Summary of Contents for Officine Gullo BBS4G
- Page 1 INSTRUCTIONS FOR INSTALLATION AND USE BBS4G - BBS8G GAS BARBECUE FOR RESIDENTIAL AND PROFESSIONAL USE...
- Page 2 14. In case of failure or malfunction, turn the appliance off, close the gas supply valve and do not attempt to carry out any repairs, which must be done exclusively by an authorized service center. Request the use of original spare parts only. Failure to comply with the above recommendations may compromise the appliance’s safety. Officine Gullo...
-
Page 3: Table Of Contents
WHAT TO DO IN THE EVENT OF A BREAKDOWN ..............13 OBSERVATIONS AND ADVICE ....................14 PROCEDURE TO FOLLOW IF THE APPLIANCE IS NOT ..............14 GOING TO BE USED FOR SOME TIME ..................14 MAINTENANCE (only for qualified personnel) ................14 IINSTRUCTIONS FOR DISCHARGING GAS EMISSIONS ............14 Officine Gullo... -
Page 4: Installation Manual
INSTALLATION MANUAL Fig. A/1 BBS4G G. Gas Connection ISO 7-1 R1/2GM Officine Gullo... - Page 5 Fig. A/2 BBS8G G. Gas Connection ISO 7-1 R1/2GM Officine Gullo...
- Page 6 Fig. B Injector Thermocouple Piezolelectric device Pilot Drip pan Lighting spark plug 10. Burner Knob 11. Tub Gas pipes Officine Gullo...
-
Page 7: Declaration Of Compliance
DECLARATION OF COMPLIANCE This appliance is manufactured by OFFICINE GULLO S.r.l Headquarters and factory Via Della Torricella 29, Antella, Bagno a Ripoli 50012 Florence - Italy Tel. +39 055 65 60 3324 +39 055 62 18 07 officinegullo.com | info@officinegullo.com... -
Page 8: Checking For Adequate Ventilation
Take suitable measures to guarantee thermal insulation of the inflammable sides, such as, for example, the installation of protection against radiation. The appliances must be installed in a suitable manner, observing the safety standards. The small feet are adjustable to level the appliance. Officine Gullo... -
Page 9: Pipe For Gas Connection
All the burners are provided with a bush for regulating the primary air which must be positioned at a distance h indicated in the technical data table. TECHNICAL BURNERS DATA TABLE 12,68 kWh/kg 12,87kWh/kg 9,45 kWh/m BBS4G 1 burner BBS8G 2 burners BUTANE PROPANE NATURAL GAS (max 9 kW min. 2,7 kW) -
Page 10: Checking Heat Output
• Remove the front fixing screws from the panel, remove the start-up cable from the piezoelectric ignition device • Using a suitable spanner, unscrew the nozzle and substitute it with the right one (see the technical data table). Officine Gullo... -
Page 11: Substituting The Nozzle In The Pilot Burner
Cock: after taking off the front panel, unscrew the screwed fittings from the gas connections and the thermocouple fitting, after which, substitute the cock. • To substitute the thermocouple, unscrew the fitting of the pilot burner, likewise unscrew the thermocouple fitting and substitute the element. • The spark plug must be unscrewed and substituted. Officine Gullo... -
Page 12: User Manual
Push and turn the knob into position “0”. This command blocks the gas supply to both the main burner and the pilot burner. To relight the appliance, it is necessary to turn the knob again into position and press the button. Officine Gullo... -
Page 13: Cleaning And Maintenance
All the brushed steel surfaces should be cleaned using degreasing products or products specifically designed to be used on steel and, where necessary, extra-fine steel wool or extra-thin sandpaper. WHAT TO DO IN THE EVENT OF A BREAKDOWN Turn off the gas tap and notify the after sales service. Officine Gullo... -
Page 14: Observations And Advice
4.3 of the UNI-CIG norm 8723. Supplying the appliance with gas again must only be possible manually. NATURAL DISCHARGE FORCED DISCHARGE Fig.1 Fig.2 Fig.2 1. Extractor hood 1. Extractor hood 2. Interlocking Officine Gullo... - Page 15 Officine Gullo...
- Page 16 international V 2.5 - 7.20 Tel. +39 055 656 0324 | info@officinegullo.com Via Della Torricella 29, Antella, Bagno a Ripoli - 50012 Florence - Italy OFFICINEGULLO.COM...
