  • Page 1 Global REV 1.0 First Solar Series 6 CuRe Modules | USER GUIDE MPD-00600-06-C...
  • Page 2 26 First Solar and the First Solar logo are trademarks of First Solar, Inc., registered in the U.S. and other countries. Series 6, CuRe, Series 6 CuRe, and the Series 6 CuRe logo are trademarks of First Solar, Inc.

  • Page 3: Table Of Contents

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR ii of 26 TABLE OF CONTENTS INTRODUCTION SAFETY REGULATORY COMPLIANCE PRODUCT IDENTIFICATION & RATINGS 4.1 PRODUCT IDENTIFICATION & RATINGS 4.2 SYSTEM DERATING FACTORS HANDLING & STORAGE 5.1 HANDLING & STORAGE 5.2 MODEL TYPE DIFFERENTIATION...

  • Page 4: Introduction

    1 of 26 INTRODUCTION This document provides information on First Solar Series 6 CuRe modules of model types beginning as FS- 6XXX-C (“XXX” references the module power rating) for system designers, installers, and maintenance personnel. Model types including ‘A’ contain an anti-reflective coating (ARC) on the front side surface.

  • Page 5: Safety

    All instructions and safety information should be read and understood before attempting to handle, install, or electrically connect First Solar modules. Failure to follow safety, installation, and handling instructions may result in injury. Only qualified personnel should install, operate, or maintain PV modules or systems.
  • Page 6 DANGER Reverse currents higher than the rated values for a First Solar module, may result in module failure, including module breakage due to RCOL. Extreme and continuous RCOL conditions may cause a fire or create electrical shock hazards. To avoid RCOL: Maintain equivalent voltage in parallel strings by installing an equal number of modules ►...

  • Page 7: Regulatory Compliance

    REGULATORY COMPLIANCE It is the responsibility of the installer and/or system integrator to ensure compliance with all local structural and electrical codes, which may be applicable to the installation and use of First Solar Series 6 CuRe modules. For systems installed in North America, First Solar Series 6 CuRe modules are Listed by a Nationally Recognized Test Laboratory (NRTL) to UL 61730, the standard for Flat-Plate Photovoltaic Modules and Panels.

  • Page 8: Product Identification & Ratings

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 5 of 26 PRODUCT IDENTIFICATION & RATINGS 4.1 PRODUCT IDENTIFICATION & RATINGS Each module is equipped with a product label on the back and laser-etched identification on the front glass.

  • Page 9: System Derating Factors

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 6 of 26 Table 2: Temperature Characteristics TEMPERATURE CHARACTERISTICS Module Operating Temperature Range (°C) -40 to +85 Temperature Coefficient of P -0.28%/°C (Temperature Range: 25°C to 75°C) Temperature Coefficient of V -0.24%/°C...

  • Page 10: Handling & Storage

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 7 of 26 HANDLING & STORAGE 5.1 HANDLING & STORAGE When handling packs using forklifts or other mechanical aids, ensure uniform pack support, and the forks fully extend under the pallet. Packs can be lifted from either the short or long side of the pallet. Forklifts must engage the pallet a minimum of 1.3 m (51 in) for long side engagement and a minimum of 1.5 m (60...

  • Page 11: Model Type Differentiation

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 8 of 26 5.2 MODEL TYPE DIFFERENTIATION The Series 6 CuRe module includes model numbers of FS-6XXX-C, FS-6XXXA-C, FS-6XXX-C-I, and FS-6XXXA- C-I (“XXX” references the module power rating). The model types are differentiated by the following factors: Model number presence on the module product label and pack label ►...

  • Page 12: Mechanical Specifications

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 9 of 26 MECHANICAL SPECIFICATIONS Table 3: Series 6 CuRe Module Mechanical Specifications SERIES 6 CURE MODEL TYPE SPECIFICATION FS-6XXX-C / FS-6XXXA-C FS-6XXX-C-I / FS-6XXXA-C-I Module Weight 34.9 kg +1.5/-4 kg (76.9 lbs +3.3/-8.8 lbs) 34.2 kg +1.5/-4 kg (75.4 lbs +3.3/-8.8 lbs)

  • Page 13: Installation & Mounting

    First Solar is not responsible for bonding failure, breakage, damage, wear, corrosion, or module performance issues that are deemed to be caused by design or installation practices that do not comply with this User Guide.

