13/30
HERITAGE TRACTOR
CODE 131E
INSTRUCTION BOOK
CODE SERIAL NO.
PART NO: 111-1012 (rev.A.)
131E
270000001
ISSUE 01/22/07
1740520

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 131E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hayter 131E

  • Page 1 13/30 HERITAGE TRACTOR CODE 131E INSTRUCTION BOOK CODE SERIAL NO. PART NO: 111-1012 (rev.A.) 131E 270000001 ISSUE 01/22/07 1740520...
  • Page 2: Danger: No Step

    5 (30x49) 4 (17x195) 7 (17x192) 5 (1001054) 4 (17x47) 7 (14x79) 4 (25x3) 6 (2x82) 6 (17x146) 6 (2x82) 6 (1x121) 7 (15x116) 6 (1x121) 6 (1x121) 7 (15x116) 6 (1x121) 7 (15x116) 1740520...
  • Page 3: Danger: Keep Feet And Hands Away From Rotating Blade

    1740520...
  • Page 4: Declared Airborne Sound Power Level Of 100

    1740520...
  • Page 5: Db(A) Is In Accordance With Directive 2000/14/Ec

    1740520...
  • Page 6: Danger: Disconnect Spark Plug Wire

    1740520...
  • Page 7: Warning: Hot Surface

    1740520...
  • Page 8: Warning: Maximum Loading When Using

    1740520...
  • Page 9: Warning: Crushed Fingers

    150N 30x49 2x82 14x79 15x116 25x3 20729 1x121 17x146 17x195 1001054 17x192 17x47 1740520...
  • Page 10: Limited Warranty

    LIMITED WARRANTY Hayter Limited warrants to the original user / purchaser that this unit shall be free from defects in material and workmanship under normal use and service for a period of three years from the date of purchase. The manufac- turers of the engine and battery pack system (where applicable) furnish their own warranty and services are pro- vided through their authorised network (Refer to “Engine/Battery Pack Warranty Statement”).
  • Page 11: Table Of Contents

    13/30 Values determined with operator in operating position when the machine was operated stationary on a concrete surface at 2850 min- -1. 2850 131E 270000001 Declared airborne noise emissions in accordance with Directive 2000/14/EC, Annex VI. Sound Pressure Level at operator position 86 dB.
  • Page 12: Owner's Information

    OWNER’S INFORMATION Thoroughly inspect the area where the nor allow anyone near the machine while in equipment is to be used and remove all ob- operation. jects which may be thrown by the machine. Know your product: If you understand the unit 10.
  • Page 13: Assembly

    ASSEMBLY How To Assemble The Steering Wheel How To Charge The Battery (Figure 4) (Figure 3) WARNING: When you charge the All fasteners are in the parts bag. Do not discard 1. Make sure the front wheels point forward. battery, do not smoke. Keep the bat- any parts or material until the unit is assembled.
  • Page 14: Operation

    OPERATION 4. Before you ride the unit across a sidewalk or 4. Set the parking brake (6). a road, move the blade rotation control (1) WARNING: Make sure the parking to the DISENGAGE position. NOTE: Illustrations and pictorials begin on brake will hold the unit.
  • Page 15: Maintenance

    Before Starting The Engine 3. To start again, make sure the shift lever is in 6. Slowly move the throttle control to the SLOW the slowest speed. Move the throttle control position. to the SLOW position. Slowly release the 7. To start a hot engine, move the throttle con- Check the oil pedal.
  • Page 16 To Remove 5. Check the blade (1) and the blade adapter 9. (Figure 22) Check the operation of the blade (5) according to the instructions for “Inspect brake. Rotate the mandrel pulley (5) with 1. Move the blade rotation control to the DIS- your hand.
  • Page 17 How To Charge The Battery (Figure 4) 3. Disconnect the adjustable nut (4) from the NOTE: Apply grease to the steering gear as- brake lever assembly (5) and the parking sembly. WARNING: When you charge the brake latch (6). CAUTION: If the unit is operated in dry areas battery, do not smoke.
  • Page 18 If you are unable to obtain parts or service in the and “B”. manner outlined above, then contact: 5. Disconnect the extension spring (5) from HAYTER LIMITED, Service Department, the blade control rod (6). See illustration Spellbrook, Bishop’s Stortford, Hertfordshire “E”.
  • Page 19: Trouble Shooting Chart

    TROUBLE SHOOTING CHART 3. Clean the air filter. 7. Clean the extension tube and the connector tube (applies only to model with rear dis- 4. Replace the fuel filter. charge grass bag). PROBLEM: The engine will not start. PROBLEM: The engine stops when the PROBLEM: The mower housing does 1.
  • Page 20 1740520...
