1. FEATURE SUMMARY...1 2. INTRODUCTION...2 3. GETTING TO KNOW THE PLAYER...2 Appearance and Controls...2 LCD Indication...3 4. BASIC FUNCTIONS...3 Using the Menus...4 Enter Various Functional Modes...4 5. MUSIC MODE...5 Playing Music...5 Folder Navigation...5 Display Lyric...5 A-B Repeat...6 Set Play Mode...6 Set EQ Mode...7 Set SRS and WOW Sound Effect...7 Delete Track...8...
Thank you for purchasing our digital MP3 player. This uniquely designed device combines an MP3 player, voice recorder and removable flash memory drive all in one unit. You can transfer files between this player and your computer, and enjoy your MP3 music collection anytime and anywhere.
Thank you for purchasing our MP3 player. Before using the unit, please read this manual carefully, to obtain the best possible performance from your player. Keep this manual for future reference. 3. GETTING TO KNOW THE PLAYER Appearance and Controls “MENU”: to select an entry and to enter a menu, hereafter referred to as “MENU”...
3. GETTING TO KNOW THE PLAYER LCD Indication Function Power On/Off Press and hold the PLAY key until you see prompt on the display. Play/Pause Press the PLAY key to play or pause. Adjust Volume Press the VOL+ button or VOL- button to increase or decrease volume.
Using the Menus (1) Press and hold the MENU key to enter the main menu. (2) Move the MENU key left or right to select menu item and press the MENU key to confirm the selected item. (3) Press the PLAY key to return. Or, do not press any key it will return automatically in a few seconds.
Playing Music (1) On the main menu, select “MSC” menu and press the MENU button to enter the music mode. (2) Briefly press the PLAY button to start playing. (3) Move the MENU button left or right to select the previous or next track. (4) Press the VOL- or VOL+ button to adjust the volume.
A-B Repeat To repeat a specified section of the current track, (1) When the music is being played, briefly press the MENU button to display submenus. (2) Select “Replay” , and then press the MENU button to enter A-B repeat mode. (3) At your desired start point, move the MENU button right to confirm the start point of the repeat.
To select play mode: (1) When the music is being played, briefly press the MENU button to display the submenu. (2) Select "Repeat ", and then press the MENU key to show the provided options. (3) Move the MENU key left or right to select the desired repeat mode, and press the MENU key to confirm, or press the PLAY key to cancel and return.
(2) Select "SRS WOW mode", and then press the MENU key to show the options. (3) Move the MENU key left or right to select the desired option, and press the MENU key to confirm, or press the PLAY key to cancel and return. Delete Track You can delete one single track or all tracks following these steps: (1) Pause the music first and then briefly press the MENU button to display the...
(4) During recording, you can press the PLAY button to pause or resume Recording. (5) Press and hold the MENU button to stop and save the recording. CAUTION: DO NOT REMOVE THE BATTERY DURING RECORDING. DOING SO WILL CAUSE THE CURRENT RECORDING TO BE LOST. Play Recording (1) On the main menu, select the “RPL”...
To browse all folders and tracks, on the main menu, select “BRO” and then press the MENU button to enter the explorer mode. For detail information about how to use the file browser, see the “Folder Navigation” section. To customize the player settings: (1) On the main menu, select the “SYS”...
Page 13
Backlight Set the duration of the backlight after you press any key. Language Select the language in which the on-screen text is displayed. Power set Off time - set the length of time after which the player is turned off automatically when there is no activity. Sleep time - set the continuous playback time before the player is turned off automatically.
Connect to the PC and Download Audio Files The MP3 player is plug & play for WIN2000/XP/ME OS. You don't need to install the driver. Just connect the player to the PC and download audio files following these steps: (1) Remove the USB cover to reveal the USB connector.
(1)Remove the USB connector cover. (2)Press and Move the battery cover in the direction of the arrow. (3)Remove the battery cover and insert one AAA-size battery into the battery compartment. (4)Replace the battery cover. Problem The LCD displays nothing when the device is started.
Page 16
11. TROUBLESHOOTING Total memory displayed on the player is not in accordance with the marked amount. Some of MP3 files cannot be played properly Part of the memory is used to store programs and display characters. The MP3 file is compressed by a standard, such as MPEG I Layer 1 or Layer 2 that the player does not support.
Page 17
IMPORTANT Please read the following carefully: 1) The drivers on the CD are just for Win98. Normally you do not need to install drivers if you are running Windows 2000 SP3 or later. If your PC still does not recognize your player, install the included drivers.
Specification Music format Bit rate Frequency range Signal/noise ratio Channel separation Frequency response Output power to earphones EQ modes Display Type of ports Memory media Memory capacities Output current Power off current Specifications and appearance are subject to change and improvement without further notice. 12.
1). When not using the player for an extended period of time, remove the batteries to avoid damage due to leakage Do not use the player in extremely hot, cold, dusty or damp environments. 3). Make sure the HOLD key is in the unlock position before using the player (otherwise controls will not function).
Page 21
guarantee that interference will not occur in a particular installation. If this equiprnent does cause harrmful interfernce to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ·Reorient or relocate the receiving antenna.
