I N S T R U C T I O N M A N U A L
E X T R A C T I O N
P E R M A
www.geovent.com
Version 1.0
27.09.2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXTRACTION PERMA and is the answer not in the manual?

Questions and answers

Related Manuals for Geovent EXTRACTION PERMA

Summary of Contents for Geovent EXTRACTION PERMA

  • Page 1 I N S T R U C T I O N M A N U A L E X T R A C T I O N P E R M A www.geovent.com Version 1.0 27.09.2022...

  • Page 3: Table Of Contents

    Do not modify the product or use spare parts from other The manual is relevant for people involved in transpor- suppliers than Geovent, as this may hamper the product tation, stocking, installation, using, maintaining and all and the function.

  • Page 4: Machine Overview

    3.2 Intended use Example: PERMA arm ø57 ESD, 580 mm 2 joint The 580 mm is from center joint to center joint. Geovent offers a new extraction arm, PERMA. PERMA arm is good for use in laboratories, hospitals, 260 mm...

  • Page 5: Assembly, Installation And Start Of Operation

    Tighten the arm joint, so that the arm can hold itself. Mounting of optional equipment Geovent offers a great range of accessories for the PERMA arm: Round hood, extraction pen, flat hood, Typisk montagehøjde er 2100 til 2300 mm over aluminium hood.

  • Page 6: Commissioning

    The arm is only intended to support the weight of the arm. Geovent has made it easy to replace equipment on the PERMA arm. When you need to change a hood or a flat hood, screw off existing hood or extraction pen and mount the new hood.

  • Page 7: Dimensions

    Wear on parts such as filter cartridges and hose is not included in the warranty. User liability In order for Geovent to be capable of granting the decla- red warranty, the user/fitter must follow this instruction manual in all respects.

  • Page 8: Spare Part List

    14.0 Spare part list 14.0 Spare part list Art. No. Description 10-325 Suction Pen L:350 mm, ALU, ø57 10-520 Table spring for 1490 mm PERMA arm 10-423 Suction Pen L:350 mm, ALU, ø76 10-521 Wall spring for 1490 mm PERMA arm 10-368 Suction Pen L:350 mm, ALU, ESD ø57 10-525...
  • Page 9 14.0 Spare part list Hood, ø380 mm, painted polycarbona- 10-470 te, ESD, ø76 Hood, ø280 mm, painted polycarbona- 10-374A te, ESD, ø57 Hood, ø280 mm, painted polycarbona- 10-470A te, ESD, ø76 Hood conical, ø250 mm, painted polyc- 10-375 arbonat, ESD, ø57 Hood conical, ø250 mm, painted polyc- 10-471 arbonat, ESD, ø76...
