Summary of Contents for Apriva BT200-T
- Page 1 Apriva BT200-T ® Smart Card Reader for Intermec ® CK61B/G Installation and User’s Guide Apriva 6900 East Camelback Road Suite 700 | Scottsdale AZ 85251...
- Page 2 Apriva BT200-T Smart Card Reader ® for Intermec CK61B/G ® Installation and User’s Guide Part number 700013-01 September 2010 Apriva 6900 East Camelback Road Suite 700 | Scottsdale AZ 85251...
- Page 3 CK61B/G Installation and User’s Guide Notice Terms and Conditions This publication is proprietary of Apriva and is intended solely for use by Apriva customers. This publication may not be reproduced or distributed for any purpose without the written permission of Apriva.
- Page 4 Intermec CK61B/G or other approved ancillary or peripheral equipment. Finally, Apriva will have no obligations hereunder where it is determined by Apriva that there is no defect in the Product itself. To obtain warranty service, Purchaser must return the Product to Apriva at the address below, transportation and insurance pre-paid.
-
Page 5: Table Of Contents
® ® Apriva BT200-T Smart Card Reader for Intermec CK61B/G Installation and User’s Guide Contents Introduction ......................1 Definitions ......................1 Hardware and Software Requirements ..............2 Hardware Required ..................2 Software and Firmware Required ..............2 Apriva BT200-T Reader ..................3 Apriva Reader Features .................. - Page 6 Adding a Soft-Token Certificate ..............23 Viewing All Certificates ................. 24 Apriva Guard ..................... 25 Downloading the Apriva Guard Software ............25 Installing the Apriva Guard Software on the Mobile Device ......... 27 Apriva Vault ....................... 28 Support ......................29 Apriva Technical Support ..................29 Technical Support Contact Information ............
- Page 7 CK61B/G Installation and User’s Guide Figures Figure 1 – Apriva Reader features ................ 3 Figure 2 – Apriva Reader driver and firmware files ..........5 Figure 3 – Intermec Version Information screen ........... 6 Figure 4 – Reader Connection area ..............7 Figure 5 –...
-
Page 8: Introduction
Table 1 shows product terms and definitions used in this guide. Term Definition Apriva Smart Card Reader Apriva device for allowing an interface between a mobile device and a smart card. Intermec CK61B/G mobile Mobile device designed and supported by Intermec device Technologies Corporation. -
Page 9: Hardware And Software Requirements
® ® Apriva BT200-T Smart Card Reader for Intermec CK61B/G Installation and User’s Guide Hardware and Software Requirements The following sections describe hardware and software requirements. Hardware Required The following hardware is required: • Intermec CK61B/G barcode scanner with cradle •... -
Page 10: Apriva Bt200-T Reader
CK61B/G Installation and User’s Guide Apriva BT200-T Reader The Apriva BT200-T Reader uses a hardware security module with embedded public key infrastructure (PKI) information to create a secure, one-to-one connection with the mobile device through wireless Bluetooth protocol or a Universal Serial Bus (USB) connection. -
Page 11: Powering On The Reader
Charging a Completely Discharged Reader Battery on page 15. Installing the Reader Driver on the Mobile Device You must install the Apriva Reader driver on the mobile device before you can pair the devices. See Pairing the Devices on page 7. -
Page 12: Figure 2 - Apriva Reader Driver And Firmware Files
BT200-T Smart Card Reader for Intermec CK61B/G Installation and User’s Guide 4. Copy and paste the Apriva reader firmware and driver files from the computer to the following directory of the mobile device: Start > File Explorer > My Documents, as shown in Figure 2. The Apriva Reader file names are similar to the following: •... -
Page 13: Checking The Intermec Sspd And Firmware Versions
® ® Apriva BT200-T Smart Card Reader for Intermec CK61B/G Installation and User’s Guide Checking the Intermec SSPD and Firmware Versions Before you pair the reader to the mobile device, make sure the Intermec firmware and SmartSystems Platform Bundle (SSPD) are the latest versions available. -
Page 14: Pairing The Devices
4. From the mobile device applications menu, select the Apriva Reader icon ( ). The Apriva Smart Card Reader screen appears. See Figure 4. If you do not see the Apriva Reader icon, you might need to reinstall the software. See Installing the Reader Driver on the Mobile Device page 4. - Page 15 3. o Make sure that the reader battery is charged. See Charging the Reader Battery on page 10. Contact Apriva Support if the problem persists. See Apriva Technical Support on page 29. © Copyright 2010 Apriva Page 8...
