Your Growth Is Our Goal
PF50, PF80, PF80LP, PF110
Portable Filter
Installation, Operation and Maintenance
Manual
This manual is updated as new information and models are released. Visit our website for the latest manual.
PF110
PF50
PF80L
PF80
CAUTION
READ THE INSTRUCTIONS BEFORE USING
8197541D
Part Number: FRY_IOM_8197541 D (US Manufactured)
10/2022
Advertisement
Related Manuals for Welbilt FRYMASTER PF80L
Summary of Contents for Welbilt FRYMASTER PF80L
- Page 1 Your Growth Is Our Goal PF50, PF80, PF80LP, PF110 Portable Filter Installation, Operation and Maintenance Manual This manual is updated as new information and models are released. Visit our website for the latest manual. PF110 PF50 PF80L PF80 CAUTION READ THE INSTRUCTIONS BEFORE USING 8197541D Part Number: FRY_IOM_8197541 D (US Manufactured) 10/2022...
- Page 2 WARNING Safe and satisfactory operation of your equipment depends on its proper installation. Installation MUST conform to local codes, or in the absence of local codes, with the latest edition of the National Electric Code, N.F.P.A. 70. WARNING ELECTRICAL GROUNDING INSTRUCTIONS This filter is equipped with a three-prong, grounded plug for your protection against shock hazard and should be plugged directly into a properly grounded, three-hole receptacle.
- Page 3 NOTICE: If this filter unit is cleaned with water, disconnect the unit from power source before cleaning and thoroughly dry the filter unit before reconnecting to electrical power source. DANGER The crumb tray (if equipped) in portable filter systems must be emptied into a fireproof container at the end of frying operations each day.
-
Page 4: Table Of Contents
PF-Series Portable Filtration Systems Operation Manual TABLE OF CONTENTS Page INTRODUCTION IMPORTANT INFORMATION FILTER PREPARATION OPERATING/FILTER INSTRUCTIONS CLEANING AND MAINTENANCE TROUBLESHOOTING... - Page 5 Register Your Warranty Online at http://fm‐hal.frymaster.com/qsys.lib/cgi.lib/swr290.pgm ...
-
Page 6: Introduction
PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 1: INTRODUCTION 1.1 Parts Ordering Place parts orders directly with your local Frymaster/Dean Factory Authorized Service agency. A list is accessible on our website at: www.frymaster.com. To help speed your order, the following information is required: Model Number Type Serial Number... - Page 7 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 1: INTRODUCTION 1.3 After Purchase In order to improve service, fill out the following chart with the nearest Frymaster Authorized Service Technician and FAS in your area. Authorized Service Technician/FAS Address Telephone/Fax Filter Model Number Filter Serial Number 1.4 Safety Information Before attempting to operate your unit, read the instructions in this manual thoroughly.
- Page 8 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 1: INTRODUCTION 1.5 Service Personnel 1.5.1 Definitions A. Qualified and/or Authorized Operating Personnel 1. Qualified/authorized operating personnel are those who have carefully read the information in this manual and have familiarized themselves with the equipment functions, or have had previous experience with the operation of equipment covered in this manual.
-
Page 9: Important Information
PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 2: IMPORTANT INFORMATION PF110 PF50 PF80LP PF80 2.1 General The PF-series portable filters can be used with a variety of Frymaster fryers, as well as other manufacturers’ equipment. Unit specifications are listed below. Model Unit Height Unit Width Unit Length Tank Height... - Page 10 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 2: IMPORTANT INFORMATION A Suction/Off/Return switch activates/deactivates the filter pump. The filter also has a Heater/Filter switch for use when filtering solid shortening. PF switch/light panel. A thermal-overload switch on the pump motor provides protection against overheating. NOTE: If the thermal overload is triggered, wait 45 minutes, and then press the reset button to activate the circuit after...
- Page 11 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 2: IMPORTANT INFORMATION 2.3 Pre-Installation NOTE: Failure to use qualified service personnel will void the Frymaster warranty. A. Standards: Use of this filter unit must be in accordance with all applicable state and local codes. DANGER This portable filter is equipped with a three-prong (grounding) plug for protection against electrical shock and must be plugged directly into a properly grounded,...
