Important Safety Instructions
The lighting flash with arrowhead symbol, within a triangle, alerts the user to
"dangerous voltage" which could cause electric shock.
The exclamation point within a triangle is indicates to the user to read
important operating and maintenance instructions in the manual.
Notes
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use near water.
6) Clean only with dry cloth.
7)
Do not block any ventilation openings. Maintain well-ventilated conditions around
the product. Do not put product on bed, sofa or anything that blocks ventilation.
Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9)
This unit is equipped with a polarized plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety. If the plug
provided doesn't fit in your outlet, consult an electrician for replacement of the
obsolete outlet. Removal of the polarized plug will diminish the plugs level of safety.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, for example, power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15) Apparatus should not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, should be placed on the apparatus.
Note: Do not touch the color TFT LCD screen by hand directly.
WARNING: To reduce the risk of fire
or electric shock, DO NOT expose
this product to rain or moisture.
- 1 -
Advertisement
Table of Contents
Related Manuals for Nextar MC3007 20GB
Summary of Contents for Nextar MC3007 20GB
-
Page 1: Important Safety Instruction
Important Safety Instructions The lighting flash with arrowhead symbol, within a triangle, alerts the user to “dangerous voltage” which could cause electric shock. The exclamation point within a triangle is indicates to the user to read important operating and maintenance instructions in the manual. Notes 1) Read these instructions. -
Page 2: Functional Features
Functional Features This apparatus is the latest PMP player. By using the harddisk as its storage device, this product is a multi-media player which could play files of MPEG1, MPEG2 and MPEG4 video format, MP3/WMA audio format and JPEG/ BMP/ GIF picture format. It is with 40GB ultra large capacity, and hundreds of MPEG4 films and thousands of MP3 music could be stored on the harddisk. -
Page 3: Accessories
Please refer to the following sheet, make sure that all these items are attached to your player. Picture NOTE: If you find that the accessories are not in accordance with the items listed in the manual book, please contact the local sales person or the department store. Accessories Name User’s Manual... -
Page 4: Table Of Contents
Important Safety Instruction----------------------------------------------------------------------------------------- Functional Features----------------------------------------------------------------------------------------------------- Accessories--------------------------------------------------------------------------------------------------------------- Table of Contents-------------------------------------------------------------------------------------------------------- Description- Front Panel ---------------------------------------------------------------------------------------------- Description- Rear Panel ---------------------------------------------------------------------------------------------- About the Rechargeable Battery---------------------------------------------------------------------------------- System Connections --------------------------------------------------------------------------------------------------- Connecting to the Power Adapter------------------------------------------------------------------------------- Connecting to AV Input Device----------------------------------------------------------------------------------- Connecting to AV Signal Source---------------------------------------------------------------------------------- Connecting to DC adapter----------------------------------------------------------------------------------------- Connecting to PC------------------------------------------------------------------------------------------------------- Connecting to USB------------------------------------------------------------------------------------------------------ Connecting to Earphone---------------------------------------------------------------------------------------------... -
Page 5: Description- Front Panel
Description -Front Panel 1. POWER Button/Power Indicator/Charge Indicator Press and hold for about 2 seconds to turn on/off the power. The light is green under normal playback status, while red in standby mode. 2. SETUP Button Under file menu, press this button to enter file arrangement mode. Under video file playback status, press this button to switch aspect ratio between16:9 and 4:3. - Page 6 Description -Front Panel NEXT Button Press to skip to the next chapter or track. Under setup menu, press this button to select or adjust items. 8. MENU/STOP Button Press to enter or exit setup menu. In the playback mode, press this button to stop playback. Under the record mode, press this button to stop recording.
