GROWRILLA 2.0 PRO Manual Instruction

Hide thumbs

Advertisement

Quick Links

Download this manual
2.0
2.0
PRO
PRO
new
MANUAL INSTRUCTION
Strada Comunale da Bertolla
+39 329 3237168
www.growrillahydroponics.com
all'Abbadia di Stura, 140
info@growrillahydroponics.com
10156 Torino - ITALY

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2.0 PRO and is the answer not in the manual?

Questions and answers

Related Manuals for GROWRILLA 2.0 PRO

Summary of Contents for GROWRILLA 2.0 PRO

  • Page 1 MANUAL INSTRUCTION Strada Comunale da Bertolla +39 329 3237168 www.growrillahydroponics.com all’Abbadia di Stura, 140 info@growrillahydroponics.com 10156 Torino - ITALY...
  • Page 2 Growrilla is not simply a system, first of all it wants to be a resource capable of providing the grower with the tools necessary to get the most, because...
  • Page 3 INDEX SYESTEM COMPONENTS ASSEMBLY AND SET UP CONTROLLER POT FITTING AIR DISTRIBUTION SYSTEM TESTING UPGRADE RESET / SYSTEM CLEANING LOGIC OF RDWC SYSTEMS Hello and congratulations “ for choosing a Grorilla RDWc system. I’m your guide who will help you to assembly and set up your RDWc system.
  • Page 4 SIMBOLS The presence of this symbol indicates to pay the attention to the subject matter. Rotate and screw. Lubricate. Risk of leakage , pay attention to this step. Ceck that everything has been done right. Scan this QRcode to download the manual directly on your electronic device.
  • Page 5 - GROWRILLA declina qualsiasi responsabilità per utilizzo improprio del prodotto, o per un uso non descritto in questo manuale. - Prima di utilizzare il prodotto per la prima volta, rimuovere tutto l’imballaggio e assicurarsi che il prodotto sia in...
  • Page 6 SYSTEM COMPONENT AREA 1 - SYETEM COMPONENTS CONTROLLER IN LINE POT CONTROLLER LID DWC POT LIDS POT PRO 2.0 PRO 2.0 SI-GRC50VDC19 SI-GRC50VPAS19 SI-GRCOP19 SI-GRCCOP191F NET POT 14CM WATER ELBOW 90 PP TEE PP PUSH PROOF 50mm RUBBER GASKETS PUSH FIT D50 FIT D50 ID-NETHD014 RC-GSKGGDN50...
  • Page 7 BARBED FITTING BARBED FITTING BARBED FITTING THREADED TEE 1" 20X1" F 20X3/4" F 20X3/4" M 3/4" FFF RC-PG20DGM RC-PG20CGM RC-PG20CM RC-FILTECCFFFGM AREA 2 - CONTROLLER POT COMPONENTS EXT. TRHEADED THREADED ELBOW BULKHEAD 3/4" WATER PUMP FITTING 3/4" MALE 90 3/4" FF EDEN 135TB RC-FILPRLCMM RC-FIL90CCFFGM...
  • Page 8 SYSTEM COMPONENT AREA 3 - AIR DISTRIBUTION SYSTEM AIR HOSE AIR HOSE PVC AIR HOSE AIR GASKETS 6X4MM 12X8MM 6X4MM L30CM TU-SIL0604100 TU-PVCTH0812 PVC64030 RC-GSKPT1006 AIR ELBOW FITTING AIRMANIFOLD 12X6 AIRMANIFOLD 12X6 AIRMANIFOLD 12X6 3X5MM 1 WAY OUT 2 WAY OUT 4 WAY OUT RC-PG900305 RC-PGMU1206U1...
  • Page 9 AREA 4 - ADDITIONAL COMPONENTS FLEXIBLE STORAGE CONNECTION FLOAT VALVE TUBO FLESSIBILE TANK QUICK FITTING PVC DN16 ID-CONTF098 SI-GRCTF16MT2 ID-VALG12178 TU-PVCGFP16 ID-CONTF157 ID-CONTF225 ID-CONTF500 ID-CONTF700 EXTENSION FOR EXTENSION FOR CHILLER KIT DELIVERY MANIFOLD A DELIVERY MANIFOLD B WATER PUMP SI-GRC50MMBPR SI-GRC50MMAPR ID-PACCHJ600 ID-PACCHJ800...
  • Page 10 SYESTEM INSTALLATION STEP 1 SYSTEM INSTALLATION a) Unbox. Place all parts adjacent to the grow area and keep all the components separately. All the components are divided by type, this will make it easy to recognize them and will help you to understand where they have to be used.
