- Page 1 BRiB-II™ User Guide Contact Terabeam www.terabeam.com 8000 Lee Highway Falls Church, VA 22042 Office: 703-205-0600 Fax: 703-205-0610 Sales: 1-888-297-9090 MNL-500252-001 Version 1.0 March 2005...
- Page 2 Terabeam Wireless (Terabeam) warrants that your device is free of defects in material and workmanship for a period of one year after initial purchase. Terabeam will, in this period of time, repair or replace, any Terabeam product returned to the factory, freight prepaid.
-
Page 3: Table Of Contents
Power Supply ..........................5 Hardware Installation ........................6 © 2005 Terabeam Wireless. All Rights Reserved. No part or parts of this document may be reproduced, translated, stored in any electronic retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopied, recorded or otherwise, without the prior written permission of Terabeam Wireless. -
Page 4: Overview
2.4 GHz band. Two versions of the BRiB-II are available: the standard series BRiB-II with an integral 18 dBi gain flat panel antenna, and the BRiB-II–LR with the addition of an integrated bi-directional fixed amplifier to boost range and improve reception. -
Page 5: Bridge-In-A-Box-Ii Features
Two 110/220 VAC to 48 VDC wall adapters • CD-ROM with Windows-based software and documentation A Terabeam outdoor Ethernet cable must be ordered separately. Available lengths are 50, 100, 200, or 300 feet (maximum length). The latest software and User’s Manuals can also be found at: http://www.ydi.com/support/downloads.php, and... - Page 6 BRiB-II User’s Manual Figure 1.1a – BRiB-II, 110/220 VAC Power Supply, Mounting Brackets, and DC Power Injectors Figure 1.1b – Typical Application BRiB-II Side A Antenna Point-to-Point (P-P) Link BRiB-II Side B Antenna Ver 1.0 Page 3 March 2005...
-
Page 7: Installation
“line of site” (LOS), you will likely not get a reliable, long-range wireless connection. The only way to accurately determine your coverage area is to put up the BRiB-II antennas in the best locations available and run some tests. -
Page 8: Dc Power Injector
Power Supply The BRiB-II antennas come with a 110/220 VAC to 48 VDC power supply that has a standard barrel plug [center pin positive (+) tip and outer ring negative (-)]. -
Page 9: Hardware Installation
BRiB-II User’s Manual Former BRiB-II units used a 15 VDC Power Supply. Care must be followed not to confuse the current with the former units since this may damage a former 15 VDC unit if a 48 VDC Power Supply is used with it. - Page 10 (refer to Fig. 2.5). Also, a water-proof plug is located next to the LED label. You may remove this plug to gain acces to a reset push button inside the BRiB-II for disaster recovery, or if so instructed by your Terabeam support representative during troubleshooting or technical assistance.
