Summary of Contents for FREAKELECS breakElecs DH-CT3
- Page 1 DH-CT3 U S E R G U I D E F R E A K E L E C S...
- Page 2 Box Contents Fingerprint panel Metal gasket for fingerprint sensor panel Interior mechanical cylinder lock panel Upper panel (Lock Catch) Screws...
- Page 3 Lock Technical Specs Round hole of diameter 19mm Interior mechanical lock panel Metal gasket for sensor panel Fingerprint panel...
- Page 4 Lock Installation Fix the fingerprint panel and the metal gasket in proper place with two large silver screws (cabinet side / upper edge, upper edge of drawer) as shown in the figure below. Drill a 19 mm diameter round hole in the proper position on the outside board of the drawer/cabinet and then put the fingerprint panel in the hole.
- Page 5 Admin Fingerprint Registration Press and hold for 5 seconds until the blue light flashes, then remove. When the steady blue light is turned on, start registering the fingerprint by releasing and pressing the finger repeatedly. Once the green light turns on the fingerprint registration is successful.
- Page 6 Delete Fingerprint(s) Note: Deletion of the fingerprint means that all fingerprints can be deleted, instead of deleting certain fingerprint record separately. Press the fingerprint lock panel and hold for 10 seconds until the red light flashes (however blue light flashes first during this period) ,release the finger.
- Page 7 Scan the QR Code to watch the demo video. C/O. MoonWalker Workafella Sholinganallur, Rattha Group, Level 4, Tower A, TEK Meadows, No 51, OMR, Sholinganallur, Chennai, Tamil Nadu 600119 Contact # +91- 94451 04400 Email Address: support@freakelecs.com...
