Panasonic ES4033-A3 Service Manual

Panasonic ES4033-A3 Service Manual

Ac/rechargeable shaver
Hide thumbs

Advertisement

Quick Links

Download this manual
SPECIFICATIONS
Power source
Motor voltage
Charging time
Shaves per charge
Measurement
Weight
Supplied accessories
CONTENTS
AC 220V, 50-60Hz (Automatic voltage conversion)
1.2V DC
1 Hour for ES4035, 8 Hours for ES4033
7 times (3 minutes shave)
(H)14.6 x (W)5.7 x (D)4.9 cm
155g
Soft case
Cleaning brush
Page
2
2
3
6
AC/Rechargeable Shaver
ES4033-A3
ES4035-A3
© 2004 Matsushita Electric Works, Ltd. All rights
reserved. Unauthorized copying and distribution is a
violation of law.
ORDER NO. SD0406A47C3
Page
9
10
11

Advertisement

loading

Related Manuals for Panasonic ES4033-A3

Summary of Contents for Panasonic ES4033-A3

  • Page 1: Table Of Contents

    ORDER NO. SD0406A47C3 AC/Rechargeable Shaver ES4033-A3 ES4035-A3 SPECIFICATIONS Power source AC 220V, 50-60Hz (Automatic voltage conversion) Motor voltage 1.2V DC Charging time 1 Hour for ES4035, 8 Hours for ES4033 Shaves per charge 7 times (3 minutes shave) Measurement (H)14.6 x (W)5.7 x (D)4.9 cm...

  • Page 2: Schematic Diagram

    ES4033-A3 / ES4035-A3 1 SCHEMATIC DIAGRAM 2 WIRING CONNECTION DIAGRAM...

  • Page 3: Disassembly Instructions

    ES4033-A3 / ES4035-A3 3 DISASSEMBLY INSTRUCTIONS Follow the procedure below to disassemble the main unit. 1. Remove the cap, the outer foil with foil frame and the inner blade. 2. Slide the trimmer handle up to open the trimmer and unhook the trimmer handle by inserting something like a plastic spatula into a slit.
  • Page 4 ES4033-A3 / ES4035-A3 4. To remove the trimmer driving bar, press it outward. 5. Loosen a screw and remove the bottom cover. 6. Peel off the side panels on both sides. 7. Loosen two screws and the retaining plate. Remove the waterproof rubber.
  • Page 5 ES4033-A3 / ES4035-A3 9. Take out the housing B. 10. Remove the motor assembly first. And take out the module assembly from housing A. 11. Remove the battery o-ring and washer from battery terminal. Take out the rechargeable battery from the...

  • Page 6: Caution In Assembly

    ES4033-A3 / ES4035-A3 4 CAUTION IN ASSEMBLY NOTE: When reassembling, replace the new waterproof rubber. Make sure whether there is NO foreign substance sticking around a part covered with water seal. 4.1. Driving heads Install the driving head A in motor and assemble the driving head B.
  • Page 7 ES4033-A3 / ES4035-A3 4.4. Housing Set the both sides of foil frame release buttons with springs. Put the housing B on the housing A. Tighten the screws with care of pinching screw o-rings. 4.5. Waterproof rubber The waterproof rubber must be fitted the right way around.
  • Page 8 ES4033-A3 / ES4035-A3 4.7. Side panel Set the side panel on the body and press fit until clicking the hook of panel at three locations. Fit the hook on top first, then front side and rear side. NOTE: Make sure that the left and right side panels are firmly fitted on both rear and front side.

  • Page 9: Troubleshooting Guide

    ES4033-A3 / ES4035-A3 5 TROUBLESHOOTING GUIDE (Refer to) <TROUBLE> <CHECK.> <REMEDY> Motor does not rotate. <CHECK POWER CORD UNIT.> NO Replace power cord unit. → → → → Connect the rated voltage to the normal main unit of empty charge capacity →...

  • Page 10: Exploded View

    ES4033-A3 / ES4035-A3 6 EXPLODED VIEW...

  • Page 11: Replacement Parts List

    ES4033-A3 / ES4035-A3 7 REPLACEMENT PARTS LIST NOTE: *A= available as an optional accessory *B= only available as set *C= available individually Ref.No. Part No. Part Name & Descriptions Remarks Per Unit WES4025X7158 PROTECTIVE CAP (BG) WES9837EP OUTER FOIL WES9850EP...

This manual is also suitable for:

Es4035-a3
