SERVICE INSTRUCTIONS
& ASSEMBLY DRAWINGS
TECH CONTROL VALVES
(TECH, TECH-CS, TECH-EE, TECH-TC)
F I L T E R S , S O F T E N E R S , C O N D I T I O N E R S
1 INCH TECH SERIES CONTROL VALVE MODEL: WS1
1.25 INCH TECH SERIES CONTROL VALVE MODEL: WS1.25
1 INCH TECH-CS SERIES CONTROL VALVE MODEL: WS1CS
1.25 INCH TECH-CS SERIES CONTROL VALVE MODEL: WS1.25CS
1 INCH TECH-EE SERIES CONTROL VALVE MODEL: WS1EE
1.25 INCH TECH-EE SERIES CONTROL VALVE MODEL: WS1.25EE
1 INCH TECH-TC SERIES CONTROL VALVE MODEL: WS1TC
1.25 INCH TECH-TC SERIES CONTROL VALVE MODEL: WS1.25TC
t
e c h n o l o g i e S
FOR
, i
.
n c
S E R V I C E
M A N U A L
NOVEMBER 2022
Advertisement
Table of Contents
Related Manuals for SWT TECH Series
Summary of Contents for SWT TECH Series
- Page 1 F I L T E R S , S O F T E N E R S , C O N D I T I O N E R S 1 INCH TECH SERIES CONTROL VALVE MODEL: WS1 1.25 INCH TECH SERIES CONTROL VALVE MODEL: WS1.25 1 INCH TECH-CS SERIES CONTROL VALVE MODEL: WS1CS 1.25 INCH TECH-CS SERIES CONTROL VALVE MODEL: WS1.25CS...
-
Page 2: Table Of Contents
Page 2 Table of Contents 3. Introduction General Warnings Specifications Quick Reference Specifications 5. Control Valve Function 5. Control Valve Components Drive Assembly Drive Cap Assembly, Main Piston, and Regenerant Piston Spacer Stack Assembly Injector Cap, Screen, Injector Plug, and Injector Refill Flow Control Assembly or Refill Port Plug Drain Line Flow Control and Fitting Assembly Water Meter or Meter Plug... -
Page 3: Introduction
Exposure to such hydrocarbons may cause the products to leak. DO NOT USE the product(s) contained in this document on water supplies that contain hydrocarbons such as kerosene, benzene, gasoline, etc. The Tech Series water meter should not be used as the primary monitoring device for critical or health • effect applications. -
Page 4: Specifications
Page 4 Table 1 Specifications Minimum / Maximum Operating Pressures 20 psi (138 kPa) to 125 psi (862 kPa or 8.6 bar) Minimum / Maximum Operating Temperatures 40°F (4°C) to 110°F (43°C) AC Adapter U.S. International Supply Voltage 100-120 VAC 100-240 VAC Supply Frequency 50/60 Hz... -
Page 5: Control Valve Function
(or equivalent) fully automatic control valve is designed as the primary control center to direct and regulate all cycles of a water softener or filter. When the Tech Series control valve is manufactured as a softener, the control valve can be ordered to perform downflow or upflow regeneration. When the Tech Series control valve is set up as a filter, the control valve can be set to perform downflow regeneration or simply backwash. -
Page 6: Drive Assembly
Page 6 Drive Assembly The drive assembly consists of the following parts: 1. Drive Bracket 2. Printed Circuit (PC) Board 3. Motor 4. Drive Gears 5. Drive Gear Cover The drive bracket holds the PC board, the motor, the drive gears, and the drive gear cover in place. The PC board receives and retains information, displays the information, determines when to regenerate, and initiates regeneration. -
Page 7: Injector Cap, Screen, Injector Plug, And Injector
Page 7 Injector Cap, Screen, Injector Plug, and Injector The screen, injector, and/or injector plug(s) are installed under the injector cap in an easy-to-access location on top of the valve. The injector cap contains four slots so no water accumulates in the cap. The injector cap is designed to be hand tightened. -
Page 8: Refill Flow Control Assembly Or Refill Port Plug
Page 8 Refill Flow Control Assembly or Refill Port Plug The refill flow control assembly consists of an elbow, flow control retainer, and flow control washer. The flow control retainer fits in the elbow. The flow control retainer houses the flow control washer which controls the flow rate when the regenerant tank is being refilled. -
Page 9: Water Meter Or Meter Plug
