Installation Instructions
It is critical to lightly lubricate bolt threads with included Anti-Seize
before installing Nylock Nuts to prevent the precision stainless steel
hardware from galling and locking, even if you are test-fitting parts together
Leave Legs and Top Section protected with bubble wrap sleeves, removing
only the ends as needed, to protect the boat and tower during installation.
THANK YOU FOR YOUR BUSINESS. IF YOU ARE NOT COMPLETELY SATISFIED
IN ANY WAY WITH YOUR NEW MONSTER TOWER, PLEASE CONTACT US
IMMEDIATELY. Our entire purpose as a company is to create great products at
affordable prices that our customers love.
Please take a few minutes to read the installation instructions and become
familiar with the Monster Tower parts and installation before beginning to ensure
a high quality, trouble free installation. If you have any questions during your
installation give us a call at 877-77-Tower or e-mail Support@MonsterTower.com
Reference 09Aug2014 – V16
And Owners Manual
MT1
Monster Tower, Inc.
5714 US Hwy 411 S
Maryville, TN 37801
Phone: 877-77-Tower or 865-934-1290
Fax: 877-232-6538 or 770-234-3833
www.MonsterTower.com
Support@MonsterTower.com
Reference 9August2014 – V16
before installation.
IMPORTANT
Pg
1 of 12
Copyright 2002-2014, Monster Tower, Inc.
Advertisement
Related Manuals for monster tower MT1
Summary of Contents for monster tower MT1
- Page 1 IMPORTANT Please take a few minutes to read the installation instructions and become familiar with the Monster Tower parts and installation before beginning to ensure a high quality, trouble free installation. If you have any questions during your installation give us a call at 877-77-Tower or e-mail Support@MonsterTower.com Reference 09Aug2014 –...
- Page 2 If you chip or scratch your black or white powder coated tower, use Rustoleum Non-Aerosol Gloss Black/White paint with an Art-kit brush to touch up the affected areas. Reference 09Aug2014 – V16 2 of 12 Copyright 2002-2014, Monster Tower, Inc.
- Page 3 The unique Base Assembly of the Monster Tower includes: a base fastened to the boat, and a base swivel that allows the base to mount on the top, Reference 09Aug2014 –...
- Page 4 (side to side) movement of the tower from causing stress to the boat. You are now an expert on the Parts of the Monster Tower and we will use the terminology of the Parts List throughout this document. Note that Parts refer to components of the tower and Items refer to hardware, tools and accessories.
- Page 5 Do Not Loosen these set screws when folding the tower. NOTE – If you plan to purchase the Monster Tower Bimini, it mounts to the rear legs of the tower. If the tower is mounted too far back, the driver will not be covered by shade.
- Page 6 The front bases are 40” to 70” apart from the rear bases. The optimal range is from 48” to 60” although it is acceptable to mount them from 40” to 70” apart. The following Reference 09Aug2014 – V16 6 of 12 Copyright 2002-2014, Monster Tower, Inc.
- Page 7 The masking tape makes it easy to accurately mark the holes. To make drilling easier we recommend center punching the marks so the drill bit does not wander when drilling. Reference 09Aug2014 – V16 7 of 12 Copyright 2002-2014, Monster Tower, Inc.
- Page 8 Tighten these by hand; do not use a drill or driver. There is not a specific torque specification since each boat is different. Tighten until you begin to see Reference 09Aug2014 – V16 8 of 12 Copyright 2002-2014, Monster Tower, Inc.
- Page 9 M12x85 bolt (Item 2) on the outside of the base as shown here. The tower installation is almost complete and the last step provides the final adjustments to ensure a stiff tower that is custom fit to your boat. Reference 09Aug2014 – V16 9 of 12 Copyright 2002-2014, Monster Tower, Inc.
- Page 10 The tower is now centered and locked into position. All four anchor bolts MUST be installed. Reference 09Aug2014 – V16 10 of 12 Copyright 2002-2014, Monster Tower, Inc.
- Page 11 Using your Monster Tower – Operating Instructions The Monster Tower folds down flat to fit under your boat cover fast and easy. To fold the tower down remove the Quick Release bolts from the front bases. The Heim joints now allow the tower to pivot towards the back of the boat.
- Page 12 Monster Tower, Inc. - 5 Year Warranty - Monster Tower warrants that for a period of 5 years from the date the tower is sold at retail, that Monster Tower will repair directly, or supply parts for the repair of any material cracks, fractures or structural failures that are a result of a manufacturing defect.
