Razor Blade 26D/28D
Razor Blade 28C
INSTRUCTIONS FOR USE
KENT model:
908 7099 020 - 908 7100 020 - 908 7101 020
INSTRUCTIONS D'UTILISATION
Modèle KENT:
908 7099 020 - 908 7100 020 - 908 7101 020
INSTRUCCIONES DE USO
Modelo KENT:
908 7099 020 - 908 7100 020 - 908 7101 020
INSTRUÇÕES DE USO
Modelo KENT:
908 7099 020 - 908 7100 020 - 908 7101 020
909 6457 000(2)2006-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Razor Blade 28C and is the answer not in the manual?

Questions and answers

Related Manuals for KENT Razor Blade 28C

Summary of Contents for KENT Razor Blade 28C

  • Page 1 Razor Blade 26D/28D Razor Blade 28C INSTRUCTIONS FOR USE KENT model: 908 7099 020 - 908 7100 020 - 908 7101 020 INSTRUCTIONS D’UTILISATION Modèle KENT: 908 7099 020 - 908 7100 020 - 908 7101 020 INSTRUCCIONES DE USO...
  • Page 3 7 7c 7b 7a S311212 27 29 4 31 13 S311213 909 6457 000(2)2006-11...
  • Page 4 S311214 S311215 S311216...
  • Page 5 S311217 S311218 909 6457 000(2)2006-11...
  • Page 6 S311219 S311220 S311221...
  • Page 7 S311379 909 6457 000(2)2006-11...
  • Page 8 BRUSH/PAD-HOLDER DECK OR CYLINDRICAL BRUSH DECK DISASSEMBLY/ASSEMBLY ....17 SAFETY FUNCTIONS ......................... 17 EMERGENCY STOP BUTTON ........................17 SPEED REDUCTION ............................. 17 DRIVER'S SEAT MICROSWITCH ........................17 ELECTROMAGNETIC BRAKE ........................17 TROUBLESHOOTING ........................18 SCRAPPING ............................18 Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...
  • Page 9 (A06 means January 2006). This information is useful when requiring machine spare parts. Use the following table to write down the machine identification data. MACHINE model ............MACHINE serial number ..........Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...

  • Page 10: General Instructions

    During normal operation, explosive gases are released. – Do not wear jewelry when working near electrical components. – Do not work under the lifted machine without supporting it with safety stands. Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...
  • Page 11 30° from the horizontal plane to prevent the highly corrosive acid from leaking out of the batteries. If the machine must be tilted to perform any maintenance procedures, remove the batteries. Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...

  • Page 12: Machine Description

    10a. Flow increase switch 14. Recovery water tank 10b. Flow decrease switch 15. Solution tank 11. Maximum speed adjuster (enabled only when the brushes are operating) 12. Ignition key Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...

  • Page 13: Technical Data

    70.8 in H O (1,800 mmH Machine height 49.2 in (1,250 mm) Machine maximum length 57.0 in (1,450 mm) Machine width without squeegee 26.8 in (681.5 mm) 30.0 in (758 mm) Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...

  • Page 14: Wiring Diagram

    Pump fuse (if equipped) Grey Ignition switch Orange LD1: Drive system electronic board diagnostic warning light Pink Left brush motor Right brush motor Violet Vacuum system motor White Yellow Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...

  • Page 15: Electrical Fuses

    One 24 V battery box, 240 Ah/C5 (WET) – One 24 V battery box, 240 Ah/C5 (GEL) (optional) – 4 6 V batteries, 180 Ah C5 (WET) – 4 6 V batteries, 180 Ah C5 (GEL) Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...

  • Page 16: Battery Installation And Battery Type Setting (Wet Or Gel)

    For battery choice and installation, apply to qualified battery Retailers. Set the machine and the battery charger according to the type of batteries installed (WET or GEL). Install the batteries. Charge the batteries. Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...

  • Page 17: Before Start-Up

    Operator's position adjustment 19. Using the lever (1, Fig. C), adjust the inclination of the steering wheel (2) to reach a comfortable position. Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...

  • Page 18: Machine Start And Stop

    Fig. B) to “0”. Restart the machine by turning 10. Lift the brush/pad-holder deck and the squeegee by the ignition key to “I”. pressing the switch (6, Fig. B). Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...
  • Page 19 (optional)]. FIRST PERIOD OF USE After the first 8 hours, check the machine fastening and connecting parts for proper tightening. Check the visible parts for integrity and leakage. Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...

  • Page 20: Scheduled Maintenance Table

    Drive system motor carbon brush check or replacement (1): After the first 8 working hours (2): This maintenance procedure must be performed by a KENT authorized Service Center Razor Blade 26D/28D – Razor Blade 28C — 909 6457 000(2)2006-11...

This manual is also suitable for:

Razor blade 26dRazor blade 28d908 7099 020908 7100 020908 7101 020

Table of Contents
