BioFicient 1-3 INSTALLATION MANUAL HEALTH AND SAFETY You must read these warnings carefully before installing or using the equipment. Should the equipment be transferred to a new owner, always ensure that all relevant documents are supplied. Observe all hazard labels and take appropriate action to avoid exposure to the risks indicated.
BioFicient 1-3 INSTALLATION MANUAL SELF HELP In order to minimize the need for dealing with emergency situations we recommend that Treatment Plants have a Pre-service Agreement Inspection, and then is regularly serviced by us or an approved Service Engineers. Provided that your plant is installed, operated correctly and serviced, you should not need to get into much –...
BioFicient 1-3 INSTALLATION MANUAL SYSTEM OVERVIEW Pictorial representation below indicates basic requirements for a standard system, please note not all of the items required are supplied by Kingspan.
BioFicient 1-3 INSTALLATION MANUAL BioFicient® CHECKLIST The delivery paperwork will have 3 no. items listed; check that the Tank Code (Item 1) & Blower Assembly Code (Item 2) are the same as the codes on the units delivered. Example; Top Level Product Code – BFP1GPPK Item 1 –...
Page 9
BioFicient 1-3 INSTALLATION MANUAL 4. BACKFILL AND LEVEL 1. Pour 300 mm of water into the tank, 2. Backfill with pea gravel or similar. Pea gravel is reliant on use of correct strapping and anchoring. Wet site: Make sure the base is adequate to support the weight of the tank and its contents.
BioFicient 1-3 INSTALLATION MANUAL 7. VENTING To be vented locally at the plant CONTROL PANEL INSTALLATION Fuse 5 A Discharge pump Fuse 3,15 A Motor drive Discharge Pump/ Solenoid Valve Blower High water level Remote beacon Phase (red) Phase (red) detector.
Page 11
BioFicient 1-3 INSTALLATION MANUAL BioFicient® IPS HLA 1. Remove the loose float located in the blower housing. 2. Thread the float cable through the gland in the HLA bracket fixed to the Final Settlement Tank in the plant. 3. Position bottom of the float 200mm from top of the FST and tighten gland to secure the float cable. HLA Bracket Final Settlement Tank...
Page 12
BioFicient 1-3 INSTALLATION MANUAL CONTROL PANEL ENTRY POINTS DEPENDING ON THE EQUIPMENT SUPPLY 1 - Pumped discharge only 2 - See Fig.1 below Feed through Gland Hole Product Required Gland Terminate to connection number Mains power supply Integral discharge pump power cable 1&2 Sludge Return Solenoid Cable 1&2...
Page 13
BioFicient 1-3 INSTALLATION MANUAL FAULT CODES AND FUSES CODE FAULT CONDITION FUSE No power to the unit Customer Fuse box The blower pressure has failed The high level alarm has activated (where fitted) The fuse to the motor has failed 3.15 The fuse to the discharge pump has failed (where fitted) The fuse to the chemical dosing pump has failed (where fitted)
BioFicient 1-3 INSTALLATION MANUAL START UP Once the unit has been We recommend that installed it should be left the unit has a Pre-Service filled with water. Agreement Inspection by an approved engineer. NOTES...