-
Page 7: Description- Rear Panel
Description- Rear Panel Rear Panel 1. Rechargeable Battery Switch Push this switch to detach the battery. 2. Rechargeable Battery contact Port Used to connect the rechargeable battery. - 7 -... -
Page 8: About The Rechargeable Battery
About the Rechargeable Battery The power supply of the player is via the attached power adapter or the rechargeable battery. As a portable multi-media player, this player is equipped with a specific lithium polymeric rechargeable battery, for using in outdoor or traveling. About rechargeable battery Charge the battery fully before initial use. -
Page 9: Charging The Rechargeable Battery
About the Rechargeable Battery Attaching The Rechargeable Battery Place the player on a soft and smooth surface with the bottom facing up. Align the plastic tabs on the interface of the rechargeable battery with the holes on the player. Then push the battery downward until it is embedded into the battery slot at which you will hear a slight click. -
Page 10: Detaching The Battery
About the Rechargeable Battery NOTE: The rechargeable battery will discharge gradually when not used for a long period of time, and it will be exhausted within about one month SPECIAL NOTE: If the player is not to be used for a long period of time, you’d better detach the battery from the player in order to prolong the life span of the battery. -
Page 11: System Connections
System Connection NOTE: Before plugging the power cord into an AC outlet, make sure that all other connections have been made as described below. Connecting to the Power Adapter The player is supplied with an AC adapter for powering the unit and charging the battery. Connect AC adapter to the left side of the player in the jack marked DC 9.5V IN, as shown on the below. -
Page 12: Connecting To Av Input Device
System Connection Connecting to AV Input Device This player supports AV output function. Using the supplied audio/video cable to connect the player to the external AV input device, such as a TV. Plug one end into the AV Out jack on the left panel of the player Plug the other end into the input jack of the external AV input device, such as a TV, as shown on the below figure: - 12 -... -
Page 13: Connecting To Av Signal Source
System Connection Connecting to AV Signal Source This player supports AV input function. Using the supplied audio/video cable to connect the player to the external AV output signal source. Plug one end into the AV In jack on the left panel of the player Plug the other end into the output jack of the external AV signal source, such as a DVD, as shown on the below figure: - 13 -... -
Page 14: Connecting To Dc Adapter
System Connection Connecting to DC adapter When used in a vehicle, a specific power adapter should be use to connect the player. Connect the Vehicle Power Plug Adapter to the ”DC 9.5V IN” jack on the left panel of the player Plug the other end into the Vehicle DC Outlet (Cigarette Lighter Socket) as shown below. -
Page 15: Connecting To Pc
System Connection Connecting to PC (Slave-mode) Use the supplied USB cable to connect the player to the personal computer. Plug one end into the USB jack on the left panel of the player, and the other end into the USB jack of the computer. See the below figure. Connecting to USB（Master ModeⅠ... -
Page 16: Connecting To Earphone
System Connection Connecting to USB（Master Mode Ⅱ ） Use one supplied USB cable to connect the player, the other end is connected to the other USB cable, then connected to the external USB device, such as a digital camera, see the below figure: This method is to use the supplied USB cable with one bigger USB cord and one smaller USB cord to connect the USB device that support MINI USB connecting method. -
Page 17: System Setup
System Setup Pre- Operation Press the POWER button for 2 seconds to turn on the power. The main menu will be displayed on the screen. There are seven optional items in the system root menu: Movie, Music, Photo, PVR, Voice Recording, File Manager and Settings. - Page 18 Video Format Setup Adjust the ENT button to select Video Format, then press the PAL and NTSC. The LCD screen will turn off automatically when the PAL is selected. TV Aspect Ratio Setup Adjust the ENT button to select the TV Aspect Ratio, press the 16:9 Wide, 4:3 Pan Scan or 4:3 Letter Box.
- Page 19 System Setup Slideshow Setup Adjust the ENT button or press the buttons to select Slideshow, press the ENT button to enter slideshow setup menu, including Time Interval and Play Mode. The screen will display as below: In the Slideshow setup menu, adjust the ENT button to select the desired item. Then press buttons to select under the item.
- Page 20 System Setup In the power setup menu, adjust the ENT button to select the setup item, press the buttons to select and adjust under the item. Press the MENU/STOP button to return to the previous menu. Screen Saver Setup Adjust the ENT button to select Screen Saver, press the buttons to select the screen saver time or Off.