Control valves without meters should only be set up for time clock operation (i.e. no water meter, no demand-initiated regeneration). Control valves with water meters provide a wider variety of useful information. See Operation & Instruction Manuals for more information concerning specific Tech Series Control Valves. Mixing Valve (Optional) The mixing valve is installed on the outlet side of the control valve. -
Page 10: Installation Fitting Assemblies
Page 10 Installation Fitting Assemblies The installation fittings are used to connect the optional bypass or the control valve to the plumbing system. See pages 33 to 36 for available fitting assemblies. The installation fitting assemblies are sold in pairs and consist of two fittings, two nuts, two split rings, and two o-rings. The installation fitting assemblies and the bypass valve are sold separately from the control valve. -
Page 11: Bypass Valve Operation
Page 11 Bypass Valve Operation Figure 1. NORMAL OPERATION FIgure 2. BYPASS OPERATION Figure 3. DIAGNOSTIC MODE FIgure 4. SHUT OFF MODE... -
Page 12: Installation
Page 12 Installation Allow one foot of clearance to service the control valve. The control valve will withstand transportation and storage temperatures of -13°F (-25°C) to 131°F (55°C), and for short periods up to 158°F (70°C). If the control valve has been exposed to freezing conditions, let the valve warm up to room temperature before running water through it. The control valve has been packaged to prevent damage from the effects of normal humidity, vibration, and shock. - Page 13 Page 13 Installation Fitting Assemblies The installation fittings connect to the control valve or the bypass valve using nuts that only require hand tightening. Hand tightened nut connections between the control valve and installation fittings, the control valve and bypass valve, and the bypass valve and installation fittings allow for easy serviceability.
-
Page 14: Service Instructions
Page 14 Service Instructions NOTE: When servicing the control valve, water may leak from the valve. Water from the valve may create a slip hazard. Clean up ALL water spills. ALWAYS disconnect the control valve from electrical power prior to servicing the valve. Drive Assembly Remove the valve cover to access the drive assembly. - Page 15 SET.) 2. For all other Tech Series valves, press and hold NEXT and REGEN buttons for three seconds. This resets the electronics and establishes the service piston position. The display should flash all wording, then flash the software version, and then reset the valve to the service position.
- Page 16 3 seconds. (The cover button may have other names like SET HOUR, CLOCK, or SET CLOCK, but the circuit board is labeled with SET.) 2. For all other Tech Series valves, press and hold NEXT and REGEN buttons for 3 seconds. This resets the electronics and establishes the service piston position. The display should flash all wording, then flash the software version, and then reset the valve to the service position.
- Page 17 Page 17 Table 5. Valve Body Compliance Table Main Regenerant Application Injector and/or Plug(s) Stack Body * Piston Piston LC-V3001 LC-V3001-01 (QC1) 1 inch Downflow Softener Injector in DN hole, LC-V3011 LC-V3174 LC-V3005-02 LC-V3001-02 (Mixing) or Regenerating Filter Plug in UP hole LC-V3001-04 (QC2) LC-V3001-06 (Mixing QC2) LC-V3001 LC-V3001-01 (QC1)
- Page 18 Page 18 Refill Flow Control Assembly or Refill Port Plug To clean or replace the refill flow control, pull out the elbow locking clip and then pull straight up on the elbow. Replace the elbow locking clip in the slot so that it is not misplaced. Twist to remove the white flow control retainer. The flow control can be removed by prying upward through the side slots of the retainer with a small flat blade screwdriver.
- Page 19 3 seconds. (The cover button may have other names like SET HOUR, CLOCK, or SET CLOCK, but the circuit board is labeled with SET.) 2. For all other Tech Series valves, press and hold NEXT and REGEN buttons for 3 seconds. This resets the electronics and establishes the service piston position. The display should flash all wording, then...
- Page 20 Page 20...
-
Page 21: Drawings And Part Numbers
Page 21 Drawings and Part Numbers... -
Page 22: Ws1 & Ws1.25 Front Cover And Drive Assembly
Page 22 WS1 & WS1.25 Front Cover and Drive Assembly Drawing No. Part No. Description Quantity LC-V3175-01 WS1 Front Cover Assembly LC-V3107-01 WS1 Motor LC-V3002-A WS1 Drive Bracket Assembly LC-V3108-11BOARD WS1 PC Board XMEGA Replacement LC-V3110 WS1 Drive Reducing Gear 12 x 36 LC-V3109 WS1 Drive Gear Cover LC-V3186-06... -
Page 23: Ws1Cs & Ws1.25Cs Front Cover And Drive Assembly
Page 23 WS1CS & WS1.25CS Front Cover and Drive Assembly Drawing No. Part No. Description Quantity LC-V3175-01 WS1 Front Cover Assembly LC-V3107-01 WS1 Motor LC-V3002-A WS1 Drive Bracket Assembly LC-V3108CS-03BOARD WS1CS/WS1.25CS PC Board XMEGA SMT Replacement LC-V3110 WS1 Drive Reducing Gear 12 x 36 LC-V3109 WS1 Drive Gear Cover Not Shown... -
Page 24: Ws1Ee & Ws1.25Ee Front Cover And Drive Assembly
Page 24 WS1EE & WS1.25EE Front Cover and Drive Assembly Drawing No. Part No. Description Quantity LC-V3175EE-01 WS1EE Front Cover Assembly LC-V3107-01 WS1 Motor LC-V3002-A WS1 Drive Bracket Assembly LC-V3408EE-04BOARD WS1EE thru WS2EE PC Board 5-Digit Replacement LC-V3110 WS1 Drive Reducing Gear 12 x 36 LC-V3109 WS1 Drive Gear Cover LC-V3186-06... -
Page 25: Ws1Tc & Ws1.25Tc Front Cover And Drive Assembly
Page 25 WS1TC & WS1.25TC Front Cover and Drive Assembly Drawing No. Part No. Description Quantity LC-V3175TC-01 WS1TC Front Cover Assembly LC-V3107-01 WS1 Motor LC-V3002-A WS1 Drive Bracket Assembly LC-V3818TC-01BOARD WS1TC/WS1.25TC PC Board 4-Digit Replacement LC-V3110 WS1 Drive Reducing Gear 12 x 36 LC-V3109 WS1 Drive Gear Cover LC-V3186-06... -
Page 26: Ws1 Drive Cap Assembly, Downflow Piston, Upflow Piston, Regenerant Piston, And Spacer Stack Assembly
Page 26 WS1 Drive Cap Assembly, Downflow Piston, Upflow Piston, Regenerant Piston, & Spacer Stack Assembly Drawing No. Part No. Description Quantity LC-V3005-02 WS1 Spacer Stack Assembly LC-V3004 Drive Cap Assembly LC-V3178 WS1 Drive Backplate LC-V3011 * WS1 Piston Downflow Assembly LC-V3011-01 * WS1 Piston Upflow Assembly LC-V3174 WS1 Regenerant Piston... -
Page 27: Ws1.25 Drive Cap Assembly, Downflow Piston, Upflow Piston, Regenerant Piston, And Spacer Stack Assembly
Page 27 WS1.25 Drive Cap Assembly, Downflow Piston, Upflow Piston, Regenerant Piston, & Spacer Stack Assembly Drawing No. Part No. Description Quantity LC-V3430-01 WS1.5 Spacer Stack Assembly LC-V3004 Drive Cap Assembly LC-V3178 WS1 Drive Backplate LC-V3407 WS1.25/1.5 Piston Downflow Assembly (amber) LC-V4042 WS1.25/1.5 Piston Upflow Assembly (black) LC-V3174 WS1 Regenerant Piston LC-V3135 O-ring 228... -
Page 28: Injector Cap, Injector Screen, Injector, Plug, And O-Ring
Page 28 Injector Cap, Injector Screen, Injector, Plug, and O-Ring Drawing No. Part No. Description Quantity LC-V3176 Injector Cap LC-V3152 O-ring 135 LC-V3177-01 Injector Screen Cage LC-V3010-1Z WS1 Injector Assembly Z Plug LC-V3010-1A WS1 Injector Assembly A Black LC-V3010-1B WS1 Injector Assembly B Brown LC-V3010-1C WS1 Injector Assembly C Violet LC-V3010-1D... -
