Summary of Contents for TEGRAS Concept Grasmeter
- Page 1 Grasmeter / Elcometer Coating thickness gauge user manual...
- Page 2 We have all kinds of spare parts for your equipment, as well as related accessories. 941445056 This instruction manual is protected by copyright. We reserve all rights, especially the right of production, translation and processing with electronic systems. Grasmeter / Elcometer Coating thickness gauge...
- Page 3 4-29 your equipment 5-29 control panel 7-29 operating instructions 8-29 maintenance and care 23-29 waste management 24-29 technical specifications 25-29 technical specifications 26-29 warranty conditions 27-29 declaration of conformity Grasmeter / Elcometer Coating thickness gauge...
- Page 4 This symbol alerts you to a situation that may result in property damage without personal injury if you do not properly follow the instructions. IMPORTANT NOTE! This symbol alerts you to information regarding the optimal use of the equipment to avoid possible misuse. Grasmeter / Elcometer Coating thickness gauge...
- Page 5 Red (left), Green (right) - USB data transfer socket - Color Display (under the lid) - Battery compartment - Multifunction keys (1/4 turn for opening / closing) - On/Off button - Wrist strap attachment Grasmeter / Elcometer Coating thickness gauge...
-
Page 6: Contents Of The Box
Calibration gauges (gauges with integrated probe) > Wrist strap > Protective case > Carrying case > 1 x Screen protector > 2 x AA batteries > USB cable and ElcoMaster® software > Test certificate > Instructions for use Grasmeter / Elcometer Coating thickness gauge... -
Page 7: Control Panel
Bar Graph - Highest, lowest and average reading q Minimum limit activated r Measuring Mode - Standard, Auto Repeat, Scan, Auto Repeat s Graf Execution - last 20 readings t Maximum and minimum limits activated Grasmeter / Elcometer Coating thickness gauge... -
Page 8: Language Selection
2 Press and hold the left key and turn the meter on. 3 Select your language using the keys CONNECT THE PROBE 1 Rotate probe plug to align pins. 2 Screw in the probe - clockwise. Grasmeter / Elcometer Coating thickness gauge... -
Page 9: Take A Reading
Menu/Settings/Display Settings/Display Off Time. Wake up the meter either by pressing any key or with a short tap. • The meter will automatically turn off after 5 minutes of inactivity. • The meter indicates readings outside the range of the probe. Grasmeter / Elcometer Coating thickness gauge... - Page 10 3 Use your caliper to take a reading at each of the holes in the template and save all these readings in a batch. 4 Remove the template and clean the duct surface within the limits of the corner marks. Grasmeter / Elcometer Coating thickness gauge...
-
Page 11: Calibrate The Meter
3 Select Calibrate and follow the instructions on the screen. 4 When indicated, place the probe at the center of the gauges. Up to 4 sheets can be combined to create a wider range of thickness values. Grasmeter / Elcometer Coating thickness gauge... - Page 12 • If the user forgets or misplaces the PIN code, it can be disabled via ElcoMaster®. Using the USB cable, simply connect the meter to a PC with ElcoMaster® version 2.0.33 or higher installed and select Edit/Remove Calibration PIN. Grasmeter / Elcometer Coating thickness gauge...
-
Page 13: Calibration Methods
Set the calibration method to Rough/ 2 point and the Mean Swedish calculated to 5 readings - in accordance with SS Standards. Set the calibration method to Zero Offset and Average calculated to 5 Australian readings - in accordance with AS Standards. Grasmeter / Elcometer Coating thickness gauge... -
Page 14: Measurement Modes
For example batch NewBatch_1 becomes NewBatch_2, NewBatch_3, etc. • Store each reading in memory or store the average of a predefined number of readings with the Counted Average function. Grasmeter / Elcometer Coating thickness gauge... - Page 15 1 Press the Batch key. 2 Select "New Batch" or "Open Existing Batch". 3 Press the Display key and select "Graf Readings Execution". • Red dots mean that a reading is outside the lot limits (if established). Grasmeter / Elcometer Coating thickness gauge...
- Page 16 1 Select the appropriate batch name from Batch/Review Batch. 2 Select "Batch Chart". • Red columns mean that a reading is outside the lot limits (if established). • Press the Zoom+ (maximize) key followed by to review individual readings as required. Grasmeter / Elcometer Coating thickness gauge...
-
Page 17: Menu Structure
MENU STRUCTURE Grasmeter / Elcometer Coating thickness gauge... - Page 18 3, iPad Air, iPad mini 2, iPad (3rd and 4th generations), iPad mini, iPad 2, and iPod touch (4th and 5th generations). To install, download via www.elcometer.com or the App Store and follow the on-screen instructions. Grasmeter / Elcometer Coating thickness gauge...
- Page 19 The user can use ElcoMaster® to upgrade the firmware to the latest version when available. ElcoMaster® will inform the user of any updates when the meter is connected to a PC with an Internet connection. Grasmeter / Elcometer Coating thickness gauge...
- Page 20 2. Click on the batch or batches you wish to download (hold down the Ctrl key to select multiple batches). 3. Click on the download button. 4. Select the folder where you want to download, then press OK to start the download. Grasmeter / Elcometer Coating thickness gauge...
- Page 21 Double-click on the batch or drag & drop to the Report. The report will be displayed and can be printed, converted to pdf or emailed - refer to the instructions included with the ElcoMaster™ 2.0 software for more information. Grasmeter / Elcometer Coating thickness gauge...
- Page 22 EXAMPLE OF A DUCT TANK REPORT Grasmeter / Elcometer Coating thickness gauge...
-
Page 23: Maintenance And Care
The antenna(s) used for this transmitter should not be located or used adjacent to another antenna or transmitter. Spare parts: TEINNOVA has spare parts for all parts of the equipment. Should you require any parts or consumables, please contact TEINNOVA Customer Service at +34 941 44 50 Grasmeter / Elcometer Coating thickness gauge... -
Page 24: Waste Management
Dispose of the materials in the appropriate container or go to the collection points in your area. Directive 2012/19/EU of 4 July 2012 on waste electrical and electronic equipment (WEEE). Grasmeter / Elcometer Coating thickness gauge... - Page 25 -10 to 50°C (14 to 122°F) Relative humidity 0 a 95% 141 x 73 x 37mm Dimensions (W x L x H) (5.55 x 2.87 x 1.46") Weight of the 161g (5.68oz) meter (batteries included) Grasmeter / Elcometer Coating thickness gauge...
- Page 26 In case of coverage, in paragraph 1). "TEINNOVA" may replace the product. Grasmeter / Elcometer Coating thickness gauge...
-
Page 27: Product Certificate
Logroño (La Rioja), Spain Phone: +34 941 44 50 56 Web: www.teinnova.net MODEL: GRASMETER TECAI INNOVA, S.L., with full responsibility, declares that the product complies with the following product standards or regulations. AS 2331.1.4, AS 3894.3-B, AS/NZS 1580.108.1, ASTM B 499, ASTM D 1186-B, ASTM D 1400, ASTM D 7091, ASTM E 376, ASTM G 12, BS 3900-C5-6B, BS 3900-C5-6A, BS 5411-11, BS 5411-3, BS 5599, DIN 50981, DIN 50984, ECCA T1, EN 13523-1, IMO MSC.215(82), IMO MSC.244 (83), ISO 1461, ISO 19840, ISO 2063,... - Page 28 This instruction manual is protected by copyright. We reserve all rights, especially the right of production, translation and processing with electronic systems.
- Page 29 teinnova.net...
