design or installation practices that do not comply with this User Guide.

  • Page 14: Mounting Locations & Load Ratings

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 11 of 26 7.2 MOUNTING LOCATIONS & LOAD RATINGS The interface of the mounting structure to the module frame must meet the technical requirements specified in this User Guide. The mounting system design must provide adequate support for the module to prevent load damage from occurring based on the loading requirements for the given application and the chosen mounting locations.
  • Page 15 SpeedSlot clamps. Other mounting solutions not discussed in this User Guide (Such as - asymmetric mounting, higher load ratings, alternative clamp geometry, etc.) may be permitted, but require evaluation by First Solar (technicalsupport@firstsolar.com). First Solar reserves the right to reasonable access to validate proper installation.
  • Page 16 Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 13 of 26 • Design the Series 6 Plus module mounting interfaces to utilize the SpeedSlot feature, given the universally consistent interface dimensions for both Series 6 Plus SL and HL module types. This avoids the potential risk in managing the different rail top clamp height dimensions between Series 6 Plus SL and HL products.

  • Page 17: Top Mounting

    Figure 5. Module clamps may not continuously span the top of the frame across the midpoint of the long edge frame (to allow for module deflection). Clamps that do not meet the minimum requirements may not preserve module certifications or warranty and must be evaluated by First Solar (technicalsupport@firstsolar.com).

  • Page 18: Speedslot Mounting

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 15 of 26 7.4 SPEEDSLOT MOUNTING The Series 6 Plus module frames include six SpeedSlots on each side. SpeedSlot clamps must either extend 10 mm (0.39 in) beyond the inner edge of the frame, or have a retention feature to prevent module frame dislodgement under load.

  • Page 19: Module Orientation

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 16 of 26 7.5 MODULE ORIENTATION PV performance modeling software, such as PlantPredict (http://www.plantpredict.com), should be used to determine the optimum orientation and tilt angle for each location.

  • Page 20: Wire Management

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 17 of 26 7.7 WIRE MANAGEMENT All wire management shall comply with the applicable NEC/IEC codes and standards for maintaining and managing wires, as well as any applicable local requirements determined by local authorities having jurisdiction.
  • Page 21 Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 18 of 26 Figure 11: Frame Wire Management Hole Locations The above-ground DC cabling (typically a bundle of harnesses and PV array cables) may be supported by the wire management holes located on the Series 6 Plus module edge frames.

  • Page 22: Electrical Interconnection

    Any damage to the module resulting from any such interconnection will not be covered by the First Solar module warranty. Damaged wires, connectors, or junction boxes may cause ground faults, and associated electrical CAUTION hazards, including electrical shock.

  • Page 23: Inverter Compatibility

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 20 of 26 Wiring harnesses are recommended in system designs. The shorter string size and low string current of Series 6 Plus modules make it possible to connect multiple strings together in parallel and return a single pair of DC cables to the combiner box or string inverter.

  • Page 24: Grounding Method

    21 of 26 7.10 GROUNDING METHOD First Solar recommends Series 6 Plus modules be used in negative-grounded systems. Modules must not be subjected to negative voltage bias conditions that can occur in voltage floating or bi-polar systems (subjecting modules to conditions that could drive potential induced degradation). If string inverters or other...
  • Page 25 Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 22 of 26 In order to provide a reliable grounding connection to the module frame, the following hardware or equivalent is required per UL 61730: A UL Listed Grounding Lug with paint cutting star washer and #8-32 by 3/8 inch thread forming ►...

  • Page 26: Maintenance

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 23 of 26 MAINTENANCE 8.1 MAINTENANCE Only qualified personnel should perform maintenance on PV systems. Maintenance (cleaning, electrical inspection, etc.) may pose a risk of electrical shock, injury, or module damage.

  • Page 27: Module Cleaning Guidance

    First Solar does not warrant against breakage, damage, wear, or module Important performance issues that are determined to be caused by module cleaning.

  • Page 28: Module Disposal

    Cleaning solutions vary in design and size and can affect the load dispersed onto the modules. First Solar recommends no more than 40.8 kg (90 lb) per module that is evenly distributed while cleaning. Specific contact points (wheels or belts) can affect the load and pressure placed on the modules.

  • Page 29: Revision History

    Plus First Solar Series 6 Plus Modules | USER GUIDE FIRST SOLAR 26 of 26 REVISION HISTORY REVISION REVISION AMENDMENT DETAILS NUMBER DATE Document created 3/25/2021 Module cleaning guidelines updated 7/1/2021 Addition of higher bins and updated packaging images 10/27/2021...
