- Page 1 E-Lumen X SERIES TOPAZ Installation and Operation manual USER MANUAL EMLI22030741...
-
Page 2: Table Of Contents
TABLE OF CONTENT 1. IMPORTANT SAFETY AND INSTALLATION ..INSTRUCTIONS 2. PRODUCT INTRODUCTION ..2.1 BASIC ON/OFF MODE 2.2 COLORTOUCH MODE 3. LIGHT SPECIFICATION ..3.1 ELECTRICAL 3.2 DIMENSIONS 3.3 COLOR MODE 4. INSTALLATION ..4.1 WIRING DIAGRAM 5. LAMP INSTALLATION .. -
Page 3: Important Safety And Installation Instructions
1. IMPORTANT SAFETY AND INSTALLATION INSTRUCTIONS Please read the manual carefully before commencing installation. This manual contains important information about the correct installation and operation of TOPAZ lights. 1. Only qualified electrician is allowed to carry out the installation of this product. 2. -
Page 4: Basic On/Off Mode
2.1 BASIC ON/OFF MODE When the light is connected to the transformer directly, to on/off the main switch to controls the color changes. 220-240Vac 220-240Vac 220-240Vac to 12Vac to 12Vac to 12Vac Transformer Transformer Transformer 2.2 COLORTOUCH MODE It need to cooperate with Color Touch Control Box to pick up color directly and adjust brightness. -
Page 5: Light Specification
3. LIGHT SPECIFICATION 3.1 ELECTRICAL Operation Voltage Range: AC12V (COS : 0.8 ,MAX 1.0A) LED Color: RGB + Warm White (3000K) and Cool White (6500K) Operation Frequency: 50/60Hz Max Power Rating: 13W Mode of operation: ON/OFF Mode or ColorTouch control box There are three different installation types for TOPAZ lamp: TOP13-C Concrete Pool... -
Page 6: Color Mode
3.2.4 Light Intensive chart 7.00m 6.00m 5.00m 4.00m 3.00m 2.00m 1.00m 0.00m TOPAZ 3.3 COLOR MODE Mode Mode Cool White Mode C: Blue+Gradual Green Green Mode D: RGB Color Sequence Blue Mode E: RGB Color Sequence Green+Blue Mode F: Auto Color Change Red+Green Mode G: RGB Color Sequence Red+Green+Blue... -
Page 7: Wiring Diagram
4.1 WIRING DIAGRAM ColorTouch Control Box PCB AC Mains Zone 1 Power cord Power cord Zone 2 Power cord Basic ON/OFF Model wiring ColorTouch Mode 5. LAMP INSTALLATION 5.1 TOP13-C CONCRETE POOL Typical vertical and horizontal concrete pool installation layout is illustrated as below diagram for reference. - Page 8 Break Conduits Junction Box Above Waterline Water Line Transformer 27mm Hosepipe Sealant Pool Finish 20mm( MAX) Soil 10mm(MIN) 50mm 68mm(MAX) Minimum 50mm(MIN) Concrete 125mm(standard) Coverage Concrete Reinforcing Concrete Bars Thickness Installation Step: 1. Mounting the niche on steel reinforced bar. Vertical PVC Conduit Horizontal PVC Conduit D20 PVC Conduit...
- Page 9 2. The niche and the concrete wall should be seal 3. Lead the power cord with connector through with sealant to prevent water get inside. the niche Steel Reinforce Bar Sealant 125mm Cable And Screw Nut 4. Insert the clamp ring into the niche before ceramic is applied.
-
Page 10: Top13-Vl
7. Rotate the lamp on the fastener ring which 6. Screw the Fastener Ring on the clamp ring is auto locked 8. Apply a screw driver push to key hole to release the lamp . 5.2 TOP13-VL Break Conduits Break Conduits Above Waterline Junction Box Above Waterline... -
Page 11: Top13-Vs
5.3 TOP13-VS Break Conduits Break Conduits Above Waterline Above Waterline Junction Box Junction Box Transformer D20 PVC pipe Transformer Installation Step: 2. Insert the light niche through the opening 1. Opening Hole with plastic ring on both face side. O-ring TOP13-VS TOP13-VL LAMP INSTALLATION... - Page 12 4. lead the power cord with connector though 3. Screw the nut tight from inside the niche from the front side. 5. Warp the power cord few round. 6. Screw the connector to the lamp with face plate 8. Rotate the lamp on the fastener ring which is 7.
- Page 13 9. Apply a screw driver push to key hole to release the lamp. 5.4 TOP13-EM 1) TOP13-EM(Concrete Pool) 2) TOP13-EM(Concrete Pool with Conduit) Break Conduits Junction Box Break Conduits Above Waterline Junction Box Above Waterline Water Line Water Line PVC pipe PVC pipe 1.5"/GB50 PVC Pipe...
- Page 14 5) TOP13-EM(Panel Pool/Timber Pool) Break Conduits Above Waterline Junction Box Water Line Liner PVC pipe Rubber ring 1.5"/GB50 PVC Pipe Rubber ring Transformer G1.5A Screwthread ( EM2836 ) Installation Step: 1. Install EM2836/EM2831/EM2841 fitting. Opening Hole 60mm Concrete Pool Concrete Pool with Conduit Vinyl Pool Panel Pool Concrete Pool+Liner...
- Page 15 3. The cable through the fitting. 4. Screw light,Adjust the tightness by O-Ring,and “TOP” upwards. 6. MAINTENANCE OF THE LIGHTS 1. Do not leave the lights “on” above water for longer than 1 minute. 2. Before switching on the lights, check whether the lights are fully submerged underwater and the circuit boxes are running properly.
- Page 16 7. SPARE PART LIST TOP13-C Key No. Part No. Description 112010111 Screw M3*18.5(316) 440547998 15 LEDs Panel 13W Color Fastener Left 440647771 Fastener Right 440647772 112362743 M3*8 screw 316 15 LEDs Panel Suite 13W Color for TOP13-C(Composition of 2-1,2-2,2-3,2-4) E042705 Retro-fit Connector(For TOPAZ,with cable 2.5m) E042702 Cable 2.5m(For TOPAZ)
- Page 17 TOP13-VL / TOP13-VS Key No. Part No. Description 112010111 Screw M3*18.5(316) 15 LEDs Panel 13W Color 440547998 440647771 Fastener Left 440647772 Fastener Right 112362743 M3*8 screw 316 440517766 Face Plate E042701 15 LEDs Panel Suite 13W Color for TOP13-VL/VS(Composition of 1-1,1-2,1-3,1-4,1-5,1-6) E042702 Retro-fit Connector(For TOPAZ, with cable 2.5m) 105107997...
-
Page 18: Top13-Em
TOP13-EM Key No. Part No. Description E042708 15 LEDs Panel 13W Color TOP13-EM 111040072 O-Ring (vinyl pool/concrete pool) SPARE PART LIST... -
Page 19: Terms Of The Warranty
8. TERMS OF THE WARRANTY As original purchaser of this equipment have purchased from the manufacturer, through Authorized International Distributor or Dealer, warrants its products free from defects in materials and workmanship under normal use during warranty period. The warranty period begins on the day of purchase and extends only to the original purchaser. - Page 20 EMAUX WATER TECHNOLOGY CO., LTD ADDRESS FLAT A-D, 20/F., KAI BO 22, 22 WING KIN ROAD, KWAI CHUNG, HONG KONG PHONE +852 2832 9880 STRIVE FOR CLEAR WATER...
