NETGEAR ProSafe GSM7248 Brochure

• Help is there when you need it!
NETGEAR provides 24x7
technical support* in English,
with selected local language
support during office hours.
Powerful
Easy to Use
Manageable
Outstanding
GSM7248
ProSafe™ 48 Port Gigabit
L2 Managed Switch
High-Speed, Layer 2 Managed Gigabit Switching
NETGEAR delivers wirespeed Gigabit performance and a full set of Layer 2 management features with
unsurpassed affordability. This next-generation, high-speed switch delivers maximum throughput where
you need it — to high-performance workgroups at the edge of the network, or as a backbone for Fast
Ethernet switches and high-speed servers in demanding small networks. The non-blocking design offers
full Gigabit throughput simultaneously to all 48 10/100/1000 ports to ensure reliable performance.
Flexible fiber connectivity is enabled through four combination Small Form-factor Pluggable (SFP**)
gigabit interfaces. Layer 2 management functionality delivers reliability, control, and availability.
The very affordable NETGEAR ProSafe 48 Port Gigabit L2 Managed Switch GSM7248 creates a more
productive — and future-proof — network. With increasing bandwidth requirements from applications
such as voice, video, database management, and other services that slow throughput and response
time, you can unleash your network and enable maximum productivity with Gigabit Ethernet for today's
high-performance environments. Optimize bandwidth, security, and control with full Layer 2 management
capabilities. Network administrators can use any combination of these features to ensure uptime, availability,
bandwidth and throughput.
A full 48 10/100/1000 ports and a non-blocking design provide wire speed throughput and maximum bandwidth
for the most demanding network environments. Small Form-factor Pluggable (SFP) modules deliver choice
in 1000Base-SX, 1000Base-LX or 1000Base-ZX (70Km) optics. The Layer 2 management features optimize
bandwidth throughout the network – delivering Gigabit performance to systems, applications, and services.
Take advantage of forwarding rates up to 71.4 million pps, and a switching capacity of 96 Gbps.
Move up to Gigabit power in minutes. Use the GSM7248 as a managed switch out of the box – just plug
and play! All ports are auto-negotiating and support Auto Uplink™ technology. Choose from two easy to
use management interface options –Web interface or a command line interface available through console or
Telnet. Comprehensive remote administration capabilities reduce the need for on-site administration. Easy
to troubleshoot – built-in testing capability locates cable related network problems.
Meet your management needs with SNMP (v1, v2c and v3), RMON, Command-Line Interface (CLI) and
complete Web-based GUI. Advanced features include up to 512 VLANs, DiffServ traffic prioritization and
802.1p (QoS) for Voice over IP services (VoIP), broadcast storm protection, RADIUS, 802.1x, port trunking,
rapid spanning tree, and link aggregation. Full Layer 2 implementation allows you to configure your network
for maximum performance, reliability, and availability. Manageable with any popular SNMP-based management
software, but optimized for NETGEAR ProSafe Network Management Software NMS100.
Layer 2 management and full Gigabit power at a compelling price. Use at the edge to improve workgroup
connections, or at the core to upgrade a Gigabit Ethernet backbone — now you can afford the power your
network deserves. Like all NETGEAR products, everything you need is in the box – including rack mount kit,
power and serial cables, and more
** Use with AGM731F 1000Base-SX SFP module, AGM732F 1000Base-LX SFP module or the AGM733 1000Base-ZX (70Km) SFP module.
FVX538 ProSafe™
VPN Firewall 200
Internet
Broadband
modem
PDA
WG302
ProSafe 802.11g
Wireless Access Point
Wireless Notebook PC's
with WG511T Wireless Adapters
.
GSM7248 ProSafe™ 48 Port
Gigabit L2 Managed Switch
Servers with
GA311 Gigabit Cards
Notebook PC's with GA511 Gigabit Cards
NMS100 ProSafe™ Network
Management Software
Everybody 's connecting. ™
ProSafe™ NMS100
Software CD Instructions:
Version 1.0 This CD should automatically
run when inserted into your
CD-ROM drive. If the CD
does not start automatically,
browse to the CD drive and
click on NMSsetup.exe
ALL RIGHTS RESERVED © 2004 NETGEAR, INC.
© 2004 NETGEAR, Inc. 240-10041-01
All rights reserved
240-10129-01
Desktop PC's with GA311 Gigabit Cards