- Page 21 System Setup Password Setting Adjust the ENT button or press the buttons to choose Password Setting. Press the ENT button to enter Password Setting menu. The screen will display as below: Adjust the ENT button to move the cursor up and down, press the buttons to move the cursor left and right, then press the ENT button to confirm input.
-
Page 22: Movie Setup
System Setup Reset Wallpaper Adjust the ENT button to select Reset Wallpaper, then press the ENT button to confirm and reset wallpaper. Reset to Factory Setting Adjust the ENT button to select Reset to Factory Setting, then press the ENT button to resume to the default settings. -
Page 23: Music Setup
Music Setup Press the MENU/STOP button to enter main setup menu, adjust the ENT button to select Music, Press the ENT button to enter music file selecting menu. In the music file selecting menu, press the and the next page, adjust the ENT button to select music file, then press the ENT button to confirm and start playback. -
Page 24: File Management
File Management File Management Menu In the movie or music file selecting menu, press the SETUP button on top panel to set movie or music file or select items: Play Mode, Playlist, Favorites, Copy, Delete, Rename . In the file manager setup menu, press the SETUP button on the top panel to set the folder or file: New Folder, Copy, Delete or Rename. -
Page 25: Playlist
File Management Press the buttons to select the play mode: Off, Normal, Repeat One, Repeat All, Shuffle. Press the MENU/STOP button to return to the previous menu. Playlist In the movie, music or photo file selecting menu, press the SETUP button first, then adjust the ENT button to select the Playlist, and press the ENT button again to enter setup , the screen will display as below: In the playlist, adjust the ENT button to select the file, press the ENT button to move the file. -
Page 26: Copy
File Management In the Favorite menu, adjust the ENT button to select file, press the ENT button to remove the file. Press the buttons to select “Select File to Add” or “Select File to Remove”. Press the MENU/STOP button to return to the previous menu. Copy In the movie, music or photo file selecting menu and file manager menu, press the SETUP button first, and then adjust the ENT button to select Copy. -
Page 27: Rename
File Management Press buttons to select ”Yes” or ”No”. Press ENT button to confirm the selection. Rename In the movie, music or photos file selecting menu and file manager menu, press the SETUP button first, then adjust the ENT button to select Rename. Press the ENT button again to enter the setup. -
Page 28: Files Download
This player is equipped with USB 2.0 OTG port, you can download program source from the computer. Please follow the below steps: Turn power on; connect the player to the computer via USB cable. The LCD will turn off automatically after the information about that the USB has been connected is displayed on the screen. - Page 29 Files Download USB OTG（USB On The Go）means that any two eligible OTG devices can be connected with each other without the computer. The only purpose of the USB OTG is to provide a method for connecting these two USB devices. When these two devices are connected, one can be used as the host and the other one can be used as the slave.
-
Page 30: Audio And Video Recording Function
Recording Function Audio and Video Recording Function The Player support audio and video recording function, please take the following steps to operate: According to the system connection, connect the unit with the external AV signal source. Turn on the power of the unit and the extern AV signal source. In the main setup menu, select PVR, an indication will appear on the LCD screen. -
Page 31: System Upgrading
System Upgrading The Player supports system upgrading. Please follow the below steps to operate: Use the USB cable to connect the player to computer, and then turn on the power of the player and the computer. After the computer recognizes successfully, decompress the upgrading file to get ROMFS.BIN file, and then copy the file to the root directory on the player and substitute the original file that with the same name (only in the root directory) Disconnect the USB cable directly after copying, the player will restart and go to the... -
Page 32: Troubleshooting
Symptom The LCD screen does not display The LCD screen is too bright or too dark The player does not work There is no sound in the speakers Play a section repeatedly and can not continue. There is no function when pressing buttons Other possibilities: Static or other external interference may cause the player to function abnormally. -
Page 33: Specifications
Specifications Capacity of the memory Audio Response Audio Signal-to- Noise Audio Distortion + Noise Channel Separation Dynamic Range Audio Out Video Out Power Dimension Weight LCD Screen Size DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE 40GB 20Hz～20kHz ≥ 85dB ≤...
