Niles IRR-4S Installation & Operating Manual

OPERATION
This manual contains instructions If the IRR-4S does not work, and
for the IRR-4S only. For specific the LED does not light at all:
information on the adjustment
1. Test the remote control(s) by
and operation of your Niles
operating the A/V equipment
Infrared system, please refer to
directly. Replace the batteries if
the instruction manual included
needed.
with your Niles Main System
Unit (IRP-2, IRP-6A, IRZ-6A). 2. Double check the cable con-
nections on all IRR-4S's and on
Operation of the IRR-4S is sim-
the Main System Unit. Look for
ple. Aim your hand-held remote
open, shorted or reversed wires.
at the IRR-4S. Your IR command
is instantly repeated to your A/V If the IRR-4S does not work, and
equipment. A green "flash-back" the LED remains solidly lit:
LED on the IRR-4S visually con-
1. Double check the cable con-
firms remote control operation.
nections on all IRR-4S's and on
the Main System Unit. Look for
Troubleshooting
shorted or reversed wires.
The "flash-back" LED on the front
2. Test for interference from the
of the IRR-4S is a useful trou-
following sources:
bleshooting aid.
• Reduce the amount of sunlight
The LED should light only when
in the area of the IRR-4S.
a remote command is being
received. • Turn off florescent, neon or
SPECIFICATIONS
IR System Mounting
Compatible with virtually all In-wall, fits into most 18 cubic. in.
brands of remotes using carrier single-gang electrical boxes at
frequencies between 26 and 60 least 2 3/4" deep, Standard-style
kHz wall plate
IR Receiving Range Wiring Requirements
Varies depending on remote Individual "home-runs" of
strength; 18-30' typical 2-conductor shielded cable, West
Penn D291 or equivalent
IR Receiving Angle
o
60 off-axis (horizontal and verti- Unit Dimensions
cal) at 18' 1 5/8" wide x 2 5/8" high
www.nilesaudio.com
Niles Audio Corporation
12331 SW 130 STREET MIAMI, FLORIDA 33186 TEL: (305) 238-4373 FAX: (305) 238-0185
© 1999 Niles Audio Corporation. All rights reserved. Because Niles constantly strives to improve the quality of its products, Niles reserves the
right to change product specifications without notice. Niles, the Niles logo and Blending High Fidelity and Architecture are registered trademarks
of Niles Audio Corporation. Printed in USA 5/95 DS00112A
halogen lights in the room.
• Turn off light dimmers, begin-
ning with those closest to the
IRR-4S.
Observe the IRR-4S LED while
performing all the tests. It is pos-
sible to have interference from
more than one source.
There are many methods for
reducing interference. Which
solution is best for you depends
on your situation. Contact Niles
Technical Support at 1-800-289-
4434 if you require further assis-
tance.
If the LED on the IRR-4S "flickers"
dimly, and the IRR-4S functions
normally, there is no cause for
concern.
Face Plate Dimensions
Standard wall plate; 2 3/4" wide
x 4 1/2" high
Depth Behind Plate
2 3/4"
®
I N S T A L L A T I O N
MODEL IRR-4S
WALL-MOUNT
INFRARED SENSOR
INTRODUCTION
The IRR- 4S is a wall-mount, equipment in another room, and
infrared sensor which uses a instantly "repeated" .
standard-style wall plate and is
The IRR-4S is compatible with all
designed for use with the Niles
current Niles infrared systems. It
Infrared Repeating and IR
may be used along with, or as an
Routing Systems.
alternative to, the Niles IRR-4D,
Installed in a remote room loca- SCW-UIR, TIR-1, MS-1, MS-2
tion, the IRR-4S receives the IR and CMS-3 IR sensors.
commands transmitted from your
The IRR-4S is just one of the three
existing hand-held remotes in
building blocks necessary to com-
that room. The commands are
plete a Niles IR repeating system:
carried via a small 2-conductor
shielded cable to your A/V
FEATURES & BENEFITS
The IRR-4S offers a number of • 100% factory tested for pickup
improvements over other in-wall range and angle.
IR sensors.
• Green "flash-back" L.E.D. visu-
• Universal system—compatible ally confirms remote control
with most brands of A/V equip- operation.
ment and remotes using carrier
• Simple 3-wire hookup.
frequencies 26 to 60 kHz.
• Removable connector simpli-
• Greater IR receiving range—18
fies installation.
to 30 feet of remote control
range instead of the typical 15 to • Mounting depth of 2 3/4" fits
25 (depending upon the remote into most standard 18 cubic.
control, actual range may vary). inch 1-gang electrical boxes.
B
L E N D I N G
A
A N D
& O P E R A T I O N G U I D E
• Main System Unit — Models
IRZ-6A, IRP-6A or IRP-2.
• IR Sensors — Models IRR-4S,
IRR-4D, SCW-UIR, TIR-1, MS-1,
MS-2 and CMS-3.
• IR Flashers — Models IRC-1,
IRC-2, IRW-1 and IRW-2.
An expansion unit, Model
XRP-6A, is available for IR
repeater systems used in more
than six rooms.
• Printed circuit board design
uses no hand wiring, assuring
high reliability.
• Ideal for both home and com-
mercial installations.
• Available colors: White, Bone,
Almond, or Black.
• Two year parts and labor
warranty.
• Proudly made in the USA.