  • Page 11 air hole 2 FILE 3 FILE 4 FILE d) now you are able to start to insert the connection pipes inside the gaskets. Gasket. lubricate the internal side of the gaskets and the PVC pipe before insert them How to fit the pipe. insert the pipe inside the gasket simply sliding it inside them.
  • Page 12 DELIVERY MANIFOLD ASSEMBLY SI-GRCMRB50 SI-GRCMRB50 SI-GRCMRB50 SI-GRCMRB50 SI-GRCMRB50 SI-GRCMRB50...
  • Page 13 f) Assembly diagrams DELIVERY MANIFOLD. DELIVERY MANIFOLD SI-GRC50MMA 2/3 ROWS RC-PPBG90502B x1 TU-PVC50015 DELIVERY MANIFOLD SI-GRC50MMB 3/4 ROWS TU-PVC50015 TU-PVC50040 RC-PPBG90502B RC-PPBT90502B RETURN MANIFOLD SI-GRC50MRA 2/4 ROWS TU-PVC50015 SI-GRC50TR40D RC-PPBT90502B RC-PPBG90502B RETURN MANIFOLD SI-GRC50MRB 3 ROWS TU-PVC50015 SI-GRCTR5040D RC-PPBT90502B RC-PPBG90502B...
  • Page 14 ROWS RDWC SYSTEM g) DELIVERY MANIFOLD FOR 2/ ROWS SYSTEM. connect the controller pot to the first two growing pot. SI-GRC50MMA SI-GRC50MMA h) Growing Pot Connection . D I S T A N C E BETWEEN POTS: the distance between pots can be adjusted simply sliding the pipes inside the pots ( please...
  • Page 15 ROWS RDWC SYSTEM l) DELIVERY MANIFOLD FOR 3/ ROWS SYSTEM: connect the controller pot to the first 3 growing pots . Use the component SI-GRC50MMB to connect the growing pot 1 and 2. Use the com- ponent SI-GRC50MMA to connect the growing pot 3. SI-GRC50MMB SI-GRC50MMA m) Growing Pot Connection .
  • Page 16 ROWS RDWC SYSTEM o) DELIVERY MANIFOLD FOR 4/ ROWS SYSTEM. connect the controller pot to the first 4 growing pots . Use the two componen- ts SI-GRC50MMB to connect the growing pot 1 and 2, then con- nect the pots 3 and 4 SI-GRC50MMB SI-GRC50MMB p) Growing Pot Connection .
  • Page 17 CONTROLLER POT FITTING KIT STEP 3 CONTROLLER POT FITTING KIT a) Unbox. Keep the controller pot fitting bag and start the assembly. b) Water Pump. Screw the extension tube and the elbow threaded fitting as shown in the figure. RC-FIL90CCFFGM ID-PAC135TB c) BULKHEAD.
  • Page 18 CONTROLLER POT FITTING KIT Screw the VENTURI ELBOW and the other EXTENSION TUBE to the internal side of the controller pot. Note. Make it sure that all the fitting are well screwed. Water Pump. Make sure the water pump is perfectly set on the ground.
  • Page 19 RETURN HOSE KIT ORING. remember SI-GRC50FVDK KIT FILTRO CON VALVOLA 1" to put the o'ring on the male thread of the valve. RC-GSKORDM RC-VALPVCDMF IR-FLTD50B RC-VALDMF Screw the FILTER + VALVE KIT inside the RETURN TEE then connect the water sucking hose to the second valve. Make sure that the two valves are tight- ly screwed.
  • Page 20 RETURN HOSE KIT Nel sistema a 3 FILE i due tubi di aspirazione dei moduli di Ritorno rimango- no i medesimi, a variare di lunghezza sarà la dorsale principale che va dal Tee al vaso di controllo. SI-GRC50GR3F Aspirazione. La lunghezza di questo compo- nete varia in base...
  • Page 21 Nel sistema a 4 FILE i due tubi di aspirazione dei moduli di Ritorno rimango- no i medesimi, a variare di lunghezza sarà la dorsale principale che va dal Tee al vaso di controllo. SI-GRC50GR4F Aspirazione. La lunghezza di questo componete varia in base al numero di vasi posati.
  • Page 22 DISTRIBUTION AIR LINE KIT STEP 3 AIR DISTRIBUTION a) Unbox. Take all the components of your AIR DISTRIBUTION KIT and put them together, you will be able to recognise all the pieces are shown below b) Air Pump. Place the air pump. Pump.
