- Page 1 User Manual PT-HDBT-1020HU-RX User Manual HDBaseT 3.0 HDMI and USB2.0 Receiver Model PT-HDBT-1020HU-RX Designed in Germany © 2022 PureLink GmbH All rights reserved. VersionV1.0...
-
Page 2: Fcc Statement
User Manual PT-HDBT-1020HU-RX Preface Read this user manual carefully before using this product. Pictures shown in this manual are for reference only. Different model layouts and specifications are subject to the physical product. This manual is for operation instructions only, not for any maintenance usage. - Page 3 PT-HDBT-1020HU-RX REACH | 1907/2006/EU ROHS | 2011/65/EU PureLink hereby declares that this product PureTools PT-HDBT-1020HU-RX complies with Directives 1907/2006/EU und 2011/65/EU. EMC / LVD (Electro Magnetic Compatibility / Low Voltage Directive) PureLink GmbH hereby declares that this product PureTools PT-HDBT-1020HU-RX complies with Directives 2014/30/EU and 2014/35/EU.
- Page 4 User Manual PT-HDBT-1020HU-RX SAFETY PRECAUTIONS To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material ⚫...
-
Page 5: Product Introduction
1.Product Introduction 1.1 Introduction The PT-HDBT-1020HU-RX is an uncompressed 18G HDBaseT3.0 receiver that allows signal transmission up to 100m at 4K@60Hz/ 1080p@60Hz via CAT6A cable. The receiver features one HDMI output, one HDBT input and 4 USB 2.0 ports for connecting with KVM devices such as camera, speakphone, keyboard and mouse. -
Page 6: Panel Description
User Manual PT-HDBT-1020HU-RX 2. Panel Description Name Description HDMI OUT: Connects to the HDMI display ① DEVICE 4 USB 2.0 Ports for connecting KVM device. ② Connects to the HDBT OUT port of the transmitter by a CATx HDBT IN ③... -
Page 7: Specification
User Manual PT-HDBT-1020HU-RX 3. Specification Receiver Video Input (1)HDBT IN Input Connector (1) RJ45 Input Resolution Up to 4K@60Hz 4:4:4 Output (1) HDMI OUT Output Connector (1) Type-A female HDMI Output Resolution Up to 4K@60Hz 4:4:4 Control Control Part (4) DEVICE (4) DEVICE, Port 1&2 Type-A USB 2.0 5V500mA Power Supply... -
Page 8: System Diagram
User Manual PT-HDBT-1020HU-RX Storage Temperature -25 to +70℃(-13° to +158°F) Relative Humidity 10% to 90%, Non-condensing Power Supply Input:100V~240V AC; Output:24V DC 1.25A Power Consumption 13.8 W Dimension (W*H*D) 90 x 21.7 x 120 mm Net Weight 265g 4. System Diagram The following diagram illustrates typical input and output connections that can be utilized with the KVM extener. -
Page 9: After Sales Service
User Manual PT-HDBT-1020HU-RX 5. After-Sales Service If there appear some problems when running the product, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: This product will be free from defects in materials and workmanship for three years (The purchase invoice shall prevail). - Page 10 User Manual PT-HDBT-1020HU-RX...
-
Page 11: Asking For Assistance
User Manual PT-HDBT-1020HU-RX Asking for Assistance Technical Support: Phone: +49 5971 800299 - 0 Fax: +49 5971 800299 – 99 Technical Support Hours: 8:30 AM to 5:00 PM Monday thru Thursday 8:30 AM to 4:00 PM Friday Write to: PureLink GmbH Von-Liebig-Straße 10...
