Digital 30-Minute Timer
Electronic Interval Timer for MrSteam CU Commercial Steambaths
Installation and Operating Manual
FUNCTIONALITY OF THE TIMESWITCH
During the preset running time, the timer energizes and activates the connected steam solenoid by closing a
circuit. After the time has elapsed, the timer deenergizes and deactivates the connected steam solenoid by
opening the circuit again. THE TIMER MAY ONLY BE OPERATED AFTER INSTALLATION IN A
PROTECTIVE HOUSING.
Installation, Operation and Maintenance Manual
BEFORE USE
Before installing and using this timer, it is absolutely nec-essary that you read this operating manual thoroughly.
This timer may only be installed by a qualified, licensed electrician and must be installed in accordance with
National and local codes.
SHOCK HAZARD! Install the timer per these
instructions before connecting to the main supply. Never touch
live contacts or components.
Protection from contact with the line voltage
components must be achieved by proper installation in a 2 x 4
junction box. When installing the timer, ensure the fastening
sliders prevent the timer from being removed.
DO NOT install the timer in a wet or damp location.
DO NOT install the timer inside the steam room.
____________________
MP
O
_
IMPORTANT NOTE: As you follow these instructions, you will notice
warning and caution symbols. This information is important for the safe
and efficient installation and operation of this generator. These are types
of potential hazards that may occur during this installation and operation:
