- Page 1 Display Cooler Operation Instructions iMT-100L Art. No.:251005 iMT-120Z iMT-160Z Art. No.:251006 Art. No.:251011 iMT-160L Art. No.:251008 Thank you for choosing and purchasing our product. Please carefully read the operation instructions before use for a correct application and satisfactory effect.
-
Page 2: Table Of Contents
Contents General Structure and Parts Handle and Erection Preparation and Power Supply Use and Caution Maintenance Trouble Shooting Principle of Refrigeration System Circuit Diagram Major Parameters... -
Page 3: General
General 1. Top brand fully enclosed compressor is used on the desk-top refrigerator. The refrigerant R600a is of an environmentally friendly agent. It features a rational configuration of refrigeration system with blower forced air cooling. The temperature is quite even inside the refrigerator. 2. -
Page 4: Structure And Parts
Structure and Parts Glass Door Rack The height of rack is adjustable. Take out the rack; Move the rack support to a suitable height; Put the rack on the Air Suction support. Never block the air suction. Air is sucked Air Outlet in and cold air is Never block the air... -
Page 5: Handle And Erection
Handle and Erection Handle with care Unplug the wall socket first. Never tilt it over 45 degree during handling. Dry place Always locate the refrigerator at a dry place. Sufficient space The distance from both sides and back of refrigerator to wall or other substance must not less than 10cm. The refrigeration capability might be decreased if its surround space is too small to circulate air. -
Page 6: Preparation And Power Supply
No hole making Never make hole on the refrigerator. Never install other matter on the refrigerator. Stable location Unpacking and locate the refrigerator on a flat and solid place. Preparation and Power Supply Exclusive power socket Normally, the power supply should be 220-240V, single phase AC with exclusive single phase three pin receptacle (250V 10A) and fuse (6A). -
Page 7: Use And Caution
Prevent from flammables and explosive Never put any flammable or explosive inside the refrigerator such as ether, gasoline, alcohol, adhesive and explosive. Never put dangerous product nearby the refrigerator. No spray To spray the flammables such as paint or coating nearby the refrigerator is not allowed, otherwise fire might be resulted. - Page 8 The main functions are:Temperature Display/Temperature Control/Manual, automatic defrost by burning off/Illumination Control/Value Storing/self Testing/parameter Locking Front Panel Operation Set temperature Press „set“ button, the set temperature is displayed. Press button to modify and store the displayed value. Press „set“ button to exit the adjustment and display the cold-room temperature. If no more button is pressed within 10 seconds, the cold-room temperature will be displayed.
-
Page 9: Maintenance
Maintenance Notice Often keep the refrigerator clean and periodical maintenance is necessary. Always unplug the socket before maintenance. Never use damaged plug or loose socket to prevent from electric shock or short circuit. Never flush the refrigerator. Never use alkali detergent, soap, gasoline, acetone or brush. Clean outside Dip soft cloth in neutral detergent(tableware detergent) to clean the outside of the refrigerator and then wipe it with dry soft cloth. -
Page 10: Principle Of Refrigeration System
Principle of Refrigeration System The principle of compression refrigeration consists of “compression”, “condensation”, “throttling” and “vaporization”. The compression is undertaken by compressor, the condensation is completed by condenser, the throttling valve is executed by capillary and the vaporization is implemented by evaporator. When the coolant is circulating in the closed refrigeration system, the compressor sucks coolant, which has absorbs heat in evaporator, the coolant becomes a high pressure and high temperature gas. - Page 11 Major Parameters iMT-100L iMT-120Z iMT-160Z iMT-160L Model Art. No. 251005 251006 251011 251008 Coolant and injection quantity R600a(45) R600a(65) R600a(70) R600a(70) for HYE125MHU(g) Kind of weather Refrigeration temperature(ºC) 0-12 Electric shock protection class Rated Voltage(V) 220-240~ Rated Frequency(Hz) Rated Current (A) for 1.53...
