- Page 1 HD IP Fixed Bullet Camera User's Manual_Install Part G Ver. 1.2 / 2021.03 Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for future reference.
-
Page 2: Table Of Contents
Contents INTRODUCTION Important Safety Informa�on Product & Accessories Part Name INSTALLATION Installa�on Cabling Inser�ng / Removing an SD Memory Card SPECIFICATION Dimension... - Page 3 Safety Instruction These instruc�ons are intended to ensure that the user can use the product correctly to avoid danger or property loss. If the product is not func�oning properly or damaged, contact the service center or purchasing office. Warnings Cautions Serious injury or death may be caused Injury or equipment damage may be caused if any of these warnings are neglected.
- Page 4 Installa�on and Use Precau�ons The ba�ery (ba�ery pack or equipped ba�ery) must not be exposed to excessive heat such as sunlight, fire, etc. Do not disassemble the camera at your discre�on. If you forcefully install the product with excessive force, malfunc�on can damage the camera. Do not punch or shake the camera and be careful not to damage the camera with careless storage or malfunc�on.
- Page 5 Disposal of Old Appliances 1. The symbol marked in the product, will follow and covered by the Europe Direc�ve 2002/95/EC. 2. All electornic disposal of waste is differenct by the government or locally, so so it need to check. 3. The correct disposal of your old appliance will help prevent poten�al nega�ve consequences for the environment and human health.
-
Page 6: Product & Accessories
Introduc�on - Product & Accessories Please check if all the camera and accessories are included in the package. Cables Camera Torx Wrench Test Video Cable Template Sheet Quick Manual Waterproof cap & Gasket Screw & Plas�c Anchor-4pcs... -
Page 7: Part Name
Introduction - Part Name Sunshield Adjus�ng Screws Sunshield Lens Pan/Tilt Stoper Screw Control Board Bracket Con Cap Alarm In/Out RJ-45 Connector Waterproof cap Audio In/Out DC Power Jack... -
Page 8: Installation
Installation - Installation Before installing your camera, you have to read the following cau�ons. 1. You have to check whether the loca�on can bear five �mes of the weight of your camera. 2. Don’t let the cable to be caught in improper place or the electric line cover to be damaged. Otherwise it may cause a breakdown or fire. -
Page 9: Installa�On
Installa�on - Cabling Two Op�ons Use a PoE-enabled switch to connect data and power through a single cable and begin viewing and recording images instantly. A non-PoE switch will require an adaptor for power transmission. 1. Using a PoE-Enabled Switch 2. - Page 10 Installa�on - Cabling Ac�va�on In 1 In 1 Ac�va�on In 1 In 1 Alarm In Alarm Out Network Power Audio Out Audio In Audio Input Please, check the voltage and current capacity of rated power Connect the ‘Audio In’ cable of the camera to the device like microphone.
-
Page 11: Inser�Ng/Removing An Sd Memory Card
Installa�on - Inser�ng/Removing an SD Memory Card The memory card is an external data storage device that has been developed to offer an en�rely new way to record and share video, audio, and text data using digital devices. Micro Recommended SD Card Specifica�on (Not Included) - Type: Micro SD (SD/SDHC/SDXC) - Manufacturer: SanDisk, Samsung, Transcend, Micron... -
Page 12: Specification
Specifications - Dimension Unit: mm Ø 78 Ø 4.2 247.2 92.4 96.7 122.6...
