- Page 1 8”x 8” Planer Thicknesser 10”x 10” Planer Thicknesser 01558 01557 Please read and fully understand the instructions in this manual before operation. Keep this manual safe for future reference.
-
Page 2: Table Of Contents
Pg.14 Operating Instructions Pg.16 Wiring Diagram Pg.17 Maintenance Pg.19 Troubleshooting Pg.20 01557 8" Planer Thicknesser Exploded View Pg.21 01557 8" Planer Thicknesser Part List Pg.25 01558 10" Planer Thicknesser Exploded View Pg.27 01558 10" Planer Thicknesser Part List Pg.30 UK Declaration of Conformity... -
Page 3: Product Specification
PRODUCT SPECIFICATION PLANING 01557 8 x 8 Planer / 01558 10 x 10 Planer / Thicknesser Thicknesser Planer Width 204mm 252mm Planer Length 740mm 920mm Max Cutting Depth 2.5mm 2.5mm Fence Tilt 90 - 135 90 - 135 Table Width... -
Page 4: Safety Symbols
SAFETY SYMBOLS & SAFETY INSTRUCTIONS Danger / Caution: Indicates risk of personal injury and/or the possibility of damage. Warning: Risk of electrical injury or damage. Note: Supplementary information. SAFETY INSTRUCTIONS WARNING: When using electric tools, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury, including the following. - Page 5 SAFETY INSTRUCTIONS Cont. (10) Don't abuse cables - Never carry a tool by its cable , or "yank" the cable to disconnect from a socket. - Keep cable away from heat, oil and sharp edges. - Do not abuse the lead. (11) Don't overreach (12) Keep proper footing and balance at all times.
- Page 6 SAFETY INSTRUCTIONS Cont. (40) Tools equipped with chip collection and extractor hoods shall be connected to the dust and chip- collecting device. (41) Use the tool only for wood or similar materials. When the blade is abraded 95%, you must change it to the new one, which must meet EN / UK standards. (43) Two persons are required for moving round the workshop due to its heavy weight.
-
Page 7: Electrical Connection
Connecting to the power supply: The 01557 / 01558 Planer Thicknesser are fitted with a standard 230V ~ 13 amp type plug. Before every usage, inspect the mains lead and plug to ensure that neither are damaged. If any damage is visible have the welder inspected / repaired by a suitably qualified person. -
Page 8: Guarantee
GUARANTEE This SIP Planer Thicknessers are covered by a 12 month parts and labour warranty covering failure due to manufacturers defects. This does not cover failure due to misuse or operating the product outside the scope of... -
Page 9: Getting To Know Your Planer Thicknesser
GETTING TO KNOW YOUR PLANER THICKNESSER Item No Description Item No Description Overload Planing Blade Guard Assembly Adjustor NVR On / Off Inter– Lock Switch Tongue Adjustment Screw M6 Hand Knob Thicknessing Crank Handle Extraction Chute with Expander Planing Cut Adjustment Knob Guard Pivot Bolt Infeed Table Outfeed Table... -
Page 10: Assembly
ASSEMBLY The planers weigh approximately 24 & 28Kgs respectively, when completely assembled. The planer must be installed in a place with ample lighting and correct power supply. To install planter: Make sure there is plenty of room for moving the work-piece through the entire cut. There must be enough room that neither the operators nor the bystanders will have to stand in line with the wood while using the tool. - Page 11 ASSEMBLY Cont. Fig.2 2. Attaching The Table Adjustment Handle Slide the table handle on to the shaft. Fig.2 3. Attaching the Dust Collector Chute. Fig.3 IMPORTANT: Please note that the Dust Chute must always be in place, the machine will not operate if is removed.
- Page 12 ASSEMBLY Cont. . For Thicknessing Remove the Angle Fence (8). Push the Cutter Guard (9) out of its holder so that the Chute (5) may be attached to the table. Ensure both Inter-Locking Tongue keys (3) are pushed firmly into the slots in the table. Note: The Planer Thicknesser will not run without the extractor chute fitted correctly The machine is fitted with 2 inter-locking safety switches.
- Page 13 ASSEMBLY Cont. 4. Attaching the Cutter Guard System 1. Place the pivot screw (X) in the position. Use this to lock the guard arm. 2. Screw in the Angle Adjusting hand-wheel (Y). 3. Use the two Thumb screws (Z) for fine angle adjustment. 5.