-
Page 16: Using Tethered Usb Mode
2. Make sure the smart card is inserted in the reader, and then press the ON/OFF switch to power on the reader. 3. From the mobile device applications menu, select the Apriva Reader icon ( ). The Apriva Smart Card Reader screen appears. -
Page 17: Charging The Reader Battery
11. NOTICE If you are charging the battery with a computer that uses Windows XP, you must first install the Apriva USB driver. Failure to do so could drain the reader battery. See Installing the Reader USB Driver on page 11. -
Page 18: Charging Indications
Apriva USB driver. To install the USB driver and recharge the reader: 1. Download the USB driver from the Apriva downloads website. For driver download information, see Apriva Technical Support on page 29. -
Page 19: Setting The Reader Power Down Timers
(No Card) or when the smart card is inserted (Card Present). To change the Power Down Timer settings: 1. From the mobile device applications menu, select the Apriva Reader icon ( ). The Apriva Smart Card Reader screen appears. See Figure 6. -
Page 20: Viewing Reader Details
• Reader Firmware Signature: Shows the reader firmware signatures. To view reader information: 1. From the mobile device applications menu, select the Apriva Reader icon ( ). The Apriva Smart Card Reader screen appears. 2. Select the Details tab. See Figure 7. -
Page 21: Viewing Reader Versions
Installing the Reader Driver on the Mobile Device on page 4, update the reader firmware. NOTE: If you have downloaded a newer firmware version from the Apriva Secure Download website, make sure it is the correct version for the device before installing it on the reader. -
Page 22: Reader Troubleshooting Tips
2. Disconnect the reader from the charger. 3. Power the reader on to make sure the LEDs illuminate. 4. Reconnect the reader to the charger. • If the LEDs still do not illuminate, contact Apriva Technical Support. Apriva Technical Support on page 29. -
Page 23: Reader Led Descriptions
® ® Apriva BT200-T Smart Card Reader for Intermec CK61B/G Installation and User’s Guide Reader LED Descriptions Table 3 describes reader LED indications and their meanings. Action Indication Meaning Reader powered Solid GREEN Normal power on indication while reader on using power... -
Page 24: Reader Error Messages
CK61B/G Installation and User’s Guide Reader Error Messages Table 4 provides information to help you troubleshoot reader errors and error messages. For errors not defined here or for additional support, contact Apriva Technical Support. See Apriva Technical Support on page 29. -
Page 25: Apriva Cspware
Microsoft Certificate Store and use certificate interaction for secure features such as connecting to secure websites. Downloading the CSPware Software You must download the CSPware software from the Apriva secure downloads website before you can install it on the mobile device. To download the CSPware software: 1. -
Page 26: Figure 11 - Download Option
® ® Apriva BT200-T Smart Card Reader for Intermec CK61B/G Installation and User’s Guide 5. Right-click on the latest version of the AprivaCSPwareVxx-xx- xx.zip file (where <xx-xx-xx> is the version number), and then select Download from the menu. See Figure 11. -
Page 27: Installing The Cspware Software On The Mobile Device
® ® Apriva BT200-T Smart Card Reader for Intermec CK61B/G Installation and User’s Guide Installing the CSPware Software on the Mobile Device To install the CSPware software on the mobile device: 1. If you do not have one currently installed, download a data... -
Page 28: Adding And Viewing Certificates
The ID certificate contains your personal information. To add the smart card ID certificate to the mobile device: 1. From the mobile device applications menu, select Apriva CSP. The Apriva CSP Certificates screen appears. See Figure 12. Figure 12 – Apriva CSP Certificates screen 2. -
Page 29: Adding The Key Certificate
Key certificates are PKI certificates issued by a certificate authority (CA). To add the smart card Key certificate to the mobile device: 1. From the mobile device applications menu, select Apriva CSP. The Apriva CSP Certificates screen appears, as shown in Figure 12 page 21. -
Page 30: Adding A Soft-Token Certificate
1. If applicable, copy and paste the certificate to the mobile device. See Installing the CSPware Software on the Mobile Device on page 20. 2. From the mobile device applications menu, select Apriva CSP. The Apriva CSP Certificates screen appears, as shown in Figure 12 page 21. -
Page 31: Viewing All Certificates
Viewing All Certificates You can view all certificates stored on the mobile device. To view all certificates on the mobile device: 1. From the mobile device applications menu, select Apriva CSP. The Apriva CSP Certificates screen appears, as shown in Figure 12 page 21. -
Page 32: Apriva Guard
Windows Mobile operating system. Apriva Guard ensures secure access by requiring you to log in to the mobile device with your personal identification number (PIN). NOTICE Make sure the mobile device is set to the current time and date before you install the Apriva Guard software. -
Page 33: Figure 17 - Apriva Guard Files
BT200-T Smart Card Reader for Intermec CK61B/G Installation and User’s Guide 3. Double-click the SensaGuard.Release folder, and then double-click the Windows Mobile folder to view the available Apriva Guard download files. The version release dates are shown under the “Time” column. See Figure 17. -
Page 34: Installing The Apriva Guard Software On The Mobile Device
CK61B/G Installation and User’s Guide Installing the Apriva Guard Software on the Mobile Device To install the Apriva Guard software on the mobile device: 1. If you do not have one currently installed, download a data synchronization program, such as Microsoft ActiveSync (for Windows XP) or Windows Mobile Device Center (for Windows Vista or Windows 7). -
Page 35: Apriva Vault
Apriva Technical Support on page 29. 2. Select Start > Programs > File Explorer. 3. To save and access files and folders in the vault, select the Apriva Vault icon. See Figure 21. Figure 21 – Apriva Vault icon © Copyright 2010 Apriva... -
Page 36: Support
CK61B/G Installation and User’s Guide Support The following sections provide support information. Apriva Technical Support The Apriva Technical Support Department is available 24 hour a day, 7 days a week including holidays. For prompt service, please have the following information available: •... - Page 37 Apriva 6900 East Camelback Road Suite 700 Scottsdale, Arizona 85251 U.S.A. www.apriva.com © 2010 Apriva All rights reserved. Part number 700013-01...