Page 29: Refill Flow Control Assembly And Refill Port Plug
Page 29 Refill Flow Control Assembly and Refill Port Plug Drawing No. Part No. Description Quantity LC-V3195-01 WS1 Refill Port Plug Assembly LC-H4615 Elbow Locking Clip LC-H4628 Elbow 3/8 inch Brine Quick Connect LC-V3163 O-ring 019 LC-V3165-01 ** WS1 Refill Flow Control Retainer Assembly (0.5 gpm) LC-V3182 WS1 Refill Flow Control (0.5 gpm) LC-V4144-01 Elbow 3/8 inch Brine Quick Connect with Refill Flow Control Not Shown LC-V3552 WS1 Brine Elbow Assembly with Refill Flow Control Optional... -
Page 30: Drain Line - 3/4 Inch
Page 30 Drain Line – 3/4 Inch Drawing No. Part No. Description Quantity LC-H4615 Elbow Locking Clip LC-PKP10TS8-BULK Polytube Insert 5/8 inch Optional LC-V3192 WS1 Nut 3/4 inch Drain Elbow Optional LC-V3158-01 WS1 Drain Elbow 3/4 inch Male with Silencer LC-V3158-02 WS1 Drain Elbow 3/4 inch Male without Silencer LC-V3163... -
Page 31: Drain Line - 1 Inch
Page 31 Drain Line – 1 Inch Drawing No. Part No. Description Quantity LC-H4615 Elbow Locking Clip LC-V3166 WS1 Drain Fitting Body 1 inch LC-V3166-01 WS1 Drain Fitting Body Female 1 inch LC-V3167 WS1 Drain Fitting Adapter 1 inch LC-V3163 O-ring 019 LC-V3150 WS1 Split Ring... -
Page 32: Water Meter, Meter Plug, And Mixing Valve
Page 32 Water Meter, Meter Plug, and Mixing Valve Drawing No. Part No. Description Quantity LC-V3151 WS1 Nut 1 inch Quick Connect LC-V3003 * WS1 Meter Assembly LC-V3118-01 WS1 Turbine Assembly LC-V3105 O-ring 215 LC-V3003-01 WS1 Meter Plug Assembly LC-V3013 Mixing Valve Optional * Drawing Number Parts 3 and 4 included with assembly: Part No. -
Page 33: Installation Fitting Assemblies
Page 33 Installation Fitting Assemblies Part No: LC-V3007 Part No: LC-V3007-01 Description: WS1 Fitting 1 Inch Description: WS1 Fitting 3/4 Inch and 1 inch PVC Male NPT Elbow Assembly PVC Solvent 90 degree Assembly Drawing Drawing Part No. Description Qty. Part No. - Page 34 Page 34 Installation Fitting Assemblies Part No: LC-V3007-04 Part No: LC-V3007-05 Description: WS1 Fitting 1 Inch Description: WS1 Fitting 1-1/4 Inch Plastic Male NPT Assembly Plastic Male NPT Assembly Drawing Drawing Part No. Description Qty. Part No. Description Qty. LC-V3151 WS1 Nut 1 inch Quick Connect LC-V3151 WS1 Nut 1 inch Quick Connect...
- Page 35 Page 35 Installation Fitting Assemblies Part No: LC-V3007-08 Part No: LC-V3007-09LF Description: WS1 Fitting 1-1/4 Inch Description: WS1 Fitting 1-1/4 Inch and 1-1/2 inch Plastic Male BSPT Assembly Brass Sweat Assembly Lead Free * Drawing Drawing Part No. Description Qty. Part No.
- Page 36 Page 36 Installation Fitting Assemblies Part No: LC-V3007-14 Part No: LC-V3007-15 Description: WS1 Fitting 3/4 Inch Description: WS1 Fitting 3/4 Inch Plastic Male BSPT Assembly John Guest Quick Connect 90° Assembly Drawing Drawing Part No. Description Qty. Part No. Description Qty.
