BLAM BT30 - Wireless Stereo Speaker Manual

Table of Contents

Contents

1 Box Content
2 Overview
3 Connect two speakers in stereo
4 Bluetooth
5 AUX
6 NFC
7 SAFETY
8 Documents / Resources
- 8.1 Download manual

Box Content

30W Wireless Speaker
Audio Cable (jack 3.5mm - jack 3.5mm)
Charging cable
User Manual

Overview

Power button
Press and hold for three seconds to turn on/off. Auto power off after 40 minutes idea for power saving.
Previous button
Press to navigate between tracks.
Play/Pause button
Use to play and pause audio. While in Bluetooth mode, press and hold to activate Siri or S-Voice. Press again to disable. Incoming call: press once to answer, press again to end. Press and hold to decline call.
Next button
Press to navigate between tracks.
Mode button
Use this button to toggle between Bluetooth/AUX/USB mode. Press and hold to pair TWS speakers together.
Bluetooth button
If there is no AUX cable inserted, the speaker will automatically enter default Bluetooth Mode. When in Bluetooth mode, press to initiate Bluetooth pairing.
Charging Indicator
Flashing red: battery is low. Solid green: device is charging.
Battery-Level Indicator
Lights indicate remaining power. Flashing: device is charging. Solid: device is fully charged.
Volume decrease button
Thermal sensor
Detects the heat of a human hand and will automatically activate the devices frosted LED button-backlighting.
Microphone
Remain within three feet of microphone while speaking.
AUX indicator
When an AUX cable is inserted into speaker, the device will automatically enter AUX mode. When solid green indicator light is on, AUX mode is enabled.
Volume increase button
Bluetooth indicator
When the indicator light is on, Bluetooth mode is enabled. When Bluetooth is in pairing mode, a blue indicator will flash. Once a device has been paired, blue indicator will remain solid.
NFC area
Hold your device over this area to use NFC for Bluetooth Connection.
AUX IN port
Connects speaker to external media devices.
AUX OUT port
For headphone use.
Micro USB Jack
This port cannot be used for external device connection, for charging use only.
USB power port
Provides power to connected devices. This function is enabled when speaker is on.
Reset button
Press to reset device.

Connect two speakers in stereo

Une fois Once on of your two speakers are successfully paired with a device, follow these steps to pair TWS:

Press Mode button on the first speaker to enter pairing with blue indication flashing and pairing prompts.
Power the 2nd speaker to paring (disconnected if Bluetooth connected).
A tone will sound when the two speakers have been successfully paired with purple Bluetooth indicator on the 1st speaker and yellow indicator on 2nd speaker.
Now you can enjoy the crisp stereo surround sound with separate left channel and right channel. The next time when both speakers are powered on, the need to be re-paired.

NOTE

TWS function available only in Bluetooth & AUX IN mode.
No memory function for TWS connection.
Two speakers shut down simultaneously while power off.

Follow the above instruction to pair the two speakers again next time when you turn on.

Bluetooth

Power on speaker and hold your phone or other device within 3 feet of the speaker, press the Bluetooth button : the speaker will enter pairing mode and the indicator light should begin flashing.
Pairing mode will automatically be stopped (signaled by a beep) after 3 minutes. To re-enter pairing mode, follow the instructions beginning at step 1.
Ensure Bluetooth is enabled on the device you want to pair the speaker with.
The speaker will appear as "BT30" when scanning for available devices.
When selecting "BT30" from the list, if prompted for a password, enter ''0000''.
The speaker will record this device as the last device paired.
When in Bluetooth mode you can with to AUX mode by inserting the AUX cable.
Incoming calls will override music and other media with an incoming call voice prompt, simply press the Play button . to answer/end or press and hold to decline the call. Press the Play button to answer a second incoming call.
Press and hold the Play button for three seconds to activate Siri/S-Voice function of your phone.

AUX

Insert the AUX cord into the designated port to automatically switch the speaker to AUX mode. While in AUX mode, AUX indicator will glow Connect your audio device to AUX input with the supplied 3.5mm audio cable.

NFC

Turn on the NFC function on the device you wish to connect to your speaker. Touch the device to the speaker NFC area located on the top of the speaker next to the Mic. Port. The speaker will connect automatically.

Proper use

To prevent damage and risk of electrical shock, do not expose this device to dust, vibration, rain, water or liquids of any kind.
Do not place device near open flames or extreme heat sources. Always place your device on level, flat and stable surfaces.
Avoid placing items on top of the speaker.
Do not use excessive force when pressing buttons or handling speaker.
To clean your speakers, use a dry, soft cloth or minimally damp cloth without any corrosive solvent or cleaning agent.

SAFETY

To prevent fire, shock or injury, please do not disassemble or replace any parts of this speaker. If your device becomes damaged or in need of repair, please contact a professional maintenance or qualified service center for assistance. We are not responsible for any personal injury or property damage caused by improper use of this product. Please do not allow the use of this speaker by small children without proper adult supervision.
