Wahl 7388 - Cordless Shaver Manual

IMPORTANT SAFEGUARDS

When using your electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS AND SAFEGUARDS BEFORE USING THIS APPLIANCE.

To reduce the risk of death or injury by electric shock:

1. Do not reach for an appliance that has fallen into water. Unplug immediately from the outlet. Note: Some electrical parts inside the appliance are electrically live, even with the switch "OFF."
2. Do not use while bathing or in a shower.
3. Do not place or store appliance where it can fall or be pulled into a tub or sink. Do not place in or drop into water or other liquid.
4. Always unplug this appliance before cleaning.
5. Except when charging, always unplug this appliance from the electrical outlet immediately after using.

To reduce the risk of burns, electrical shock or injury to persons:

1. This appliance can be used by children aged from 14 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction, by a person responsible for their safety, concerning the use of the appliance in a safe way and understand the hazards involved. Children should be supervised to ensure that they do not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
2. Use this appliance only for its intended use as described in this manual. Do not use attachments not recommended by the manufacturer.
3. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or if it has been dropped into water. Return the appliance to Wahl Clipper Corporation for examination and repair.
4. Keep the cord away from heated surfaces.
5. Never operate the appliance with the air openings blocked or while on a soft combustible surface, such as a bed or couch, where air openings may be blocked. Keep the air openings (if any) free from lint, hair or the like.
6. Do not use outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered.
7. Never drop or insert any object into any opening.
8. Do not use this appliance with damaged or broken foils, as injury may occur. Before use, make certain blades are aligned properly. (See Shaver Care Instructions. May not be applicable for all appliances.)
9. 9. During use, do not place or leave the appliance where it is expected to be subject to damage by an animal, or exposed to weather.
10. To disconnect, turn all controls to "OFF," then remove plug or charger from outlet.
11. Turn all controls to "OFF" before placing on or removing blades or attachments.
12. An appliance with a permanently attached cord should never be left unattended when plugged in.
13. Keep this appliance dry.

For an appliance that has a rechargeable battery:

14. Do not crush, disassemble, heat above 100°C (212°F), or incinerate the appliance, due to risk of fire, explosion, or burns.
15. For the purpose of recharging the battery, only use the detachable power supply unit (charger) provided with this appliance.
16. This charger is intended to be correctly orientated in a vertical or floor mount position.
17. Always attach plug to appliance first, then to outlet.
18. Use charge stand with Wahl products and power supplies only.

SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR COMMERCIAL USE ONLY

QUICK TIPS

The foil is for super close cutting and designed to cut hair that is 1/32" or shorter.

The foil needs to glide over the skin. Do not press hard against the skin but allow the shaver to work for you. Pressing against the skin too hard can cause damage to the foil.

It is important to use the shaver with a foil and cutter bar assembly that is clean and free of hair and other debris that might affect performance.

The foil and cutter bar assembly are wear out parts. Replacement may vary depending on usage. The foil is micro-thin with precise, raised inner cutting edges around the holes. These raised cutting edges will wear with use which will be indicated if your shaver slows down and the foil seems to get warm.

To ensure continued shaving satisfaction, you should replace the foils often and cutter bar assembly periodically.


CUTTER BARS

Replace cutter bar assembly if damaged. Damage to the foil will result from using a broken or bent cutter bar assembly.
REPLACEMENT FOIL/CUTTER BAR ASSEMBLY
WAHL MODEL NO. 7031-100
Replace foil if creased, worn or broken. Using a damaged or broken foil can result in facial injury.

REPLACEMENT SUPER CLOSE GOLD FOIL
WAHL MODEL NO. 7031-200

Always replace the Foil Guard to protect the delicate dual foil heads when the shaver is not in use.

If you are a first-time electric shaver user, or changing FACE from another brand, there will be a 2-3 week (or less) adjustment period, while your face and beard adapt to the new foil.

During the break-in period of the cutter bar, black residue may be left on the face. It is a harmless combination of whiskers, skin debris and minute particles from the cutter bar, which will wash off easily. This condition will quickly disappear with use.

We suggest that you thoroughly cleanse and completely dry skin prior to shaving. For those times when the beard is longer than 1/32" begin by using a trimmer to cut the beard, then use the shaver to get a close, clean shave.

Begin shaving at the neckline, in short, upwards strokes and then continuing upwards until you have shaved all areas of the beard. The shaver is designed to remove most facial hair and give a close, clean shave that is bump and irritation free.

SHAVER USE

USING CORD/CORDLESS SHAVERS
If battery power is low, the power cord can attach directly to the unit for continued use as a corded unit.

CORDED OPERATION

• Attach power cord plug into shaver first, then to outlet. If your battery is completely run down, allow the unit to charge for 1 minute (switched OFF) before using as a corded unit. (Figure 1)
• If the cord is left attached to the shaver when not in use, the cord will automatically charge the shaver when left in the OFF position.


