Specifications - Niles VCS50 Specification Sheet

Features and Specifications
VCS50
Color Stock Number
White FG01283
a
b
(a) Electrical Box
(b) Speaker Wire
(c) VCS50 Volume Control
(d) Decora-Style Insert
(e) Knob
(f) Device Screws (2 supplied)
Wiring the connectors
NILES AUDIO CORPORATION
©2006 Niles Audio Corporation. All Rights Reserved. Niles and the Niles logo are registered trademarks of Niles Audio Corporation. CS0012
Features
Power handling: 50 watts per channel RMS; 100 watts peak
■
10 step control, 42 dB maximum attenuation
■
Pop-free switching between all steps
■
Removable knob and Decora
■
Recommended for use with SMS-10 Impedance Matching System or Speaker Selection Systems
■

Specifications

Dimensions: 1-5/8" wide x 2-5/8" high x 2-9/16" deep (behind faceplate)
■
Requires 1-gang electrical box at least 2-3/4" deep
■
Power Handling: 50 W (RMS)/100 W (peak music power) per channel
■
Frequency Response: 20Hz to 20kHz ± 2dB
■
Minimum Speaker Load: 4 ohm
■
Wiring Requirements: 14 to 16 gauge, stranded-copper loudspeaker wire with two individual runs
■
of two-conductor wire, or one run of four-conductor wire
Warranty: Ten Years
d
e
c
f
Left
(Input)
To Speakers
(Output)
12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI – www.nilesaudio.com
snap-in color insert for quick and easy color changes
®
Receiver
VCS50
Right
(Input)
Wiring diagram shows
a Niles system with a
VCS50 volume control