  • Page 23 c) AIR JOINT . For 3/4 Row systems we have pre-assembled the tail joints to facilitate your work, here below the two versions. SI-GRC50GCA3F 3 ROWS L100 SI-GRC50GCA4F 4 ROWS d)AIRHOSE 12X8mm. It’s used to connect the air distribution line to the air pump. AIR PUMP BRASS FIT- TING.
  • Page 24 DISTRIBUTION AIR LINE KIT e) AIR MANIFOLD ( 4 WAY OUT). Air manifolds are used to bring air from the main distribution line to every growing pot. End cap and the air mani- fold 4 way out it come with the swivel lock system, and have to be assembled as shown in the picture below.
  • Page 25 f) AIR DISTRIBUTION LINE. Complete the air distribution line following the diagrams shown below. Search for your system diagram, every system has a di erent distribution line according to the number of pots involved. RDWC 4 - 2 ROWS AIR PUMP V-30 ID-PARV30 RC-PGSMU1206U4...
  • Page 26 DISTRIBUTION AIR LINE KIT RDWC 8 - 2 ROWS AIR PUMP ET40 ID-PARET40 RC-PGSMU1206U4 RC-PGSTAP012 TU-PEN12100B to air pump L100 TU-PVCTH0812 RDWC 9 - 3 ROWS AIR PUMP ET40 ID-PARET40 RC-PGMU1206U1 RC-PGMU1206U2 RC-PGSMU1206U4 RC-PGSTAP012 SI-GRC50GCA3F TU-PEN12050B TU-PVCTH0812 to air pump...
  • Page 27 RDWC 12 - 3 ROWS AIR PUMP V-60 ID-PARV60 RC-PGMU1206U2 RC-PGSMU1206U4 RC-PGSTAP012 SI-GRC50GCA3F TU-PEN12100B TU-PVCTH0812 to air pump L100 L100 GOMITO ARIA 11MM RC-PG9010 TAPPO ARIA 11MM RC-PGSTAP012...
  • Page 28 DISTRIBUTION AIR LINE KIT RDWC 12 - 4 ROWS AIR PUMP V-60 ID-PARV60 RC-PGMU1206U2 RC-PGSMU1206U4 RC-PGSTAP012 SI-GRC50GCA4F TU-PEN120050B TU-PVCTH0812 to air pump...
  • Page 29 RDWC 16- 4 ROWS AIR PUMP V-60 ID-PARV60 RC-PGSMU1206U4 RC-PGSTAP012 SI-GRC50GCA4F TU-PEN12100B TU-PVCTH0812 to air pump L100 L100...
  • Page 30 DISTRIBUTION AIR LINE KIT RDWC 18 - 3 ROWS AIR PUMP ET80 ID-PARET80 RC-PGMU1206U2 RC-PGSMU1206U4 RC-PGSTAP012 SI-GRC50GCA3F TU-PEN12100B TU-PVCTH0812 to air pump L100 L100 L100 L100...
  • Page 31 RDWC 24- 4 ROWS AIR PUMP V-60 ID-PARV60 RC-PGSMU1206U4 RC-PGSTAP012 TU-PEN12100B TU-PVCTH0812 to air pump L100 L100 to air pump L100 L100...
  • Page 32 DISTRIBUTION AIR LINE KIT g) Air Stones. Connect the air stone as shown in the picture below AIR STONES: RC-PG900305 the air stone are used to release the air from the pump in order to oxygenate the water and then increase the oxygene of the solution inside PVC64030 the pots.
  • Page 33 l) Complete installed system example.
  • Page 34 SYESTEM TESTING STEP 3 SYSTEM TESTING Now that your system has been assembled let’s proceed with the testing of the system before starting with to load the solution and start growing. Follow the step below: 1) FITTING. Make sure you have tightened all the threaded fittings across the RETURN HOSE 20MM from the IN LINE FILTER KIT to the WATER PUMP.
  • Page 35 2) GASKETS. Fill the system with water until the connecting pipe will be covered 1 cm. Switch on the water pump and wait for about 15 min, let the water circulate throughout the system and look for any water leak. If you recognize a leak go to the TROUBLESHOOTING CHART and find the right way for fixing it.
  • Page 36 SYESTEM TESTING 4) AIR DISTRIBUTION. connect the air pump to the power supply and check that all the air stone works fine. 5) LOADING THE SYSTEM. Fill the system with water up to the level of the bottom of the net pots. 6) TEST.