-
Page 12: Filter Preparation
PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 3: FILTER PREPARATION 3.1 Assembling The Filter System On initial installation and before each use, remove all loose parts from the filter, wash all accessories in hot, soapy water and dry thoroughly. DO NOT WASH INTERIOR OF FILTER PAN WITH DETERGENT OR WATER! Wipe debris and residue from the filter pan with a damp cloth or paper towel, then with a dry cloth or paper towel. - Page 13 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 3: FILTER PREPARATION 3.1 Assembling The Filter System (cont.) 1. Ensure the filter pan is clean and free of all food and breading particles that could prevent the filter paper from sealing against the bottom of the pan. 2.
- Page 14 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 4: OPERATING/FILTERING INSTRUCTIONS 4.1 Filter Operation (Suction and Return) WARNING Use care when draining and filtering oil to avoid the possibility of a serious burn. 1. Sprinkle 8 ounces (1 cup) of filter powder over the filter paper, distributing the powder as evenly as possible.
- Page 15 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 4: OPERATING/FILTERING INSTRUCTIONS 4.1 Filter Operation (cont.) 5. Ensure the oil is at operating temperature [~350° (177°C)]. Turn the fryer off. WARNING The filter pan maximum capacity varies with model. DO NOT OVERFILL THE FILTER PAN.
- Page 16 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 4: OPERATING/FILTERING INSTRUCTIONS 4.1 Filter Operation (cont.) To flush residual shortening and sediment from the frypot, place a clean metal container under the frypot drain valve. Open drain valve and place the hose nozzle inside the frypot. Turn the Suction/Off/Return switch to RETURN.
- Page 17 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 4: OPERATING/FILTERING INSTRUCTIONS Close the drain valve and allow the frypot to fill. Ensure all oil is returned to the frypot before turning filter off. Allow the portable filter to cool, then remove and discard the filter paper. Clean the interior of the filter pan and all components.
- Page 18 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 4: OPERATING/FILTERING INSTRUCTIONS 4.2 Filter Operation (Return Only) WARNING Use care when draining and filtering oil to avoid the possibility of a serious burn. 1. Sprinkle 8 ounces (1 cup) of filter powder over the filter paper, distributing the powder as evenly as possible.
- Page 19 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 4: OPERATING/FILTERING INSTRUCTIONS 4.2 Filter Operation (cont.) 5. Ensure the oil is at operating temperature, 350°F (177°C). Turn the fryer off. WARNING The filter pan maximum capacity is 50 lbs. DO NOT OVERFILL THE FILTER PAN. 6.
-
Page 20: Cleaning And Maintenance
PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 5: CLEANING AND MAINTENANCE 5.1 General Cleaning operations fall into three general categories: • Wiping unit clean after each filter session; • Cleaning, changing filter paper and preparing the unit for the next day’s business. •... - Page 21 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 5: CLEANING AND MAINTENANCE 5.3 Daily— Close Of Business At the close of a working day, filter the oil in all fryers. When the last fryer is filtered, follow these steps: Ensure the flexible hose and pump lines are clear by running the filter pump for an additional 15–30 seconds after air bubbles start coming from the oil return line.
-
Page 22: Troubleshooting
PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 6: TROUBLESHOOTING 6.1 Operating Problems Plugged lines and plugged filter paper account for over 90 percent of filtration system malfunctions. A general troubleshooting chart, included in this chapter, provides instructions in diagnosing common malfunctions. Contact a factory-authorized service technician for troubleshooting beyond the scope of the operator. - Page 23 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 6: TROUBLESHOOTING 6.2 General Troubleshooting (cont.) Pump won't -- Tripped thermal overload switch. start. -- Incorrect or no line voltage. -- Allow filter unit to cool for at least 45 minutes and Pump stops then press (reset) the motor thermal overload switch. during -- Turn filter pump "OFF".
- Page 24 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 6: TROUBLESHOOTING Wiring Diagrams 120VAC 220/240VAC...
- Page 25 PF-SERIES PORTABLE FILTRATION SYSTEMS CHAPTER 6: TROUBLESHOOTING Parts List • = used or included with portable filter. Name Part Number Description PF110 PF50 PF80 CASTER 8102805 CASTER, 2" FILTER PAN • • • CASTER 8102806 CASTER, 2" W/BRAKE FILTER PAN •...
- Page 26 , Merrychef and Multiplex ® ® ® ® ® Bringing innovation to the table · welbilt.com ©2022 Welbilt Inc. except where explicitly stated otherwise. All rights reserved. Continuing product improvement may necessitate change of specifications without notice. Part Number FRY_IOM_8197541D 10/2022...