-
Page 37: Bypass Valve
Page 37 Bypass Valve Drawing No. Part No. Description Quantity LC-V3151 WS1 Nut 1 inch Quick Connect LC-V3150 WS1 Split Ring LC-V3105 O-ring 215 LC-V3145 WS1 Bypass 1 inch Rotor LC-V3146 WS1 Bypass Cap LC-V3147 WS1 Bypass Handle LC-V3148 WS1 Bypass Rotor Seal Retainer LC-V3152 O-ring 135 LC-V3155... -
Page 38: Flow Diagrams - Service And Backwash
Page 38 Flow Diagrams – Service and Backwash Flow Diagram – Service Flow Diagram – Backwash... - Page 39 Page 39 Flow Diagrams – Downflow and Upflow Flow Diagram – Downflow Brine Flow Diagram – Upflow Brine...
-
Page 40: Flow Diagrams - Rinse And Fill
Page 40 Flow Diagrams – Rinse and Fill Flow Diagram – Rinse Flow Diagram – Fill... -
Page 41: Ws1 Service Spanner Wrench
Page 41 WS1 Service Spanner Wrench (Part No. LC-V3193-02) Although no tools are necessary to assemble or disassemble the valve, the WS1 Service Spanner Wrench (shown in various positions on the valve) may be purchased to aid in assembly or disassembly. Loosens and Tightens Injector and Bypass Caps Loosens and Tightens... -
Page 42: Injector Graphs Us Units: Injector Draw, Slow Rinse, And Total Flow Rates
Page 42 Injector Graphs US Units: Injector Draw, Slow Rinse, and Total Flow Rates Black, Part No. LC-V3010-1A Brown, Part No. LC-V3010-1B US Units US Units Violet, Part No. LC-V3010-1C Red, Part No. LC-V3010-1D US Units US Units White, Part No. LC-V3010-1E Blue, Part No. - Page 43 Page 43 Injector Graphs US Units: Injector Draw, Slow Rinse, and Total Flow Rates Yellow, Part No. LC-V3010-1G Green, Part No. LC-V3010-1H US Units US Units Orange, Part No. LC-V3010-1I Light Blue, Part No. LC-V3010-1J US Units US Units Light Green, Part No. LC-V3010-1K US Units...
-
Page 44: Injector Graphs Metric Units: Injector Draw, Slow Rinse, And Total Flow Rates
Page 44 Injector Graphs Metric Units: Injector Draw, Slow Rinse, and Total Flow Rates Black, Part No. LC-V3010-1A Brown, Part No. LC-V3010-1B Metric Units Metric Units Violet, Part No. LC-V3010-1C Red, Part No. LC-V3010-1D Metric Units Metric Units White, Part No. LC-V3010-1E Blue, Part No. - Page 45 Page 45 Injector Graphs Metric Units: Injector Draw, Slow Rinse, and Total Flow Rates Yellow, Part No. LC-V3010-1G Green, Part No. LC-V3010-1H Metric Units Metric Units Orange, Part No. LC-V3010-1I Light Blue, Part No. LC-V3010-1J Metric Units Metric Units Light Green, Part No. LC-V3010-1K Metric Units...
-
Page 46: Ws1 & Ws1.25 Identification
Page 46 WS1 & WS1.25 Identification WS1 with 1.050 inch Riser Port Identification Spacer Color: Grey 1.25 inch Black Plug 1.25 inch NOTE: The WS1 downflow piston is a solid amber color. The WS1 upflow piston is black and amber. WS1.25 with 1.32 inch Riser Port Identification Spacer Color: Black 1.5 inch... - Page 47 SWT’s obligation to Dealer under this Limited Warranty shall be limited, at its option, to replacement or repair of any Softener and Filter Control Valve covered by this Limited Warranty. Prior to returning a Control Valve, Dealer must obtain a return goods authorization number from SWT and return the Control Valve freight prepaid. If any Control...
- Page 48 Page 48 FORM TECH1-SERVICE S A F E W A T E R T E C H N O L O G I E S , I N C . EFFECTIVE 9 9 6 B L U F F C I T Y B O U L E V A R D , E L G I N , 6 0 1 2 0...