-
Page 14: Operating Instructions
OPERATING INSTRUCTIONS DUST EXTRACTION REQUIRED! Make sure that the switch is in off position before adjusting the cutting depth, replacing or adjusting the blades. Make sure the blade screws are securely tightened and the table is free of nails, screws and staples etc., before use. - Page 15 OPERATING INSTRUCTIONS Cont. PLANING 1. The cutting depth is set by the knob (13) & gauge (15) at the infeed table. We recommend a depth of cut of no more than 1mm and no less than 0.5mm. The maximum depth of cut is 2mm. 2.
-
Page 16: Wiring Diagram
OPERATING INSTRUCTIONS Cont. Fig.C General Information: For best results try to plane / thickness following the grain. This will reduce the amount of further finishing required. For rough sawn timber requiring finishing on all 4 sides:- Set the machine for planing. Identify the flattest of the two wider faces on the timber. -
Page 17: Maintenance
Blades must always be fitted as a pair, and must be of the same type, only fit blades recommended by SIP Industrial Products Ltd. First, ensure the machine is switched OFF and isolated from the mains supply. - Page 18 MAINTENANCE Cont. NOTE: It is recommended that sharpening is done professionally, using a jig, as blades must be sharpened as a pair to ensure they are correctly balanced. This avoids the possibility of vibration due to unbalanced cutters rotating at speed. Fig.
-
Page 19: Troubleshooting
TROUBLESHOOTING Cause Remedy Problem Machine does not start Blown Fuse Replace Fuse Loose switch terminal Inspect back of switch Faulty switch Replace switch Guard not fitted Re-fit the plastic guard ensuring it connects with the interlock switch Only starts when Green Faulty switch Replace switch button is held down... - Page 20 EXPLODED VIEW 01557 8" PLANER THICKNESSER...
- Page 21 PARTS LIST DESCRIPTION Elastic cylindrical pin Striker plate lock shaft Hex Nut Striker plate left support Philips Screw and spring Hex nut Lock handle Striker plate angle pointer Striker plate support body 10 Striker palte right support 11 Hex screw 12 Hex screw 13 Philips screw and flat washer 14 Hexagon socket head cap...
- Page 22 PARTS LIST Cont. Description 46 Plane cutter 47 Fixed worktable 48 Travel switch 49 Switch hanger 50 Philips screw and spr, flat washer assy 51 Work table adjustment handle 52 Work table adjustment screw 53 Work table adjustment screw support 54 Table pointer 55 Self-locking nuts 56 Belleville spring...
- Page 23 PARTS LIST Cont. Description 91 7 tooth sprocket (08A) 92 Small flat washer 93 Opening ring 94 Motor ribbed pulley 95 Double screw1 96 Switch box bottom 97 overcurrent protective device 98 Switch box cover 99 Switch 100 Over-current protector nut 101 Triangle capacitance 102 Motor end support plate 103 Cross head screws...
- Page 24 PARTS LIST Cont. Description 136 Pressure planing pointer 137 Driven screw 138 Drive screw 139 Hex screw 140 Chain 141 Sprocket up tight shelf 142 Flat washer 143 8 tooth rounf hole sprocket (05B) 144 Opening ring 145 8 tooth rounf hole sprocket (05B) 146 Base 147 Knife 148 Knife shaft...
- Page 25 EXPLODED VIEW 01558 10" PLANER THICKNESSER...
- Page 26 PARTS LIST DESCRIPTION DESCRIPTION...
- Page 27 PARTS LIST Cont. DESCRIPTION DESCRIPTION Handle...
- Page 28 NOTES...
- Page 29 NOTES...
-
Page 30: Uk- Declaration Of Conformity
England As the manufacturer within the UK, England, Scotland & Wales, declare that the 8”x 8” Planer Thicknesser - SIP Part. No. 01557 10" x 10" Planer Thicknesser - SIP Part No. 01558 Conforms to the requirements of the following directive(s), as indicated. -
Page 31: Eu Declaration Of Conformity
England s the manufacturer's authorised representative within the EC declare that the 8”x 8” Planer Thicknesser - SIP Part. No. 01557 10" x 10" Planer Thicknesser - SIP Part No. 01558 Conforms to the requirements of the following directive(s), as indicated. - Page 32 Please dispose of packaging for the product in a responsible manner. It is suitable for recycling. Help to protect the environment, take the packaging to the local amenity tip and place into the appropriate recycling bin. Never dispose of electrical equipment or batteries in with your domestic waste.
