- Page 3 Instructions for Setup Please follow these instructions carefully. For setup, you will need a Phillip’s head screwdriver. Ex21 The top piece and the bottom piece look similar. The bottom piece has holes close to the edge on EACH side of the bottom. The top piece only has holes on THREE of the four sides.
- Page 4 Select the side piece with no opening. The side piece has a frame. Install the side piece with the hole on the bottom. Select the side piece with the outer opening. The piece with the outer opening has a frame around the opening.
- Page 5 For ease of assembly carefully turn the box upside down before performing this step. After carefully turning the box upside down, install the bottom piece to the box. Screw the Part A screws into the bottom of the box. Note: the two front corners of the bottom piece have rounded edges, the back do not.
- Page 6 First, install the side hinges - part H. Find the side of the hinge that is shaped like a right angle. Put this part of the hinge with the right angle into the grooves in the back piece of box. (Refer to image for correct positioning) Use screws E to attach the hinges to the back piece.
- Page 7 Distributed by Designer Pet Products, Inc - Pembroke, MA 02359 Copyright 2019 Designer Pet Products, Inc- All rights reserved United State Patent No: US D616,617 S...
