Summary of Contents for Freezimer HIM-35B
- Page 1 THIS INSTRUCTION CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Follow Freezimer Visit us:www.freezimer.com...
- Page 8 DESCRIPTION Buttons Upper cover Control panel Transparent lid Water tray Micro switch support Bullet evaporator Ice shovel board Motor support Ice basket Rear housing Liner Front housing Ice shovel...
-
Page 9: Control Panel Operation
CONTROL PANEL OPERATION The indicator lights in green when select small ice. SMALL The indicator lights in green when select large ice. LARGE The indicator lights in green when the ice maker is cleaning. CLEAN The indicator lights in red when the water tank is lack of water. - Page 11 Plug the ice maker into the wall outlet and press “ ” to start. NO/OFF CLEAN Press “ ” button to select the ice size, “ ” means Large ice, SELECT LARGE “ ” means Small ice. SMALL The ice-making cycle will last approximately 6-8 minutes, depending on the ambient temperature and water temperature.
- Page 12 The ” ” indicator will light up when the water tank is lack of water and the ADD WATER ice-making cycle will stop automatically. About 5 seconds later, the ice maker will restart its ice making function automatically. NO/OFF CLEAN...
- Page 13 Use a diluted solution of water and vinegar to clean the inside and outside of the ice maker. Do not spray ice maker with chemicals or diluted agents such as acids, gasoline or oil. Rinse thoroughly before starting. When the efficient and quiet ice making process is over, you need to press CLEAN button for 3 seconds to enter the self-cleaning mode.
-
Page 14: Troubleshooting
TROUBLESHOOTING 1. Please note, if a power failure occurs due to disconnection of the power cord, or the power button has been pushed off during an ice making cycle, small ice chips may form and lodge in the automatic shovel causing it to jam. If this occurs, the ice chips may be removed by disconnecting the power cord and gently pushing the shovel to the rear of the cabinet and removing the ice chips, then restarting. - Page 15 Model number: HIM-35B Daily ice output: 15kg (33lb) / 24 hours Ice storage capacity: 700g / 1.54lb (Max) Refrigerant: R600a Water tank capacity: 2.2L / 2.32qt Voltage: 120 V Frequency: 60 Hz Current: 2.2 A Max overall dimensions 14.1" X 9.65" X 11.54"...
- Page 17 Icewox This symbol indicates the refrigerant R600a and the non-metal- lic materials of the appliance are flammable. ltys a warning symbol.Warning:Risk of fire/flam- mable materials. WARNING: When positioning the appliance,ensure the supply cord is not trapped or damaged. WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance Children aged from 3to 8years are allowed to load and unload refrigerat- ingappliances.To avoid contamination of foodplease respect the follow- inginstructions.
- Page 18 E-Mail: service@freezimer.com Manufacturer: Iceplus Tech (DongGuan) Co., Ltd Iceplus Tech Industrial Zone, Room 201, No.9, Yangwu Tangxing Road, Qishi Town, Dongguan +44(0)7825478124 +49(0)211-97538868 freezimerclub Made in China...
- Page 20 www.freezimer.com...
