- Page 1 HATTI 150cm Ottoman Bed HATT-OK-SS20-A Width - 163.5cm Length - 214cm Height - 123cm 0344 499 4686...
- Page 2 General information Please retain your receipt as proof of If for any reason you should have purchase. problems with your Habitat product, please contact the store from which If you have any comments or suggestions regarding this product, you purchased it.
- Page 3 Important Ottoman Safety Warnings Caution. This bed uses a pressurised mechanism. Use caution when operating - Always use two hands at arm’s length, and only where illustrated on the product. You must ensure the mattress is on the bed frame before lifting the mechanism - Failure to do so may result in injury.
- Page 4 Components - Panels 0344 499 4686 Hattie Bed Baseboards x4 Slat Frame x1 Headboard x1 Footboard x1 Side Rail x2 Slat Frame x1...
- Page 5 Components - Fittings 0344 499 4686 Fittings contained in pack 2 of 4 Stick Felts x 8 Allen key x1 Gold Bolts (8*18) x8 Brackets x 8 Bolts (8*80) x 4 Bolt (8*25) x 16 uts x 12 Spanner x 1 Bolts (8*45) x 8 Belt x 1 Mattress holder x 1...
- Page 6 Assembly Instructions Step 1 A x 8...
- Page 7 Assembly Instructions Step 2 B x 1 Frame must be square...
- Page 8 Assembly Instructions Step 3 C x 8 D x 8 E x 1 6...
- Page 9 Assembly Instructions Step 4 The nuts and washers already in position on the bracket.
- Page 10 Assembly Instructions Step 5 B x 1 F x 4 G x 4...
- Page 11 Assembly Instructions Step 6 B x 1 F x 8 I x 8...
- Page 12 Assembly Instructions Step 7...
- Page 13 Assembly Instructions Step 8 K x 1...