RECHARGING OPTIONS

• For units without a recharge stand, attach power cord plug into shaver first, then to outlet. Be sure shaver is switched OFF when charging. (Figure 1)
• For units with a recharge stand, place shaver in recharge stand so nameplate faces forward. Attach power cord plug into recharge stand first, then to outlet. (Figure 2) Not all units have a recharge stand.

CHARGING THE BATTERY

Before the equipment is used for the first time, it should be charged fully.
For recharging information, refer to Shaver Use Recharging Options.
Recommendation: The batteries should only be recharged when the performance of the equipment has deteriorated noticeably.

BATTERY OPERATION

Switch ON the unit using the ON/OFF switch and, after use, switch it OFF again. When the battery is fully charged, the unit can be used for up to 60 minutes of continuous run.

LED INDICATOR

1. Solid: LED will be fully lit when battery has reached full charge.
2. Pulse: While charging, LED will pulse until battery is fully charged. The LED will change to solid when the battery has a full charge.

SHAVER CARE

CLEANING THE FLEX FOIL HEAD AND CUTTER BAR ASSEMBLY

1. Remove the flex foil head from the top of the unit by pressing the round button located on the right side of the unit. Next, lift the flex foil head off of the unit. The flex foil head may be cleaned of loose material, by gently tapping the housing against the surface of your sink.
   The foil is micro-thin with precise, raised inner cutting edges, always handle with care.


2. To remove the cutter bar assembly, gently press down on it and turn the assembly 90 degrees.


3. Gently brush any loose hair and debris from the cutter bar assembly with the pre-unit brush. Run the cutter bar assembly under warm water and dry it off with a paper towel.


4. Return the cutter bar assembly to the unit by reversing this process.


5. Replace the flex foil head to the top of the unit before use.


DO NOT DIP OR SOAK the shaver or foils in any type of cleaning solution, disinfectant or oil. To disinfect foils, spray disinfectant directly onto foils and wipe off excess liquid to prevent damage to the foil housing. Excess liquid can deteriorate the unit's plastic components and seep into the motor compartment affecting motor life and performance.

UNIT CARE

Use a clean cloth (dry or dampened with water).
DO NOT USE bleach, benzene or thinner to clean the unit.

CORD CARE

The cord should never be used to pull the shaver. Freedom of movement needs to be maintained. Care should be used to keep the cord untwisted, and undamaged. When stored, the cord should be coiled and placed neatly in a dry place.

NI-CAD BATTERY REPLACEMENT, SHAVER DISPOSAL AND RECYCLING

CONTAINS SEALED, RECHARGEABLE NICKEL-CADMIUM BATTERY. MUST BE RECYCLED OR DISPOSED OF PROPERLY.

The RBRC Battery Recycling Seal on the nickel-cadmium (Ni-Cd) battery contained in this product indicates Wahl is voluntarily participating in an industry program to collect and recycle these batteries at the end of their useful life, when taken out of service in the United States or Canada. The RBRC program provides a convenient alternative to placing used Ni-Cd batteries into the trash or the municipal waste stream, which is illegal in some areas. Please call 1-800-8-BATTERY for information on Ni-Cd battery recycling in your area. Wahl's involvement in this program is part of our commitment to preserving our environment and conserving our natural resources.
The battery must be removed from the unit before it is scrapped. The unit must be disconnected from the supply mains when removing the battery. The battery is to be disposed of safely.

1. Remove the flex foil head.
2. Remove the cutter bar assembly by gently pressing down and turning the bar 90 degrees.
3. Remove the two spring clips on the top of the unit using a small, flat blade screwdriver.
4. Pull back the unit housing away from the unit.
5. Cut the wire to the negative side (-) of the battery and then cut the wire to the positive side (+) of the battery.
6. Remove the battery by prying the cement loose.

The battery is a non-consumer replaceable battery. For battery replacement, send your unit and recharging transformer to Wahl Clipper Corporation for service.

TROUBLESHOOTING

If your cord/cordless shaver does not seem to be operating or charging properly, please check the following:

• Check the outlet's current by plugging another appliance (one you know is in proper working condition) into the outlet.
• Make sure the unit is not connected to a power source that turns itself off when lights are turned off.
• Make sure the unit and recharging transformer contacts are clean and free of hair or other contaminants.
• Verify that the blade assembly moves freely and is mounted properly.

If you still encounter problems with your unit, send your unit and recharging transformer to Wahl Clipper Corporation with a note explaining the problem.

Wahl Clipper Corporation offers a limited warranty on this product.
Please visit our website for full warranty terms.

For servicing, please ship your product prepaid to:
Wahl Service Center
3001 North Locust Street
Sterling, IL 61081
