The Genesis
is a professionally designed tent series offering an elegant
®
profile and spacious interiors. Like a building pre-fabricated of tensile
components, each element is designed to specific load and weather
protection criteria. Extensive field testing and years of rental experience
now identifies the Genesis as a proven leader in rental tents.
Genesis Tent Construction Features
• SNYDER 14-18 oz. Translucent or blockout vinyl
laminate tent fabric that is flame retardant and
mildew resistant
• Cast aluminum side pole and center pole fittings
• Reinforced pole positions
• Catenary Web belts
• Rope and grommet lace lines
• Double rain flaps
• Sealed valances with Velcro closures
In s t r u ct i o n s f o r :
Genesis tents are a Todd Dalland/FTL Happold design
30' Wide with 7'or 8' Aluminum or Wood side poles
40' Wide with 7'or 8' Aluminum or Wood side poles
50' Wide with 8' Aluminum or Wood side poles
60' Wide twin center poles with 8' Aluminum or Wood side poles
w w w . e u r e k a t e n t s . c o m f a x : 6 0 7 . 7 7 9 . 2 2 9 1
• Removable ropes with carabiner fasteners on
30'-50', optional on 60'
• Side pole and center pole jump ropes
• Sidewall rope permanently installed
• Ring and snap attachments for tent sections
• Genesis tents are provided with storage bags
• Genesis tents are professionally designed,
patterned, cut, manufactured and finished
R E V . G 5 . 0 7
