35010999 ver.02 1-01
TeraStation
a
4 post rack mounting bracket (inner) ............ 2
b
4 post rack mounting bracket (outer) ............ 2
c
2 post rack mounting bracket ........................ 2
1
Are the holes in your rack round or square?
A
2-A
Round Holes (2 post)
1
Attach brackets c to the TeraStation with screws
e.
c
e
Phillips screwdriver.
Rack Installation
Rack Installation
Included Parts
Installation
B
e
c
d
hand screw.................. 6
e
M4 screw..................... 4
f
M5 screw..................... 4
g
inch screw................... 4
h
cage nut...................... 4
Next Page
2
Attach the TeraStation to the rack with screws f
or g.
f
g
or
Installation is now complete.
f
g
or
