TECHNICAL DATA
Nominal voltage: 230 volts
Ampacity (rolled up): max. 4.3 amps
Ampacity (unrolled): max. 13 amps
Power (rolled up): max. 1000 watts
Power (unrolled): max. 3000 watts
Number of sockets: 4
Degree of protection: IP 20
Protection class: 1
Cable length: 15 m
Cable cross section: 3x 1.5 mm²
Storage temperature: -30°C to 50°C
Weight w/o packaging: approx. 2.4 kg
Dimensions:
ATTENTION
Before putting the product into operation, carefully read all safety notes and instructions and always
keep the instructions in the immediate vicinity of the installation location, or on the product. Store the
User manual for future reference and hand over the user manual when selling the product to third
parties.
INTENDED USE
The product serves as extension cable for 230 V electric devices. The maximum permissible
connecting power must not exceed a total of 3,000 W when rolled out and 1,000 W when rolled in.
SAFETY INFORMATIONS
Failure to observe the safety information and instructions may lead to electric shock, burns and
severe injuries.
•
Never operate the product in potentially explosive atmospheres.
•
Never operate the product in aggressive atmospheres.
•
Never operate or use the product with moist or wet hands.
•
Never immerse the product under water.
•
Never place the product on wet or flooded substrates.
•
The product is not a toy. Keep away from children and animals.
•
Use the product only when supervised.
•
Check the product for possible damage before using each time. Do not use the product if it is
damaged.
•
A defective power cable must be replaced by the manufacturer, customer services or a
qualified electrical dealer.
•
Never use the product if damage has been caused to the electric cables or mains connection!
•
Insert the mains connector exclusively into a mains socket fused and earthed correctly.
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Cable Reel, 15 m
width 200 mm
depth 170 mm
height 265 mm
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
BGS 3360
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
