- Page 1 Dryspell Series Instruction Manual Desiccant Compressed Air Dryer Dryspell Series INSTALLATION, OPERATION, MAINTENANCE Regenerative Type Heatless Desiccant Dryer R1 - 06/13...
- Page 2 The condensation can lead to considerable costs (corrosion, freezing, etc.). These costs can be avoided by the application of a Dryspell Series dryer. This complete purification system includes an optional prefilter with automatic condensate drain, heatless adsorption dryer and in built afterfilter. The Dryspell...
- Page 3 1 pressure gauge 2 Mufflers Electronic auto drain Adsorbent Material The desiccant used in the dryspell series is a smooth sphere of activated alumina produced by a unique manufacturing process. The benefits of using this high performance desiccant include: Uniform ball size...
-
Page 4: Description Of Operation
Trident products. Before start-up or performing any maintenance on any Trident air dryer, filter, drain system, or other equipment, you must first turn off and disconnect all electrical power and service to the equipment at the main disconnect switch. -
Page 5: Installation And Maintenance
Dryspell Series Instruction Manual INSTALLATION AND MAINTENANCE Safety Dryspell dryers are intended for the drying of compressed air. Under no circumstance should they be used to dry other gases. The desiccants used are not toxic. However, they may cause respiratory problems if they are inhaled in dust form. - Page 6 Dryspell Series Instruction Manual Install a system of by-pass valves between the dryer inlet and outlet so the dryer can be serviced without having to interrupt the compressed air supply from the circuit (see diagram above). The upstream and downstream valves must be closed during installation.
- Page 7 Dryspell Series Instruction Manual Control Panel DS 31-200 The control panel presents all the instruments necessary to control and regulate the dryer: a machine diagram two LEDs indicating the tower in drying operation (Tower 1 and Tower 2). a LED indicating the prefilter drain operation (Drain) (for models equipped with electronic auto drain.).
- Page 8 Dryspell Series Instruction Manual Shutting Down the Dryer Follow the procedure below: Open the by-pass valve. Close the inlet valve. Close the outlet valve. Turn off power to the dryer. Adsorption dryers are robust, reliable machines. To ensure uninterrupted, problem-free operation, regularly perform the inspections below.
- Page 9 Dryspell Series Instruction Manual The total quantities required for each model are as follows (weight in kgs): Dryspell Models Quantity (Kgs) 60 A 8 Bag* 10 Bag 16 Bag 20 Bag 24 Bag 30 Bag *Bag is a special custom made desiccant cartridge. It is accurately packed and sealed with a required quantity and quality of desiccant.
- Page 10 Dryspell Series Instruction Manual LEDS not Glowing A – Check the power supply connection and tension Tower Status LED not Changing A – Change the controller LEDS Status Change but Tower not Switching A – Check coil connection at DIN and terminal connector in the controller B –...
-
Page 25: Installation
Dryspell Series Instruction Manual INSTALLATION & COMMISIONING REPORT MINI REGENERATIVE AIR DRYER Customer Model : Sl. No. : Contact person : Phone : Designation (Please add any comments or remarks here found while unpacking) 1. INSTALLATION a) Installation at :...
