- Page 1 USER MANUAL 49” / 55”M SERIES Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time RSAG2.025.7065SS E English...
- Page 2 The software content service applicable to this product depends on the third party provider, and some software may not be used due to network, region, service cycle and other problems, which has nothing to do with the product quality. Please contact the third party provider for relevant details. www.hisense-b2b.com...
- Page 3 Please do not therefore dispose of your old electrical and electronic equipment with your household waste. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. www.hisense-b2b.com...
- Page 4 Never push objects of any kind into this device through openings as they may touch dangerous voltage points or short-out parts that could result in fire or electric shock. Never spill liquid of any kind on or into the device. www.hisense-b2b.com...
- Page 5 A Main plug is used as the disconnect device, the disconnect device shall remain ready for operating. A Main plug is used as the disconnect device, the disconnect device shall remain ready for a protective earthing connection. www.hisense-b2b.com...
- Page 6 When mounted on the wall: Please leave this space around the device 2. Do not install the device as shown below. Hinder air circulation Insufficient ventilation will overheat the device and may cause damage to the device and even fire. www.hisense-b2b.com...
-
Page 7: Table Of Contents
Wall Mount (Optional) ....................2 Remote Control ......................5 Control Panel ......................7 Terminal Introduction ....................8 Initial Startup ......................10 System Menu ......................11 Serial Protocol ......................12 Miscellaneous ......................15 Specifications ......................16 EU Declaration of Comformity (DoC) ..............18 www.hisense-b2b.com... -
Page 8: Accessories List
At the four wall-mounting positions shown in the figure, the screw installation depth H should be 6-10mm from the bottom of sunken pit in the rear shell. • The vertical installation shall be performed as shown in Figure 2. The screen can not be turned upside down. www.hisense-b2b.com... - Page 9 49_55BM66AE User Manual Figure 1: Horizontal installation Figure 2: Verticle installation www.hisense-b2b.com...
- Page 10 This wall mount is suitable for concrete and brick walls. For plank and plasterboard walls, special reinforcement is required instead of directly using the wall mount. Ensure that a single expansion bolt fixed in the wall can bear over 1 /3 of the overall weight of the machine. www.hisense-b2b.com...
-
Page 11: Remote Control
Move the focus left/right, etc. Home Enter the home page of the machine Increase/decrease the volume (+/-) Note When the remote control is locked, it can be unlocked by pressing the “Unlock OK - OK - Unlock” keys in sequence. www.hisense-b2b.com... - Page 12 (Please dispose of waste and used batteries properly as such batteries can cause environmental pollution.) 2. To achieve the optimal remote control reception effect, please align the remote transmitter of the remote control with the remote receiver on the machine. www.hisense-b2b.com...
-
Page 13: Control Panel
[ Note ] • The appearance is subject to the actual product. • Since power outage and system processing takes some time, DO NOT power on and off the machine in rapid succession; otherwise the machine may work abnormally. www.hisense-b2b.com... -
Page 14: Terminal Introduction
[ Note ] • The appearance is subject to the actual product. • Since power outage and system processing takes some time, DO NOT power on and off the machine in rapid succession; otherwise the machine may work abnormally. www.hisense-b2b.com... - Page 15 RS232 port: It is for serial communication control of the machine. • It is possible that some external devices cannot be connected to the machine due to individual difference. In such case, please replace the signal line with a suitable one or add an adapter cable matching the port. www.hisense-b2b.com...
- Page 16 The rear view is for reference only, subject to the actual product. • It is possible that some external devices cannot be connected to the machine due to individual difference. In such case, please replace the signal line with a suitable one or add an adapter cable matching the port. www.hisense-b2b.com...
-
Page 17: Initial Startup
Press the arrow keys to select each option Press the OK key to confirm operation or enter the sub-menu Press the LEFT/RIGHT key to adjust values Press the UP/DOWN key to adjust options • Press the key to go back to the previous menu. www.hisense-b2b.com... -
Page 18: System Menu
ON, the remote control can be used only after the correct password is input. • Net Start System: The default state is OFF. When it is OFF, the machine cannot be woken up; when it is ON, the machine can be woken up via network. www.hisense-b2b.com... -
Page 19: Serial Protocol
XX is the check digit OFF, PC to TV AA AA TV to PC AA AA ON/OFF ON, PC to TV TV to PC OFF, PC to TV TV to PC Mute Control ON, PC to TV TV to PC www.hisense-b2b.com... - Page 20 00 is the unmuted state; valid in power-on state); the seventh XX represents the signal presence/ absence state (00 means signal is absent; 01 means signal is present, valid in power-on state); the eighth XX is the check digit www.hisense-b2b.com...
- Page 21 500ms before resending the command. • When the TV is in sleep mode, only the startup command and the query command are supported. • Check digit: XOR values of length, command code, Board ID, data. www.hisense-b2b.com...
-
Page 22: Miscellaneous
• The software content services applying to this product depend on the third-party provider. It is possible that partial software cannot be used due to network, region, service period or other problems, which has nothing to do with the product quality. Please contact the third-party provider for relevant details. www.hisense-b2b.com... -
Page 23: Specifications
49_55BM66AE User Manual Specifications Product Name Digital Signage Model 49BM66AE 55BM66AE Size(mm) (WxHxD)excluding 11Q5x639x65 1241x715x66 base Weight(kg) excluding base 16.7 20.5 Visual picture diagonal size(cm) Power supply 100-240V-50/60Hz 2A Model W2NM2510 Wireless LAN Module Frequency 2.4-2.4835GHz Specifica- Range tions Output 2.4-2.4835GHz 17.5dBm... - Page 24 .ts .mkv Dolby Audio, AAC, MPEG1 H.265 4096X2160 160Mbps 60fps .mp4 (Layer1 ,2,3) Dolby Audio: Support Dolby Digital and Dolby Digital Plus. [Note] Since video production tools are nonuniform, it cannot be guaranteed that the machine supports all listed formats. www.hisense-b2b.com...
-
Page 25: Eu Declaration Of Comformity (Doc)
*The company reserves the right to install updated Software versions to improve the performance of the appliance. Place and date of issue (of this DoC): QingDao 2020/06/15 Signed by or for the manufacturer: Hisense Commercial Display Co., Ltd. Address: No. 218, Qianwangang Road, Economic& Technology Development Zone, Qingdao, China Title: Product manager Name (in print): Yanglin www.hisense-b2b.com... - Page 26 *The company reserves the right to install updated Software versions to improve the performance of the appliance. Place and date of issue (of this DoC): QingDao 2020/06/15 Signed by or for the manufacturer: Hisense Commercial Display Co., Ltd. Address: No. 218, Qianwangang Road, Economic& Technology Development Zone, Qingdao, China Title: Product manager Name (in print): Yanglin www.hisense-b2b.com...
- Page 27 Hisense Commercial Displays Tel : +44 (0)115 8248811 Email: sales@hisense-b2b.com Web: www.hisense-b2b.com...
