- Page 1 INSTALLATION AND OPERATION MANUAL HH-S91918SS / HH-S91918BK / HH-S61918BK SLIM HOOD...
-
Page 2: Table Of Contents
Model: HH-S91918SS / HH-S91918BK / HH-S61918BK SLIM HOOD CONTENT PAGE SAFETY PRECAUTIONS ..................3 SPECIFICATIONS ....................5 INSTALLATION ....................7 OPERATION ....................... 9 MAINTENANCE AND CARE ................10 TROUBLE-SHOOTING ..................11 To all, please provide this manual to the user without fail. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS When unpacking ● Do not use the appliance if there are obvious signs of transportation damage. ● If the supply cord has been damaged, it must be replaced by the manufacturer, its service agents or qualified personnel in order to avoid a hazard. Please contact us in an event like this. Installation ●... - Page 4 SAFETY PRECAUTIONS Usage ● This hood is designed for domestic kitchen use to eliminate unpleasant odours from the kitchen. Do not use or install this hood for any other uses than its specific purpose. ● This appliance can be used by children aged 8 years and above and also persons with reduced physical, sensory or mental capabilities if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
-
Page 5: Specifications
SPECIFICATIONS Model: HH-S61918BK Power Rating: 153W Voltage: 220-240V~ Power Frequency: 50Hz Power of Motors: 2 x 75W Power of Lamps: 2 x 1.5W Length of the cable: Appliance Dimensions: 100 x 596 x 500 mm Net Weight: 4.9 KGS *The manufacturer reserves the right to effect any technological improvement or modification without prior notice. - Page 6 SPECIFICATIONS HH-S91918BK | HH-S91918SS HH-S61918BK Product Parts Product Parts Non return flap Non return flap Air outlet cover Air outlet cover Hood body Hood body Charcoal filter CP120 Charcoal filter CP120 Aluminum grease filter Aluminum grease filter Installation Accessories Installation Accessories...
-
Page 7: Installation
INSTALLATION This appliance can be installed in recirculation or ventilation mode. Ducted Mode Recirculation Mode The cooker hood fan extracts the cooking The cooker hood fan extracts the cooking vapours vapours and passes them to the outside. In this which are purified in the grease filter and charcoal mode, only grease filters are installed (charcoal filter. - Page 8 INSTALLATION Step 2 Step 2 a. Mount the cooker hood onto the tightened a. Put the one-way valve on the cooker hood. screws. b. Align the cooker hood with the holes and fix b. Fix the cooker hood with safety screws position by screwing in with 4pcs of the positioned on the back casing with a 6mm provided ST4*25 screws.
-
Page 9: Operation
OPERATION This appliance is equipped with 3 speed controls. Function controls of the cooker hood can be found below. To achieve better air extraction, it is advisable to switch on the cooker hood a few minutes before starting to cook and to leave it on for approximately 15 minutes after cooking (or at least until all cooking smell is completely removed). -
Page 10: Maintenance And Care
● Replace the light and reconnect the terminal. ● Press the light back into cavity and place back grease filters. ● Please reach out to the Hilde Service Care Team for LED light replacement if you face any difficulties. Note: The manufacturer will not be held liable for any damages resulting from improper installation nor failure to adopt proper safety measures during installation and operational use of the appliance. -
Page 11: Trouble-Shooting
If problems still persist after the checks, please reach out to Hilde Service Care Team for further assistance. - Page 12 The Company reserves the right to change the information of this installation and operation manual at any time without prior notice. In the event that any changes are made, the revised information shall be posted on www.hilde.com.sg immediately. Please check the latest information posted herein to inform yourself of any changes.
