- Page 1 Installation Guide Kitchen Sinks L20513-00-PDS, L20515-00-PDS, L20857-00-PDS 1369514-2-A...
-
Page 2: Tools And Materials
Thank You For Choosing Kallista We appreciate your commitment to KALLISTA quality products. Please take a moment to review this manual before you install your KALLISTA product. If you encounter any installation or performance problems, please do not hesitate to contact us at the phone number listed on the back cover. - Page 3 Plan the sink installation so future removal from underneath the countertop is possible without damaging the countertop. Do not use adhesive sealants. For L20513-00-PDS Only: This sink is intended for installation into a standard 24″ (610 mm) base cabinet. For L20515-00-PDS Only: This sink is intended for installation into a standard 30″...
- Page 4 B = Top of Cabinet to Top of Doors IMPORTANT! Before installing this sink, verify that: • The opening height (A) is less than the apron height. • The distance to the top of the doors (B) is greater than the apron height. Roughing-In 1369514-2-A Kallista...
- Page 5 Remove the false drawer front from your cabinet. Carefully cut away the top rail and center support. Notch the cabinet as shown, so the top of the sink is flush with the top of the cabinet when installed. Kallista 1369514-2-A...
- Page 6 Secure the supports with construction adhesive and screws (not provided). Cut four lengths of support framing to extend from the bottom of the installed supports to the floor of the cabinet. Secure the vertical supports with construction adhesive and screws (not provided). 1369514-2-A Kallista...
- Page 7 Remove the sink. Apply a bead of 100% silicone sealant to the top of each support. Lower the sink onto the supports and push in to ensure the apron is flush to the front of the cabinet. Kallista 1369514-2-A...
- Page 8 4. Install the Countertop Apply a bead of 100% silicone sealant around the side and back of the sink. Install the countertop. Apply a thin bead of 100% silicone sealant where the sink meets the countertop and cabinet. 1369514-2-A Kallista...
- Page 9 1-5/8" (41 mm) 5. Secure the Sink NOTE: Anchors are pre-installed by the countertop manufacturer. Install the clips to the countertop and ensure each clip engages the rim. Tighten evenly. Wipe away any excess sealant. Kallista 1369514-2-A...
-
Page 10: Complete The Installation
Apply 100% silicone sealant. 6. Complete the Installation Apply 100% silicone sealant where the sink meets the countertop. Immediately wipe away any excess. Install the faucet and strainers according to the installation instructions. Connect the trapway to the strainers. 1369514-2-A Kallista... - Page 11 1369514-2-...
- Page 12 USA/Canada: 1-888-4-KALLISTA Fax: 1-888-272-3094 kallista.com ©2018 KALLISTA 1369514-2-A...
