BOAT10PCO.
2018 MONSTER TOWER
FRONT OF
TOWER
50.8mm /
1) MEASURE 2" (50,8 mm) UP FROM WELD ON TOP SIDE FOR CENTER OF MAIN BOW
MOUNT. PLACE MOUNT 50 IT SWIVELS TOWARDS INSIDE OF BOAT. ATTACH WITH
SELF TAPPING SCREWS.
MEASURE 11" (279,4mm) OUT FROM CENTER OF BRACE BAR FOR CENTER OF
2)
SUPPORT POLE MOUNT. PLACE MOUNT ON FRONT OF BAR 50 THAT MOUNT SWIVELS
DOWN. ATTACH WITH SELF T APPING SCREWS.
HARDWARE PACKAGED
200614 - 4 - UNIVERSAL 90
101180 - 4 - BLACK TWIST KNO BS
100391 - 8 - #8 X 1" PHIL FLAT TEK SCREWS
Monster Tower
TOWER BIMINI TOP
MOUNTING INSTRUCTIONS
SMALL: 76" - 82" / 193-208cm
HS-1
MEDIUM: 83" - 88" / 210-224cm
LARGE: 89" - 96" / 226-244cm
279,4 mm
BRACE BAR
°
SWIVEL MOUNTS
MTHS1 SM NN1-3T0AA
MTHS1 MEDNN1-3T0AA
MTHS1 LG NN1-3T0AA
279,4 mm
50.8mm /
4/4/17
5/3/17