  • Page 37 7) NUTRIENT SOLUTION. now you are ready to make your nutrient solution. Use the control pot for ceck your EC and pH level . Calibrate the solution as needed by placing fertilizers or pH regulators in the control pot. Let the solution circulate inside the system and let the EC and pH values stabilize, then double check and correct if needed NB: choose your cultivation range well, on our website you can find a wide choice of fertilizers, additives and tools, as well as tutorials for cor-...
  • Page 38 CUSTOMIZE SYSTEM STEP 5 MODIFY AND CUSTOMIZE YOUR SYSTEM The new GROWRILLA RDWC PRO systems can be easily modified and customized according to the grower's needs. Everything is made particularly simple thanks to the use of push fit fittings that allow them to be disassembled and reas- sembled as needed.
  • Page 39 EXTENDED PIPES a) EXTENDED PIPES. For example, you can extend the distance of the control pot from the growing pots to place it outside the grow tent. PROLUNGA MODULO MANDATA A - L60 SI-GRC50MMAPR 2 ROWS 3 ROWS PROLUNGA MODULO MANDATA B - L40 SI-GRC50MMBPR 4 ROWS...
  • Page 40 INTEGRATION CHILLER b) Run the chiller with RECIRCULATION PUMP. you can connect a chiller or a refrigeration unit to the system in order to keep the water tem- perature under control. You can doing that in two di erent way. Switch o the recirculating water pump.
  • Page 41 INTEGRAZIONE CHILLER CHILLER Use a 16mm flexible pipe to connect the two barbed fitting to the chiller in/out b) Run the chiller with an INDEPENDENT PUMP. The chiller can be connected by another water pump as shown in the picture below. The use of an independent pump is highly recommended to keep the flow rate of the solution in the system separated from the water flow to the chiller.
  • Page 42 FLOATING VALVE d) FLOATING VALVE. Floating valves allow you to connect the system with a separated water storage tank in order to always keep the right water level. When the water level in the system drops, the valve opens allowing new water to enter until the set level is reached.
  • Page 43 SYSTEM DOWNLOAD CLEANING For system unloading operations, refer to the methods listed below. You can download the system in two di erent way: Svita la ghiera mobile del gomito a 90°. Posiziona il gomito come in figura. LIV.MIN Posiziona il portagomma maschio sul gomito e colega un tubo flessibile su di esso, indirizzalo...
  • Page 44 RDWC HOW DOES IT WORK? , aka Deep Water Culture is one of the best performing methods for growing hydroponic plants. The plant grows with the roots immersed in a nutrient solution constantly oxygenated by an air pump. The high value of dissolved oxygen available directly to the plant’s roots increases growth processes, accelerating deve- lopment and increasing the weight of the crop.
  • Page 45 COLTIVARE IN UN SISTEMA La chiave della coltivazione con i sistemi deep water culture sta nell’ossigenazione della soluzio- ne nutritiva e nello specifico nel contenuto di ossigeno disciolto all’interno della soluzione nutriti- In ogni vaso di coltivazione è presente una pietra porosa col- legata ad un aeratore mediante linea distribuzione...
  • Page 46 Strada Comunale da Bertolla +39 329 3237168 www.growrillahydroponics.com all’Abbadia di Stura, 140 info@growrillahydroponics.com 10156 Torino - ITALY...