  • Page 14: Mounting Locations & Load Ratings

    SpeedSlot Mount: 400 mm 800 mm FS-6XXX-C-I / FS-6XXXA-C-I Model Types are IEC 61215/IEC 61730 certified at Mounting Configuration B only when supplemented with additional interface point(s). Consult First Solar for supplemental documentation. FIRST SOLAR, INC. | MPD-00600-06-C REV 1.0...
  • Page 15 It is recommended all array positions be designed to mechanically accommodate the FS-6XXX-C / FS-6XXXA- C model types, given their ability to be utilized in all array zones. For the same reason, First Solar will typically provide these FS-6XXX-C / FS-6XXXA-C model types as spares and/or warranty replacements.
  • Page 16 First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 13 of 26 CAUTION Model types FS-6XXX-C-I / FS-6XXXA-C-I may only be deployed in engineered PV systems, where the following conditions are met: UL 61730 is the applicable certification standard (in any instance where a ►...

  • Page 17: Top Mounting

    9 mm (0.35 in) minimum width on the top ledge and 30 mm (1.18 in) minimum length as depicted in Figure 5. Clamps that do not meet the minimum requirements may not preserve module certifications or warranty and must be evaluated by First Solar (technicalsupport@firstsolar.com). Figure 5: Shared Top Clamp Detail...

  • Page 18: Speedslot Mounting

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 15 of 26 7.4 SPEEDSLOT MOUNTING The Series 6 CuRe module frames include six SpeedSlots on each side. SpeedSlot clamps must either extend 10 mm (0.39 in) beyond the inner edge of the frame, or have a retention feature to prevent module frame dislodgement under load.

  • Page 19: Module Orientation

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 16 of 26 7.5 MODULE ORIENTATION PV performance modeling software, such as PlantPredict (http://www.plantpredict.com), should be used to determine the optimum orientation and tilt angle for each location. Mount modules in portrait orientation for applications where row-to-row shading could occur. Landscape orientation is permitted only in flat mount applications where the module long edge is not completely shaded and when compliant with Section 7.6 Module Shading Considerations.

  • Page 20: Wire Management

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 17 of 26 7.7 WIRE MANAGEMENT All wire management shall comply with the applicable NEC/IEC codes and standards for maintaining and managing wires, as well as any applicable local requirements determined by local authorities having jurisdiction.
  • Page 21 First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 18 of 26 Figure 11: The above-ground DC cabling (typically a bundle of harnesses and PV array cables) may be supported by the wire management holes located on the Series 6 CuRe module edge frames.

  • Page 22: Electrical Interconnection

    Any damage to the module resulting from any such interconnection will not be covered by the First Solar module warranty. Damaged wires, connectors, or junction boxes may cause ground faults, and associated electrical CAUTION hazards, including electrical shock.

  • Page 23: Inverter Compatibility

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 20 of 26 Wiring harnesses are recommended in system designs. The shorter string size and low string current of Series 6 CuRe modules make it possible to connect multiple strings together in parallel and return a single pair of DC cables to the combiner box or string inverter.

  • Page 24: Grounding Method

    21 of 26 7.10 GROUNDING METHOD First Solar recommends Series 6 CuRe modules be used in negative-grounded systems. Modules must not be subjected to negative voltage bias conditions that can occur in voltage floating or bi-polar systems (subjecting modules to conditions that could drive potential induced degradation). If string inverters or other...
  • Page 25 First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 22 of 26 A UL Listed grounding strap type EM2050 as manufactured by Electric Motion CO. Inc. ► Grounding means must be secured to grounding hole opening on frame and torqued to 25 in-lbs.

  • Page 26: Maintenance

    Other snow clearing methods, such as blowers, may be used depending on snow conditions and if approved by First Solar. To prevent pile up and overload, periodically clearing snow from the bottom modules first in an array is a critical process.

  • Page 27: Module Cleaning Guidance

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 24 of 26 8.2 MODULE CLEANING GUIDANCE Series 6 CuRe modules do not require cleaning in most climates. Installed modules may collect a light layer of dust and/or dirt (soiling) over time and periodic rainfall should be sufficient to remove light soiling in most cases.

  • Page 28: Module Disposal

    First Solar recommends no more than 40.8 kg (90 lb) per module that is evenly distributed while cleaning. Specific contact points (wheels or belts) can affect the load and pressure placed on the modules.

  • Page 29: Revision History

    First Solar Series 6 CuRe Modules | USER GUIDE FIRST SOLAR 26 of 26 REVISION HISTORY REVISION REVISION AMENDMENT DETAILS NUMBER DATE Document created 3/25/2021 FIRST SOLAR, INC. | MPD-00600-06-C REV 1.0...
