- Page 1 Heathdon/ Lavendon Spare Parts Customer Support www.argos-support.co.uk 0345 640 2020 Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 19/05/21...
-
Page 2: Care And Maintenance
Safety and Care Advice Product Details Grey Fabric 951/5400 Grey PU 947/3566 Black PU 945/2721 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. Keep children and animals Assemble the item as close We do not away from the work area, small to its final position (in the same recommend the parts could choke if swallowed. - Page 3 Fittings (Shown to scale) 8x45mm Bolt x 10 8x25mm Bolt x 34 12mm Spring washer x 20 8mm Bolt x 4 17mm Flat washer x 40 Nut x 6 22mm Flat washer x 4 Note: All fittings packed inside the back of the headboard...
- Page 4 Parts INSIDE Side rail x 2 (1930 x 305mm) INSIDE FRONT Footboard x1 (1000 x 305mm) Headboard x1 (1050 x 860mm) Note: Packed inside the back of the headboard Wooden rail x2 (4'/4'6-760 x 40mm) Hinge Mechanism (x 1 pair) NOTE: PISTON ATTACHED Bentwood slats x 28 (903 x 9 x 53mm) Note: Packed inside the back...
-
Page 5: Tools Required
Tools required Ruler/tape Allen key (Supplied) measure Spanner (Supplied) Box spanner (Supplied) - Page 6 Components packed inside back of headboard Unzip WARNING! The headboard is heavy. Lift with care. 8x45mm Bolt x 10 8x25mm Bolt x 34 12mm Spring washer x 20 8mm Bolt x 4 8x25mm Bolt x 12 12mm Spring washer x 12 17mm Flat washer x 12 17mm Flat washer x 40 Nut x 6...
- Page 7 5mm Allen key x 1 Ensure frame is square...
- Page 8 8x25mm Bolt x 10 17mm Flat washer x 10 22mm Flat washer x 4 8x45mm Bolt x 4 Opening from right side 5mm Allen key x 1 Headboard fixing holes position Headboard fixing holes position Footboard fixing holes position Footboard fixing holes position...
- Page 9 8x25mm Bolt x 10 17mm Flat washer x 10 22mm Flat washer x 4 8x45mm Bolt x 4 Opening from left side 5mm Allen key x 1 Headboard fixing holes position Headboard fixing holes position Footboard fixing holes position Footboard fixing holes position...
- Page 10 Turn Product 8mm Bolt x 4...
- Page 11 8x25mm Bolt x 12 12mm Spring washer x 8 17mm Flat washer x 12 5mm Allen key x 1...
- Page 12 Nut x 6 17mm Flat washer x 6 5mm Allen key x 1 8x45mm Bolt x 6 Spanner x 1 Box spanner x 1 Important Two people required. Frame to be fully supported at all times.
- Page 13 Repeat...
