STEP 5
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY.
Carefully turn the unit over on its front side.
Position back panel as shown. Align squarely with all edges and nail straight into back edges as
shown.
14
Finished Edges
systembuild.com
14
(x30)
B
Face Down
Assure that our unit is square.
Distance from corner to corner
must be equal as shown.
Raw Surface Shown
D
Flush bottom edge of the back
panel with the bottom edge of
bottom (D).
13
